Behavioral design style registers counters shift registers basic testbenches l.jpg

ECE 448

Lecture 5

Behavioral Design Style:Registers, Counters, Shift RegistersBasic Testbenches

ECE 448 – FPGA and ASIC Design with VHDL


Required reading l.jpg
Required reading

  • S. Brown and Z. Vranesic,Fundamentals of Digital Logic with VHDL Design

    • Chapter 7, Flip-Flops, Registers, Counters,

    • and a Simple Processor

    • (7.14 optional)

ECE 448 – FPGA and ASIC Design with VHDL


Optional reading l.jpg
Optional Reading

  • Sundar Rajan, Essential VHDL: RTL Synthesis

  • Done Right

  • Chapter 4, Registers and Latches

  • Chapter 5, Counters and Simple Arithmetic

  • Functions

  • (see errata at http://www.vahana.com/bugs.htm)

ECE 448 – FPGA and ASIC Design with VHDL


Slide4 l.jpg

Behavioral Design Style:

Registers & Counters

ECE 448 – FPGA and ASIC Design with VHDL


What is a process l.jpg
What is a PROCESS?

  • A process is a sequence of instructions referred to as sequential statements.

The keyword PROCESS

  • A process can be given a unique name using an optional LABEL

  • This is followed by the keyword PROCESS

  • The keyword BEGIN is used to indicate the start of the process

  • All statements within the process are executed SEQUENTIALLY. Hence, the order of statements is important.

  • A process must end with the keywords END PROCESS.

testing: PROCESS

BEGIN

test_vector<=“00”;

WAIT FOR 10 ns;

test_vector<=“01”;

WAIT FOR 10 ns;

test_vector<=“10”;

WAIT FOR 10 ns;

test_vector<=“11”;

WAIT FOR 10 ns;

END PROCESS;

ECE 448 – FPGA and ASIC Design with VHDL


Anatomy of a process l.jpg
Anatomy of a Process

OPTIONAL

[label:]PROCESS[(sensitivity list)]

[declaration part]

BEGIN

statement part

ENDPROCESS [label];

ECE 448 – FPGA and ASIC Design with VHDL


Statement part l.jpg
Statement Part

  • Contains Sequential Statements to be Executed Each Time the Process Is Activated

  • Analogous to Conventional Programming Languages

ECE 448 – FPGA and ASIC Design with VHDL


Process with a sensitivity list l.jpg

List of signals to which the process is sensitive.

Whenever there is an event on any of the signals in the sensitivity list, the process fires.

Every time the process fires, it will run in its entirety.

WAIT statements are NOT ALLOWED in a processes with SENSITIVITY LIST.

label: process (sensitivity list)

declaration part

begin

statement part

end process;

PROCESS with a SENSITIVITY LIST

ECE 448 – FPGA and ASIC Design with VHDL


Processes in vhdl l.jpg
Processes in VHDL

  • Processes Describe Sequential Behavior

  • Processes in VHDL Are Very Powerful Statements

    • Allow to define an arbitrary behavior that may be difficult to represent by a real circuit

    • Not every process can be synthesized

  • Use Processes with Caution in the Code to Be Synthesized

  • Use Processes Freely in Testbenches

ECE 448 – FPGA and ASIC Design with VHDL


Slide10 l.jpg

Use of Processes

in the Synthesizable Code

ECE 448 – FPGA and ASIC Design with VHDL


Component equivalent of a process l.jpg

All signals which appear on the left of signal assignment statement (<=) are outputs e.g. y, z

All signals which appear on the right of signal assignment statement (<=) or in logic expressions are inputse.g. w, a, b, c

All signals which appear in the sensitivity list are inputs e.g. clk

Note that not all inputs need to be included in the sensitivity list

Component Equivalent of a Process

clk

y

w

priority

a

z

b

c

priority: PROCESS (clk)

BEGIN

IF w(3) = '1' THEN

y <= "11" ;

ELSIF w(2) = '1' THEN

y <= "10" ;

ELSIF w(1) = c THEN

y <= a and b;

ELSE

z <= "00" ;

END IF ;

END PROCESS ;

ECE 448 – FPGA and ASIC Design with VHDL


Vhdl design styles l.jpg
VHDL Design Styles statement (<=) are outputs e.g.

dataflow

VHDL Design

Styles

structural

behavioral

Concurrent

statements

Components and

interconnects

Sequential statements

Registers & counters

ECE 448 – FPGA and ASIC Design with VHDL


Slide13 l.jpg

Registers statement (<=) are outputs e.g.

