Presentation Transcript


Binary lesson 4 slash notation l.jpg

Binary Lesson 4Slash Notation


A single ipv6 address l.jpg

A Single IPv6 Address

fe80:0000:0000:0000:462a:60ff:fef6:0278

8 fields, each containing 16 bits

Each field has 4 hexadecimal characters, representing 4 bits each

fe80 = 1111 1110 1000 0000

462a = 0100 0110 0010 1010


A range of ipv6 address l.jpg

A Range of IPv6 Address

fe80::/64

  • The number after the slash is how many bits are fixed in the address range

  • All the remaining bits are allowed to vary

  • This range contains these addresses:

    fe80:0000:0000:0000:0000:0000:0000:0000

    fe80:0000:0000:0000:0000:0000:0000:0001

    fe80:0000:0000:0000:ffff:0000:0000:0000

    fe80:0000:0000:0000:ffff:ffff:ffff:ffff

    ---- ---- ---- ----

    64 bits


A range of ipv6 address4 l.jpg

A Range of IPv6 Address

fe80::/16

The number after the slash is how many bits are fixed in the address range

All the remaining bits are allowed to vary

This range contains these addresses:

fe80:0000:0000:0000:0000:0000:0000:0000

fe80:0000:0000:0000:0000:0000:0000:0001

fe80:ffff:0000:0000:0000:0000:0000:0000

fe80:ffff:ffff:ffff:ffff:ffff:ffff:ffff

----

16 bits


A range of ipv6 address5 l.jpg

A Range of IPv6 Address

fe80::/8

The number after the slash is how many bits are fixed in the address range

All the remaining bits are allowed to vary

This range contains these addresses:

fe80:0000:0000:0000:0000:0000:0000:0000

fe80:ffff:ffff:ffff:ffff:ffff:ffff:ffff

fe8f:ffff:ffff:ffff:ffff:ffff:ffff:ffff

feff:ffff:ffff:ffff:ffff:ffff:ffff:ffff

--

8 bits


A single ipv6 address6 l.jpg

A Single IPv6 Address

  • fe80::462a:60ff:fef6:0278/128

    • The /128 means all 128 bits are fixed

      fe80:0000:0000:0000:462a:60ff:fef6:0278

      ---- ---- ---- ---- ---- ---- ---- ----

      128 bits


The unspecified ipv6 address l.jpg

The Unspecified IPv6 Address

  • ::/0

    • The /0 means no bits are fixed

    • All 128 bits can vary

  • This range includes all addresses, including

    0000:0000:0000:0000:0000:0000:0000:0000

    ffff:ffff:ffff:ffff:ffff:ffff:ffff:ffff

    0 bits


Binary iclicker questions l.jpg

Binary iClicker Questions


Which address is not included in this range 2620 64 l.jpg

Which address is not included in this range?2620::/64

2620::FFFF

2620::FFFF:FFFF:FFFF

2620::FFFF:FFFF:FFFF:FFFF

2620::FFFF:FFFF:FFFF:FFFF:FFFF

More than one of the above


Which address is not included in this range 2620 32 l.jpg

Which address is not included in this range?2620::/32

2620::F:F:F:F

2620:0:0:1::FFFF:FFFF:FFFF

2620:1:0:0:F:F::1

262F::FFFF:FFFF:FFFF:FFFF:FFFF

More than one of the above


Which address is not included in this range fc00 16 l.jpg

Which address is not included in this range?FC00::/16

FC00::1:1:1:1

FC00::1:1:1:1:1:1

FC00:F:F:F:1:1:1:1

FC0F::1

More than one of the above


Which address is not included in this range ff02 96 l.jpg

Which address is not included in this range?FF02::/96

FF02::F:F:F

FF02::F:F

FF02::FFFF:FFFF

FF02::F

More than one of the above


Which address is not included in this range 2000 4 l.jpg

Which address is not included in this range?2000::/4

2000::

20FF::

2FFF::

3000::

More than one of the above


Which address is not included in this range 2620 1 b 48 l.jpg

Which address is not included in this range?2620:1:B::/48

2620::1

2620:1:B::F:F:F:F

2620:1:B::F:F:F:F:F

2620:1:C::F:F:F:F

More than one of the above
