Channel allocation

Channel Allocation


Channel allocation problem multiple access protocols

Channel Allocation Problem

Multiple Access Protocols


Two types of transmission technology

Two types of transmission technology

Point-to-Point Link

Broadcast Link


Channel allocation problem

Channel AllocationProblem

Static Method

Dynamic Method


Lans channel allocation

LANs: channel allocation

  • Allocation?Who goes next?

    • Static: assignment for long duration

    • Dynamic: stations continuously compete


Lans channel allocation1

LANs: channel allocation

  • Static channel allocation

    • Scheme:

    • After allocation:

    • Division of channel

  • Request channel

  • Data Transfer

  • Release channel

  • Channel is private

  • Can be used for a long time

  • FDM: Frequency division multiplexing

  • TDM: time division multiplexing

Data link layer -- June 2004


Lans channel allocation2

1

T =

 . C - 

LANs: channel allocation

  • Static channel allocation

    • Simple and efficient

      • Small & fixed number of users

      • Heavy load

    • Problems

      • Loss of bandwidth

        • If some users are quiescent

        • If less users than subchannels

      • Poor performance


Lans ma protocols

LANs: MA Protocols

Multiple Access protocols

  • University of Hawaii Aloha system

    • Central computer system

    • Terminals spread over 4 islands

    • Communication: FM radio

    • No station to station communication

    • Shared channel for communication from terminals to computer system

    • Transmission strategy:

      • Terminal sends data as data comes available

      • Collision possible

      • Retransmission if no ack received


Aloha

ALOHA

Idea: Users can transmit whenever they have data to send

Aloha!!

  • Two types of ALOHA:

  • Pure ALOHA

  • Slotted ALOHA

    The main difference between them is time and time and time


Pure aloha

frame

Send & then wait

for collision

collision?

wait a random

time

yes

no

end

Pure ALOHA

continuous time

no global time synchronization


Lans ma protocols1

2 frames sent at same time  collision

both frames destroyed

LANs: MA Protocols

  • Pure Aloha: frames transmitted at arbitrary times

Contention system


Lans ma protocols2

LANs: MA Protocols

  • Pure Aloha: channel efficiency

    • Vulnerable period = 2 x packet time

    • Packet time = time required to transmit 1 frame


Slotted aloha

Slotted ALOHA

1. Time is divided to equal intervals (slots)

2. Need time synchronization

3. Frames can only be transmitted at starts of time slots


Lans ma protocols3

LANs: MA Protocols

  • Aloha: channel efficiency

    • Pure: max 18%

    • Slotted (time divided in slots; start sending at start of slot)


Csma with collision detection csma cd

CSMA with Collision Detection (CSMA/CD)

How?

Idea: A station stop transmitting its frame immediately after a collision is detected to save time and bandwidth

This is the basis of Ethernet LAN

But: half-duplex


Lans csma protocols

LANs: CSMA protocols

Carrier Sense Multiple Access CSMA

  • Aloha type system + ability to test for a carrier i.e. a transmission

  • Persistent <> Nonpersistent

    • 1-persistent

      • If channel is idle, a frame is transmitted

      • If channel is busy, the channel is continuously checked

    • Nonpersistent

      • If channel is idle, a frame is transmitted

      • If channel is busy, a random time is waited before channel is sensed again

    • p-persistent (slotted channel only)

      • If channel is idle a frame is transmitted with probability p

      • If channel is busy, next slot is sensed again


Lans csma protocols1

LANs: CSMA protocols

Carrier Sense Multiple Access CSMA

  • Performance


Lans csma cd protocols

LANs: CSMA/CD protocols

Carrier Sense Multiple Access Collision Detect

  • Strategy

    • Try to detect collisions asap

    • Listen while transmitting

    • If collision is detected, abort transmission

  • Channel model


Lans csma cd protocols1

LANs: CSMA/CD protocols

Carrier Sense Multiple Access Collision Detect

  • Contention period

    • Worst case scenario

    • Detection = analog process


Lans collision free protocols

LANs: collision free protocols

  • Problem?

    • Very long, high bandwidth protocols

    • 1 km, 10 Mbps = 5 sec or 50 bits

  • Bit-Map protocol

    • Each contention period has N slots (N = #stations)

    • Station k is assigned slot k; is used to indicate if station k has to send data

    • Data transmission proceed without collisions

  • 20 km, 100 Mbps = 100 sec or 10.000 bits

  • 1 km, 10 Gbps = 5 sec or 50.000 bits


Lans wdma protocols

LANs: WDMA protocols

Wavelength division multiple access

  • Approach:

    • Divide channel into subchannels(FDM,…)

    • Allocate them as needed

  • 2 channels/station

    • Narrow: used by other stations to signal the station:

    • Wide: used by station to output data frames

Data link layer -- June 2004


Lans wireless protocols

LANs: wireless protocols

  • Common configuration for a wireless LAN

    • Base stations (access points) wired together

    • Notebooks with radio transmitter/receiver

    • A receiver within range of 2 active transmitters receives a garbled signal

    • Not all stations are in range of one another

    • CSMA does not work: interference at receiver is important not at sender

    • Example …


Lans wireless protocols1

A sends to B

If C senses medium, it will not hear A

If C transmits to B, it will garble the signal at B

Hidden station problem

B sends to A

If C senses the medium, it may falsely conclude it cannot send to D

Exposed station problem

LANs: wireless protocols


Lans wireless protocols2

A wants to send to B

A sends RTS (request to send) frame (short frame) with length of data frame

B replies with CTS (clear to send) frame, containing same length

LANs: wireless protocols

Multiple Access with Collision Avoidance MACA

Data link layer -- June 2004


Lans wireless protocols3

A wants to send to B

A sends RTS (request to send) frame (short frame) with length of data frame

Stations hearing RTS should remain silent to not interfere with CTS

B replies with CTS (clear to send) frame, containing same length

Stations hearing CTS should remain silent to not interfere with data frame

LANs: wireless protocols

Multiple Access with Collision Avoidance MACA

Collisions possible!

Wait random time

Binary exponential backoff!

Data link layer -- June 2004


Lans wireless protocols4

LANs: wireless protocols

MACAW = MACA for Wireless

  • Optimisations for MACA

    • Introduce ACK from receiver of data frame to sender: detect loss in DL iso network/transport layer

    • Add CSMA: avoid sending a RTS by a station close to a station sending to the same destination

    • Run binary exponential backoff for each destination iso each station

    • Exchange of information between stations about congestion


Lans ieee 802 3 or ethernet

LANs: IEEE 802.3 or Ethernet

  • Overview

    • 1-persistent CSMA/CD

      • When a station wants to transmit, it listens to the cable

      • If idle, it transmits immediately

      • If busy, it waits until the cable goes idle

      • If collision, it waits a random time

    • History

      • Real start: Aloha

      • 3 Mbps experiment at Xerox  ethernet

      • Agreement between Intel, DEC, Xerox

      • Base for IEEE 802.3


Ethernet cabling

Ethernet Cabling

The most common kinds of Ethernet cabling.


Ethernet cabling 2

Ethernet Cabling (2)

Three kinds of Ethernet cabling.

(a) 10Base5, (b) 10Base2, (c) 10Base-T.


Ethernet cabling 3

Ethernet Cabling (3)

Cable topologies. (a) Linear, (b) Spine, (c) Tree, (d) Segmented.


Channel allocation

802.3 MAC Frame

2 or 6

1

2 or 6

2

4

7

Destination

Address

Source

Address

Information

FCS

Pad

Preamble

Length

SD

Synch

Start

frame

64 to 1518 bytes

  • Destination address is either single address

  • or group address (broadcast = 111...111)

  • Addresses are defined on local or universal basis

  • 246 possible global addresses

0

Single address

Group address

1

0

Local address

1

Global address


Channel allocation

Ethernet Frame

2 or 6

1

2 or 6

2

4

7

Destination

Address

Source

Address

Information

FCS

Pad

Preamble

Type

SD

Start

frame

Synch

64 to 1518 bytes


Switched ethernet

Switched Ethernet

A simple example of switched Ethernet.


Different between hub and switch

Different between Hub and Switch

  • In a hub, a frame is passed along or "broadcast" to every one of its ports. It doesn't matter that the frame is only destined for one port. The hub has no way of distinguishing which port a frame should be sent to. Passing it along to every port ensures that it will reach its intended destination. This places a lot of traffic on the network and can lead to poor network response times.


Different between hub and switch1

Different between Hub and Switch

  • A switch, however, keeps a record of the MAC addresses of all the devices connected to it. With this information, a switch can identify which system is sitting on which port. So when a frame is received, it knows exactly which port to send it to, without significantly increasing network response times.


Channel allocation

     

Twisted Pair Ethernet

hub

Single collision domain

(a)

switch

High-Speed Backplane or Interconnection fabric

(b)

   


Switched ethernet1

Switched Ethernet

  • Basic idea: improve on the Hub concept

  • The switch learns destination locations by remembering the ports of the associated source address in a table.

  • The switch may not have to broadcast to all output ports. It may be able to send the frame onlyto the destination port.

  •  a big performance advantage over a hub, if more than one frame transfer can go through the switch concurrently.


Fast ethernet

Fast Ethernet

The original fast Ethernet cabling.


Gigabit ethernet

Gigabit Ethernet

(a) A two-station Ethernet. (b) A multistation Ethernet.


Gigabit ethernet1

Gigabit Ethernet

  • Full-duplex operation mode  switches

    • Collisions impossible: CSMA/CD not used

    • Maximum cable length determined by signal strength

  • Half -duplex operation mode  hubs

    • Collisions possible: CSMA/CD required

    • Cable length not to be reduced: 200m!

    • Solutions:

      • Carrier extension: hardware padding of frames to minimum of 512 bytes

      • Frame bursting: transmit concatenated sequence of frames in a single transmission


Wireless lans 802 11

Wireless LANs – 802.11

  • 2 modes:

    • In the presence of a wired base station – access point

    • In the absence of a base station – ad hoc networking

  • Make 802.11 compatible with ethernet