ECE 448 – FPGA and ASIC Design with VHDL


Slide14 l.jpg

Q statement (<=) are outputs e.g.

D

Clock

D latch

Truth table

Graphical symbol

Q(t+1)

Clock

D

Q(t)

0

0

1

0

1

1

1

Timing diagram

t

t

t

t

1

2

3

4

Clock

D

Q

Time

ECE 448 – FPGA and ASIC Design with VHDL


Slide15 l.jpg

Q statement (<=) are outputs e.g.

D

Clock

D flip-flop

Truth table

Graphical symbol

Q(t+1)

Clk

D

0

0

1

1

Q(t)

0

Q(t)

1

Timing diagram

t

t

t

t

1

2

3

4

Clock

D

Q

Time

ECE 448 – FPGA and ASIC Design with VHDL


Slide16 l.jpg

Q statement (<=) are outputs e.g.

D

Clock

D latch

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY latch IS

PORT ( D, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC) ;

END latch ;

ARCHITECTURE Behavior OF latch IS

BEGIN

PROCESS ( D, Clock )

BEGIN

IF Clock = '1' THEN

Q <= D ;

END IF ;

END PROCESS ;

END Behavior;

ECE 448 – FPGA and ASIC Design with VHDL


Slide17 l.jpg

D flip-flop statement (<=) are outputs e.g.

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY flipflop IS

PORT ( D, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC) ;

END flipflop ;

ARCHITECTURE Behavior_1 OF flipflop IS

BEGIN

PROCESS ( Clock )

BEGIN

IF Clock'EVENT AND Clock = '1' THEN

Q <= D ;

END IF ;

END PROCESS ;

END Behavior_1 ;

Q

D

Clock

ECE 448 – FPGA and ASIC Design with VHDL


Slide18 l.jpg

D flip-flop statement (<=) are outputs e.g.

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY flipflop IS

PORT ( D, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC) ;

END flipflop ;

ARCHITECTURE Behavior_2 OF flipflop IS

BEGIN

PROCESS

BEGIN

WAIT UNTIL Clock'EVENT AND Clock = '1' ;

Q <= D ;

END PROCESS ;

END Behavior_2 ;

Q

D

Clock

ECE 448 – FPGA and ASIC Design with VHDL


Slide19 l.jpg

D flip-flop with statement (<=) are outputs e.g. asynchronous reset

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY flipflop IS

PORT ( D, Resetn, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC) ;

END flipflop ;

ARCHITECTURE Behavior OF flipflop IS

BEGIN

PROCESS ( Resetn, Clock )

BEGIN

IF Resetn = '0' THEN

Q <= '0' ;

ELSIF Clock'EVENT AND Clock = '1' THEN

Q <= D ;

END IF ;

END PROCESS ;

END Behavior ;

Q

D

Clock

Resetn

ECE 448 – FPGA and ASIC Design with VHDL


Slide20 l.jpg

D flip-flop with statement (<=) are outputs e.g. synchronous reset

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY flipflop IS

PORT ( D, Resetn, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC) ;

END flipflop ;

ARCHITECTURE Behavior OF flipflop IS

BEGIN

PROCESS

BEGIN

WAIT UNTIL Clock'EVENT AND Clock = '1' ;

IF Resetn = '0' THEN

Q <= '0' ;

ELSE

Q <= D ;

END IF ;

END PROCESS ;

END Behavior ;

Q

D

Clock

Resetn

ECE 448 – FPGA and ASIC Design with VHDL


Slide21 l.jpg

8 statement (<=) are outputs e.g.

