  1. 香水打火機應用TRIZ創新設計 指導老師:翁明珠 老師 四企二B 第十五組 組員: 4970L071 林鈺雯 4970L045 王思婉 4970L064 丁妤芳 4970L003 何思穎

  2. 目錄 • LOGO與標語介紹 • 問題描述 • Function-Attribute 9/12 Windows • Identified Opportunities/Projects • Root Contradiction Analysis • CM & IP:矛盾矩陣與發明原則

  3. 空氣清新打火機 • 提神打火機 • 噴式防蚊打火機 • 口氣芳香打火機 • 模擬香水打火機構造圖 • 相關專利資料 • 工作分配表

  4. LOGO: P L & perfume & lighter 香氣增加你的魅力!

  5. 問題描述:6W1H1G

  6. Past Present Future Super system System Neg/Alt- System Function-Attribute 9/12 Windows(by life cle): Sub- system Oppr. Identified: 香水打火機、口氣芳香劑打火機、空氣清新劑打火機、提神打火機、防蚊打火機、消炎止傷打火機...等。

  7. Identified Opportunities/Projects

  8. Root Contradiction AnalysisSubject: 香水打火機 Why = What causes it? What stopping us? Contradictions:26.物質數量↑35.適應性↑31.物料產生的有害因素↓14.強度↑

  9. CM & IP:矛盾矩陣與發明原則 1.分割 2.分離/抽出 9.預先的反作用 10.預先作用 14.曲度 15.動態性 22.將有害變有益 27.拋棄式 29.使用氣體或液體 32.改變顏色 35.參數改變 40.複合材料 Subject: 享用美食、抽菸造成衣物和空氣有異味

  10. 空氣清新打火機 + +

  11. + +

  12. +

  13. 模擬香水打火機構造圖

  14. 我們找到相關的專利資料…

  15. 工作分配表 資料蒐集:林鈺雯、王思婉、丁妤芳、何思穎 PPT製作:丁妤芳、林鈺雯、王思婉 繪圖:林鈺雯
