  1. HI-WIRE Final Design Report

  2. Executive Summary • Project Plan • Haptic Feedback System • Immersive • Intuitive • Implementation • Vest • Vibration • 360 degree feedback coverage

  3. Vest Fabrication • Pattern • Butterick suit Vest • Fits Small to Large Users • Materials • 2-way Lycra • 1" Nylon Webbing • Plastic Buckles • Design Features • Shoulder, stomach, and rib sizing straps • 360 degree feedback coverage • Pouch on the upper back to hold motor battery, controller PCB, and Arduino

  4. Vest Fabrication

  5. Vest Fabrication • Two motors • More powerful vibrations • Large surface area • Motors offset by height and mass distribution • Increased vibration sensitivity • Vibration phase change

  6. Vest Fabrication • Parallel motors (2x30) • Connection protection • Hot glue • Heat shrink • Homemade twisted pair • 2-pin female JST(XH) connector • Carpet tape • Thin • Sticky

  7. Vibration Motor Control • Hardware • Custom-Designed Circuit Board (Rev. 2) • Motors • 20 currently • 32 possible • 2 TLC4950 ICs • One channel per motor • Controlled by one signal

  8. Vibration Motor Control • Software • Arduino IDE • Arduino Pro (3.3V, 8Mhz) • TLC4950 Library • Handles bit level serial commands • Vest Program • Awaits connection with WiFly • Enters Data Loop • Requests motor speeds • Pre-scaled and pre-mapped by server • Updates motors

  9. Original Testing Platform • Platform • Stability Issues • Large Area • Sonar Sensor • Slow Update Rate • 180° Coverage • Duck Antenna • Obstruction of Sensors

  10. Cycle 2 Platform • Platform • Better Stability • Sensors • Speed • 2 IR Sensors (front and back) • 360° Coverage • Patch Antenna • Same gain (2 dBi) • Low Profile

  11. Communication • Basic Setup • Server • Wifi Card - IEEE 802.11b • Python Library SocketServer • Robot/Vest - WiFly module • Protocol - TCP/IP • Resend/Checksum benefits • Port Allocation - Port 3000 • Weakness - Backoff time

  12. Communication (cont.) • Packet Structure - 20 bytes

  13. User Interface • Purposes • End-User Friendliness • Expedition of Testing/Debugging • Implementation • Written in Python • Uses PyGTK library • Built with Glade

  14. User Interface

  15. User Interface • Features • Robot and Vest Connection Status • Sensor Settings • Activation • Gimble settings • Sensor Status • Placement • Offset from Center • Sensor Type • Basic Load/Save Functions

  16. User Interface

  17. Standards • Vest Size • ISO/TR 10652 (International Clothing Std.) • Sizes S, M, L • Wireless Networking • IEEE 802.11b • Protocols and Configurations • Communication Protocol • TCP/IP • Internet Engineering Task Force (IETF) - RFC 793

  18. Conclusion • Project Results • Bottlenecks • Sensors • Communication • Redundancy Needed • Mimic Human Sensory System

  19. Demonstration and Questions