8

Resetn

D

Q

Clock

reg8

8-bit register with asynchronous reset

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY reg8 IS

PORT ( D : IN STD_LOGIC_VECTOR(7 DOWNTO 0) ;

Resetn, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC_VECTOR(7 DOWNTO 0) ) ;

END reg8 ;

ARCHITECTURE Behavior OF reg8 IS

BEGIN

PROCESS ( Resetn, Clock )

BEGIN

IF Resetn = '0' THEN

Q <= "00000000" ;

ELSIF Clock'EVENT AND Clock = '1' THEN

Q <= D ;

END IF ;

END PROCESS ;

END Behavior ;`

ECE 448 – FPGA and ASIC Design with VHDL


Slide22 l.jpg

N statement (<=) are outputs e.g.

N

Resetn

D

Q

Clock

regn

N-bit register with asynchronous reset

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY regn IS

GENERIC ( N : INTEGER := 16 ) ;

PORT ( D : IN STD_LOGIC_VECTOR(N-1 DOWNTO 0) ;

Resetn, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC_VECTOR(N-1 DOWNTO 0) ) ;

END regn ;

ARCHITECTURE Behavior OF regn IS

BEGIN

PROCESS ( Resetn, Clock )

BEGIN

IF Resetn = '0' THEN

Q <= (OTHERS => '0') ;

ELSIF Clock'EVENT AND Clock = '1' THEN

Q <= D ;

END IF ;

END PROCESS ;

END Behavior ;

ECE 448 – FPGA and ASIC Design with VHDL


Slide23 l.jpg

N statement (<=) are outputs e.g.

N

N-bit register with enable

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY regn IS

GENERIC ( N : INTEGER := 8 ) ;

PORT ( D : IN STD_LOGIC_VECTOR(N-1 DOWNTO 0) ;

Enable, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC_VECTOR(N-1 DOWNTO 0) ) ;

END regn ;

ARCHITECTURE Behavior OF regn IS

BEGIN

PROCESS (Clock)

BEGIN

IF (Clock'EVENT AND Clock = '1' ) THEN

IF Enable = '1' THEN

Q <= D ;

END IF ;

END IF;

END PROCESS ;

END Behavior ;

Enable

Q

D

Clock

regn

ECE 448 – FPGA and ASIC Design with VHDL


Slide24 l.jpg

Counters statement (<=) are outputs e.g.

ECE 448 – FPGA and ASIC Design with VHDL


Slide25 l.jpg

2 statement (<=) are outputs e.g.

Clear

Q

upcount

Clock

2-bit up-counter with synchronous reset

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

USE ieee.std_logic_unsigned.all ;

ENTITY upcount IS

PORT ( Clear, Clock : IN STD_LOGIC ;

Q : BUFFER STD_LOGIC_VECTOR(1 DOWNTO 0) ) ;

END upcount ;

ARCHITECTURE Behavior OF upcount IS

BEGIN

upcount: PROCESS ( Clock )

BEGIN

IF (Clock'EVENT AND Clock = '1') THEN

IF Clear = '1' THEN

Q <= "00" ;

ELSE

Q <= Q + “01” ;

END IF ;

END IF;

END PROCESS;

END Behavior ;

ECE 448 – FPGA and ASIC Design with VHDL


Slide26 l.jpg

Enable statement (<=) are outputs e.g.

4

Q

Clock

upcount

Resetn

4-bit up-counter with asynchronous reset (1)

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

USE ieee.std_logic_unsigned.all ;

ENTITY upcount IS

PORT ( Clock, Resetn, Enable : IN STD_LOGIC ;

Q : OUT STD_LOGIC_VECTOR (3 DOWNTO 0)) ;

END upcount ;

ECE 448 – FPGA and ASIC Design with VHDL


Slide27 l.jpg

Enable statement (<=) are outputs e.g.

4

Q

Clock

upcount

Resetn

4-bit up-counter with asynchronous reset (2)

ARCHITECTURE Behavior OF upcount IS

SIGNAL Count : STD_LOGIC_VECTOR (3 DOWNTO 0) ;

BEGIN

PROCESS ( Clock, Resetn )

BEGIN

IF Resetn = '0' THEN

Count <= "0000" ;

ELSIF (Clock'EVENT AND Clock = '1') THEN

IF Enable = '1' THEN

Count <= Count + 1 ;

END IF ;

END IF ;

END PROCESS ;

Q <= Count ;

END Behavior ;

ECE 448 – FPGA and ASIC Design with VHDL


Slide28 l.jpg

Shift Registers statement (<=) are outputs e.g.

