  1. How to program our lighting consoles . . . 300 Series Consoles

  2. THE PROCESS

  3. Turn on Console

  4. Turn on Console Live

  5. Wheel level Channel Levels List of upcoming cues List of submasters CH 1 ON View commands

  6. Turn on Channel (fire up a lantern) 1 ON

  7. FL CH 1 ON

  8. Turn on Channel 5 Full

  9. FL FL

  10. Turn on Channel To specific level 4 @ 5 0 *

  11. FL 50 FL

  12. Turn on Channel To specific level 9 @ W H E E L (to lets say 79%)

  13. FL 50 FL 79

  14. Turn on a group of Channels 9 THUR 1 2 @ 5 0 *

  15. FL 50 FL 50 50 50 50

  16. Turn on a group of Channels 9 + 1 2 @ 5 *

  17. FL 50 FL 50 50

  18. Turn off a Channel 1 OFF

  19. Turn off a Channel 1 THRU 2 1 OFF

  20. Turn on Channel 1 ON 1 Full Turn on Channel To specific level 1 @ 5 0 * W H E E L 1 @ Turn on a group of Channels 1 THRU 7 * @ 5 0

  21. Store a look as a cue CUE 1 REC The number of the cue you wish to record If cue already exists the console will tell you – you Will then need to press *

  22. Slip in a cue between two existing cues CUE 1 . 5 REC ( * )

  23. To fade the next cue in and the last cue out using specific timing CUE 1 . 5 TIME 2 / 5 REC *

  24. > 1 XF 2 / 5

  25. Store look on a submaster SUB 1 REC

  26. To run show CUE 0 GO 1 Then . . . GO 1 . . . To progress through cues in order.

  27. If you press GO 1 too soon the press Stop/Back once to hold the cue or twice to go back to the previous cue.

  28. To delete a cue CUE 1 * Delete| *

  29. To shutdown the Console press . . . Report

  30. . . . then look at the little green screen to find . . . EXIT . . . press the soft key that points to . . . EXIT EXIT

  31. . . . then look at the little green screen to find . . . SHUTDOWN . . . press the soft key that points to . . . SHUTDOWN Then [ *] SHUTDOWN
