netcomm nct1020 micro nct1000 mini ip dslam june 2007
NetComm NCT1020 Micro

NCT1000 Mini

IP DSLAM

June 2007

NetComm IPDSLAM
slide2

System Management Software

  • Connection, Installation & Login
  • AMCU GUI
  • AAT24B GUI
  • AESG GUI
slide3

System Management Software

Connection & Installation

MCID

Management Craft Interface Device

  • The MCID software provides a Graphical User Interface (GUI), which can be used to configure, maintain, and operate a NCT-1000/1020 across a LAN. The MCID is able to control all the cards.
  • Install the MCID management software by following the prompts.
  • A shortcut icon of the NCT-1000/1020 MCID will be placed on your desktop. Click the icon to start the CID.

connection

Shortcut icon of the

NCT-1000/1020

MCID

slide4

System Management Software

DSL Concentrator Login

  • 1.Double click the MCID icon on the desktop to display the login menu.
  • Enter the following information:
  • IP Address (default = 172.16.7.100)
  • Get Community (default = public)
  • Set Community (default = private)

2. Click Start CID to enter the login screen of the device.

Enter

Username (default = root)

Password (default = root)

slide5

System Management Software

MCID Main Menu

After login the screen will display as below. The figure below has labels for the location of the ACO button, shelf faceplate, and directory tree. The faceplatedisplays the installed units and their LED status.

Shelf faceplate

ACO Alarm

Directory Tree

slide6

System Management Software

AMCU GUI

  • To access the AMCU main control unit, select AMCU from the directory tree or click AMCU from the faceplate.
  • Contents
  • System
  • >Configuration
  • >Administration
  • >VLAN configuration
  • >VLAN PVID
  • >Maintenance
  • >System Software Upgrade
  • AMCU Configuration
  • Current Alarm
  • History Alarm
  • Alarm Event
  • Exiting the AMCU
slide7

System Management Software

AAT24B GUI

  • Contents
  • Configuration
  • >Port Information
  • >Bath Configuration
  • >Version
  • >List Slot Configuration
  • >Port Configuration
  • Status
  • Maintenance
  • Performance
  • Statistics
  • Graphical Statics
  • History Status
  • Exit
  • - The AAT24A ADSL 1 card has similar GUI -
slide8

System Management Software

AESG GUI

  • Contents
  • Configuration:
  • version, Card Configuration, Port Configuration
  • Spanning Tree:
  • Spanning tree function configuration on Up, Down, Giga Port 1 and Giga Port 2.
  • Exiting the AESG
slide10

Firmware Upgrade

NCT1000/NCT1020 Firmware Upgrade

Important rules:

1. Keep the TFTP sever and the MCID management softwarerunning for performing firmware upgrade.

2. The firmware upgrade sequence MUSTbe: AAT24A first, AES-G card 2nd and then AMCU the last.

3. For downgrade, you need to use "chkfile 0" to disable check file function by Telneting into the IP DSLAM.

slide11

Firmware Upgrade

NCT1000 / NCT1020 Firmware List

  • AAT24A ADSL1 card firmware V2.03: Aat24A_V2.03.crz
  • AAT24B ADSL2+ card firmware V1.10:
  • Aat24b_V110.crz
  • 3. AES-G Ethernet uplink card firmware V3.3: AesgAP_v33.crz
  • 4. AMCU Management card firmware V9.17N: Amcu-9.17N.crz
  • MCID Management Software v1.39N1:
  • IP-DSLAM-MCID-V139N1
slide12

Firmware Upgrade

Step 1:

Network Setup for NCT1000 / NCT1020 Firmware Upgrade

Management PC IP Address:

172.16.7.10

Management PC IP Address:

172.16.7.10

IP DSLAM IP Address: 172.16.7.100

IP DSLAM IP Address: 172.16.7.100

slide13

Firmware Upgrade

Step 3:

Set the IP address of the PC to be in the same subnet as that in the IP DSLAM. For example

NCT1000/NCT1020 default IP address: 172.16.7.100/24

Management PC IP address:

172.16.7.10/24

Step 2:

Set up a TFTP server on the MCID management PC. For example

Solar Winds-TFTP-Server

slide14

Firmware Upgrade

Step 4: Upgrade the AAT24B ADSL2+ Card

Login to “DSL Concentrator” MCID management software.

Go to AMCU GUI

>System

> SW Upgrade

> Select

“Card Type” = AAT24A

“File Type” = AP

“TFTP Server IP Address” = 172.17.1.199

(This is the IP Address that is set to the management PC.)

“Download File name” = Aat24aAP_v203.crz (Browse for the firmware file for AAT24A ADSL Line Card.)

Then Click Transmit

slide15

Firmware Upgrade

Step 4: Upgrade the AAT24A ADSL Line Card continued…

The firmware upgrade for AAT24A will take a few minutes. The different status during FW Upgrade are as follows:

slide16

Firmware Upgrade

For downgrade, you need to use "chkfile 0" to disable check file function by Telneting into the IP DSLAM.

slide17

Firmware Upgrade

Step 5: Upgrade/Downgrade the AES-G Ethernet uplink Card

Go to AMCU GUI

>System

> SW Upgrade

> Select

“Card Type” = AESG

“File Type” = AP

“TFTP Server IP Address” = 172.17.1.199

(This is the IP Address that is set to the management PC.)

“Download File name” = AesgAP_v33.crz

(Browse for the firmware file for AESG Uplink Card.)

Then Click Transmit

slide18

Firmware Upgrade

Step 5: Upgrade the AESG Ethernet uplink Card continued…

The firmware upgrade for AESG will take a few minutes. The different status during FW Upgrade are as follows:

slide19

Firmware Upgrade

Step 6: Upgrade the AMCU Management Card

Go to AMCU GUI

>System

> SW Upgrade

> Select

“Card Type” = AMCU

“File Type” = AP

“TFTP Server IP Address” = 172.17.1.199

(This is the IP Address that is set to the management PC.)

“Download File name” =

Amcu-9.17N.crz

(Browse for the firmware file for AESG Uplink Card.)

Then Click Transmit

slide20

Firmware Upgrade

Step 6: Upgrade the AMCU management card continued…

The different status during FW Upgrade are as follows:

RESET AMCU Card

slide21

Firmware Upgrade

Step 7: Reboot the system to take effect on the new firmware for all cards.

Go to AMCU > Maintenance > Reset System through MCID

The GUI pop-up message are as follows:

IP DSLAM RESTART now takes place.

LED Sequence: All off -> Flashed yellow/orange then all red and LEDs on AAT24B self checking one by one.

Estimated time for System Reset is approximately 2 minutes.

slide23

Remove MCID V1.33

Step 8: In order to control all the features in the latest firmware AAT24A V2.03 or Aat24B V1.10, AESG V3.3, AMCU V9.17N, the MCID V1.39N1 must be used.

slide24

Installed MCID V1.39N1

Step 9: Installed MCID V1.39N1 IPDSLAM Management Utility to management the NCT1020 IP DSLAM.