ECE 448 – FPGA and ASIC Design with VHDL


Shift register l.jpg
Shift register statement (<=) are outputs e.g.

D

D

D

D

Q

Q

Q

Q

Q(1)

Q(0)

Q(2)

Q(3)

Sin

Clock

Enable

ECE 448 – FPGA and ASIC Design with VHDL


Shift register with parallel load l.jpg
Shift Register With Parallel Load statement (<=) are outputs e.g.

D(0)

D

D

D

D

Q

Q

Q

Q

Load

D(3)

D(1)

D(2)

Sin

Clock

Enable

Q(3)

Q(2)

Q(1)

Q(0)

ECE 448 – FPGA and ASIC Design with VHDL


Slide31 l.jpg

4 statement (<=) are outputs e.g.

4

Enable

D

Q

Load

Sin

shift4

Clock

4-bit shift register with parallel load (1)

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY shift4 IS

PORT ( D : IN STD_LOGIC_VECTOR(3 DOWNTO 0) ;

Enable : IN STD_LOGIC ;

Load : IN STD_LOGIC ;

Sin : IN STD_LOGIC ;

Clock : IN STD_LOGIC ;

Q : BUFFER STD_LOGIC_VECTOR(3 DOWNTO 0) ) ;

END shift4 ;

ECE 448 – FPGA and ASIC Design with VHDL


Slide32 l.jpg

4 statement (<=) are outputs e.g.

4

Enable

D

Q

Load

Sin

shift4

Clock

4-bit shift register with parallel load (2)

ARCHITECTURE Behavior_1 OF shift4 IS

BEGIN

PROCESS (Clock)

BEGIN

IF Clock'EVENT AND Clock = '1' THEN

IF Load = '1' THEN

Q <= D ;

ELSIF Enable = ‘1’ THEN

Q(0) <= Q(1) ;

Q(1) <= Q(2);

Q(2) <= Q(3) ;

Q(3) <= Sin;

END IF ;

END IF ;

END PROCESS ;

END Behavior_1 ;

ECE 448 – FPGA and ASIC Design with VHDL


Slide33 l.jpg

Enable statement (<=) are outputs e.g.

N

N

D

Q

Load

Sin

shiftn

Clock

N-bit shift register with parallel load (1)

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY shiftn IS

GENERIC ( N : INTEGER := 8 ) ;

PORT ( D : IN STD_LOGIC_VECTOR(N-1 DOWNTO 0) ;

Enable : IN STD_LOGIC ;

Load : IN STD_LOGIC ;

Sin : IN STD_LOGIC ;

Clock : IN STD_LOGIC ;

Q : BUFFER STD_LOGIC_VECTOR(N-1 DOWNTO 0) ) ;

END shiftn ;

ECE 448 – FPGA and ASIC Design with VHDL


Slide34 l.jpg

Enable statement (<=) are outputs e.g.

N

N

D

Q

Load

Sin

shiftn

Clock

N-bit shift register with parallel load (2)

ARCHITECTURE Behavior OF shiftn IS

BEGIN

PROCESS (Clock)

BEGIN

IF (Clock'EVENT AND Clock = '1' ) THEN

IF Load = '1' THEN

Q <= D ;

ELSIF Enable = ‘1’ THEN

Genbits: FOR i IN 0 TO N-2 LOOP

Q(i) <= Q(i+1) ;

END LOOP ;

Q(N-1) <= Sin ;

END IF;

END IF ;

END PROCESS ;

END Behavior ;

ECE 448 – FPGA and ASIC Design with VHDL


Slide35 l.jpg

Experiment 2 statement (<=) are outputs e.g.

Problem 1

Pseudo-Random Number Generator

ECE 448 – FPGA and ASIC Design with VHDL


Slide36 l.jpg

Linear Feedback Shift Register (LFSR) statement (<=) are outputs e.g.

Each stage = D flip-flop

 L, C(D) 

Length

Connection polynomial, C(D)

C(D) = 1 + c1D + c2D2 + . . . + cLDL

ECE 448 – FPGA and ASIC Design with VHDL


Slide37 l.jpg

S statement (<=) are outputs e.g. j-1

Sj-2

Sj-(L-1)

Sj-L

Initial state

[sL-1, sL-2, . . . , s1, s0]

LSFR recursion:

sj = c1sj-1 c2sj-2 . . .  cL-1sj-(L-1) cLsj-L

for j  L

ECE 448 – FPGA and ASIC Design with VHDL


Slide38 l.jpg

Example of LFSR statement (<=) are outputs e.g.

 4, 1+D+D4

Length

Connection polynomial, C(D)

C(D) = 1 + 1D + 0D2 + 0D3 +1D4

c1=1

c2=0

c4=1

c3=0

ECE 448 – FPGA and ASIC Design with VHDL


Slide39 l.jpg

LFSR State Sequence statement (<=) are outputs e.g.

s4

s3

s2

s1

s0

s4 = c1s3c2s2 c3s1  c4s0 = s3 s0

ECE 448 – FPGA and ASIC Design with VHDL


Slide40 l.jpg

seed statement (<=) are outputs e.g.

coeff

4

4

load_coeff

init_run

PRNG

strobe

ext_clk

strobe_divclk

7

current_state

ECE 448 – FPGA and ASIC Design with VHDL


Slide41 l.jpg

Constants statement (<=) are outputs e.g.

ECE 448 – FPGA and ASIC Design with VHDL


Constants l.jpg
Constants statement (<=) are outputs e.g.

Syntax:

CONSTANT name : type := value;

Examples:

CONSTANT init_value : STD_LOGIC_VECTOR(3 downto 0) := "0100";

CONSTANT ANDA_EXT : STD_LOGIC_VECTOR(7 downto 0) := X"B4";

CONSTANT counter_width : INTEGER := 16;

CONSTANT buffer_address : INTEGER := 16#FFFE#;

CONSTANT clk_period : TIME := 20 ns;

CONSTANT strobe_period : TIME := 333.333 ms;

ECE 448 – FPGA and ASIC Design with VHDL


Constants features l.jpg
Constants - features statement (<=) are outputs e.g.

Constantscan be declared in a

PACKAGE, ENTITY, ARCHITECTURE

When declared in a PACKAGE, the constant

is truly global, for the package can be used

in several entities.

When declared in an ARCHITECTURE, the

constant is local, i.e., it is visible only within this architecture.

When declared in an ENTITY declaration, the constant

can be used in all architectures associated with this entity.

ECE 448 – FPGA and ASIC Design with VHDL


Slide44 l.jpg

Specifying time in VHDL statement (<=) are outputs e.g.

ECE 448 – FPGA and ASIC Design with VHDL


Physical data types l.jpg
Physical data types statement (<=) are outputs e.g.

Types representing physical quantities, such as time, voltage, capacitance, etc. are referred in VHDL as physical data types.

TIME is the only predefined physical data type.

Value of the physical data type is called a physical literal.

ECE 448 – FPGA and ASIC Design with VHDL


Time values physical literals examples l.jpg
Time values (physical literals) - Examples statement (<=) are outputs e.g.

7 ns

1 min

min

10.65 us

10.65 fs

Numeric value

Space

Unit of time

(dimension)

ECE 448 – FPGA and ASIC Design with VHDL


Time values l.jpg
TIME values statement (<=) are outputs e.g.

Numeric value can be an integer or

a floating point number.

Numeric value is optional. If not given, 1 is

implied.

Numeric value and dimension MUST be

separated by a space.

ECE 448 – FPGA and ASIC Design with VHDL


Units of time l.jpg
Units of time statement (<=) are outputs e.g.

Unit Definition

Base Unit

fs femtoseconds (10-15 seconds)

Derived Units

ps picoseconds (10-12 seconds)

ns nanoseconds (10-9 seconds)

us microseconds (10-6 seconds)

ms miliseconds (10-3 seconds)

sec seconds

min minutes (60 seconds)

hr hours (3600 seconds)

ECE 448 – FPGA and ASIC Design with VHDL


Slide49 l.jpg

Asserts & Reports statement (<=) are outputs e.g.

ECE 448 – FPGA and ASIC Design with VHDL


Assert l.jpg
Assert statement (<=) are outputs e.g.

Assert is a non-synthesizable statement

whose purpose is to write out messages

on the screen when problems are found

during simulation.

Depending on the severity of the problem,

The simulator is instructed to continue

simulation or halt.

ECE 448 – FPGA and ASIC Design with VHDL


Assert syntax l.jpg
Assert - syntax statement (<=) are outputs e.g.

ASSERT condition

[REPORT "message"

[SEVERITY severity_level ];

The message is written when the condition

is FALSE.

Severity_level can be:

Note, Warning, Error (default), or Failure.

ECE 448 – FPGA and ASIC Design with VHDL


Assert examples l.jpg
Assert - Examples statement (<=) are outputs e.g.

assert initial_value <= max_value

report "initial value too large"

severity error;

assert packet_length /= 0

report "empty network packet received"

severity warning;

assert false

report "Initialization complete"

severity „note”;

ECE 448 – FPGA and ASIC Design with VHDL


Report syntax l.jpg
Report - syntax statement (<=) are outputs e.g.

REPORT "message"

[SEVERITY severity_level ];

The message is always written.

Severity_level can be:

Note (default), Warning, Error, or Failure.

ECE 448 – FPGA and ASIC Design with VHDL


Report examples l.jpg
Report - Examples statement (<=) are outputs e.g.

report "Initialization complete";

report "Current time = "& time'image(now);

report "Incorrect branch" severity error;

ECE 448 – FPGA and ASIC Design with VHDL


Slide55 l.jpg

Testbenches statement (<=) are outputs e.g.

ECE 448 – FPGA and ASIC Design with VHDL


Generating selected values of one input l.jpg
Generating selected values of one input statement (<=) are outputs e.g.

  • SIGNAL test_vector : STD_LOGIC_VECTOR(2 downto 0);

  • BEGIN

  • .......

    • testing: PROCESS

    • BEGIN

    • test_vector <= "000";

    • WAIT FOR 10 ns;

    • test_vector <= "001";

    • WAIT FOR 10 ns;

    • test_vector <= "010";

    • WAIT FOR 10 ns;

    • test_vector <= "011";

    • WAIT FOR 10 ns;

    • test_vector <= "100";

    • WAIT FOR 10 ns;

    • END PROCESS;

  • ........

  • END behavioral;

  • ECE 448 – FPGA and ASIC Design with VHDL


    Generating all values of one input l.jpg
    Generating all values of one input statement (<=) are outputs e.g.

    SIGNAL test_vector : STD_LOGIC_VECTOR(3 downto 0):="0000";

    BEGIN

    .......

    testing: PROCESS

    BEGIN

    WAIT FOR 10 ns;

    test_vector <= test_vector + 1;

    end process TESTING;

    ........

    END behavioral;

    ECE 448 – FPGA and ASIC Design with VHDL


    Slide58 l.jpg

    Generating all possible values of two inputs statement (<=) are outputs e.g.

    • SIGNAL test_ab : STD_LOGIC_VECTOR(1 downto 0);

    • SIGNAL test_sel : STD_LOGIC_VECTOR(1 downto 0);

    • BEGIN

    • .......

      • double_loop: PROCESS

      • BEGIN

      • test_ab <="00";

      • test_sel <="00";

      • for I in 0 to 3 loop

      • for J in 0 to 3 loop

      • wait for 10 ns;

      • test_ab <= test_ab + 1;

      • end loop;

      • test_sel <= test_sel + 1;

      • end loop;

      • END PROCESS;

  • ........

  • END behavioral;

  • ECE 448 – FPGA and ASIC Design with VHDL


    Generating periodical signals such as clocks l.jpg
    Generating periodical signals, such as clocks statement (<=) are outputs e.g.

    CONSTANT clk1_period : TIME := 20 ns;

    CONSTANT clk2_period : TIME := 200 ns;

    SIGNAL clk1 : STD_LOGIC;

    SIGNAL clk2 : STD_LOGIC := ‘0’;

    BEGIN

    .......

    clk1_generator: PROCESS

    clk1 <= ‘0’;

    WAIT FOR clk1_period/2;

    clk1 <= ‘1’;

    WAIT FOR clk1_period/2;

    END PROCESS;

    clk2 <= not clk2after clk2_period/2;

    .......

    END behavioral;

    ECE 448 – FPGA and ASIC Design with VHDL


    Generating one time signals such as resets l.jpg
    Generating one-time signals, such as resets statement (<=) are outputs e.g.

    CONSTANT reset1_width : TIME := 100 ns;

    CONSTANT reset2_width : TIME := 150 ns;

    SIGNAL reset1 : STD_LOGIC;

    SIGNAL reset2 : STD_LOGIC := ‘1’;

    BEGIN

    .......

    reset1_generator: PROCESS

    reset1 <= ‘1’;

    WAIT FOR reset_width;

    reset1 <= ‘0’;

    WAIT;

    END PROCESS;

    reset2_generator: PROCESS

    WAIT FOR reset_width;

    reset2 <= ‘0’;

    WAIT;

    END PROCESS;

    .......

    END behavioral;

    ECE 448 – FPGA and ASIC Design with VHDL


    Typical error l.jpg
    Typical error statement (<=) are outputs e.g.

    SIGNAL test_vector : STD_LOGIC_VECTOR(2 downto 0);

    SIGNAL reset : STD_LOGIC;

    BEGIN

    .......

    generator1: PROCESS

    reset <= ‘1’;

    WAIT FOR 100 ns

    reset <= ‘0’;

    test_vector <="000";

    WAIT;

    END PROCESS;

    generator2: PROCESS

    WAIT FOR 200 ns

    test_vector <="001";

    WAIT FOR 600 ns

    test_vector <="011";

    END PROCESS;

    .......

    END behavioral;

    ECE 448 – FPGA and ASIC Design with VHDL


    Wait for vs wait l.jpg
    Wait for statement (<=) are outputs e.g. vs. Wait

    0

    0

    1

    1

    2

    2

    3

    3

    Wait for: waveform will keep repeating itself forever

    Wait: waveform will keep its state after the last wait instruction.

    ECE 448 – FPGA and ASIC Design with VHDL


    Generating reports in the message window l.jpg
    Generating reports in the message window statement (<=) are outputs e.g.

    reports: process(clk_trigger) begin

    if (clk_trigger = '0' and clk_trigger'EVENT) then

    case segments is

    when seg_0 => report time'image(now) & ": 0 is displayed" ;

    when seg_1 => report time'image(now) & ": 1 is displayed" ;

    when seg_2 => report time'image(now) & ": 2 is displayed" ;

    when seg_3 => report time'image(now) & ": 3 is displayed" ;

    when seg_4 => report time'image(now) & ": 4 is displayed" ;

    when seg_5=> report time'image(now) & ": 5 is displayed" ;

    when seg_6 => report time'image(now) & ": 6 is displayed" ;

    when seg_7 => report time'image(now) & ": 7 is displayed" ;

    when seg_8 => report time'image(now) & ": 8 is displayed" ;

    when seg_9 => report time'image(now) & ": 9 is displayed" ;

    end case;

    end if;

    end process;

    ECE 448 – FPGA and ASIC Design with VHDL


    Anatomy of a process64 l.jpg
    Anatomy of a Process statement (<=) are outputs e.g.

    [label:] process[(sensitivity list)]

    [declaration part]

    begin

    statement part

    end process;

    ECE 448 – FPGA and ASIC Design with VHDL


    Sequential statements 1 l.jpg
    Sequential Statements (1) statement (<=) are outputs e.g.

    • If statement

    • else and elsifare optional

    ifboolean expression then

    statements

    elsif boolean expression then

    statements

    else boolean expression then

    statements

    end if;

    ECE 448 – FPGA and ASIC Design with VHDL


    Sequential statements 2 l.jpg
    Sequential Statements (2) statement (<=) are outputs e.g.

    • Case statement

    • Choices have to cover all possible values of the condition

      • Use others to specify all remaining cases

    casecondition is

    when choice_1 =>

    statements

    when choice_2 =>

    statements

    when others =>

    statements

    end case;

    ECE 448 – FPGA and ASIC Design with VHDL


    Sequential statements 3 l.jpg
    Sequential Statements (3) statement (<=) are outputs e.g.

    • Loop Statement

    • Repeats a section of VHDL code

    fori in range loop

    statements

    end loop;

    ECE 448 – FPGA and ASIC Design with VHDL


    ad
