Experimenting Event Notification

in

Web Service Composition

Daniele Strollo (IMT Lucca)

Roberto Guanciale (IMT Lucca)

Dagstuhl Feb 2007


Car repair specification saga l.jpg
Car repair specification: SAGA

<<saga>>

CarRepair

ChargeCreditCard

RevokeCharge

OrderGarage

CancelGarage

<<saga>>

CarRental

OrderTowTruck

OrderRentalCar

RedirectRentalCar

CancelTowTruck


Car repair specification saga3 l.jpg
Car repair specification: SAGA

<<saga>>

CarRepair

ChargeCreditCard

RevokeCharge

OrderGarage

CancelGarage

<<saga>>

CarRental

OrderTowTruck

OrderRentalCar

RedirectRentalCar

CancelTowTruck


Car repair specification saga4 l.jpg
Car repair specification: SAGA

<<saga>>

CarRepair

ChargeCreditCard

RevokeCharge

OrderGarage

CancelGarage

<<saga>>

CarRental

OrderTowTruck

OrderRentalCar

RedirectRentalCar

CancelTowTruck


Car repair specification saga5 l.jpg
Car repair specification: SAGA

<<saga>>

CarRepair

ChargeCreditCard

RevokeCharge

OrderGarage

CancelGarage

<<saga>>

CarRental

OrderTowTruck

OrderRentalCar

RedirectRentalCar

CancelTowTruck


Car repair specification saga6 l.jpg
Car repair specification: SAGA

AtomicComponent credit =

factory.createAtomicComponent(

creditUrl,

new ChargeCreditCard(),

new RevokeCredit()

);

ChargeCreditCard

RevokeCharge


Car repair specification saga7 l.jpg
Car repair specification: SAGA

AtomicComponent garage =

factory.createAtomicComponent(

garageUrl,

new OrderGarage(),

new CancelGarage()

);

.

.

.

ChargeCreditCard

RevokeCharge

OrderGarage

CancelGarage

OrderTowTruck

OrderRentalCar

RedirectRentalCar

CancelTowTruck


Car repair specification saga8 l.jpg
Car repair specification: SAGA

Saga carRental = factory.createSaga(rentalUrl);

carRental.addInternalComponent(orderRentalUrl);

ChargeCreditCard

RevokeCharge

OrderGarage

CancelGarage

<<saga>>

CarRental

OrderTowTruck

OrderRentalCar

RedirectRentalCar

CancelTowTruck


Car repair specification saga9 l.jpg
Car repair specification: SAGA

TransactionalParallel par =

factory.createParallel(parallelUrl);

par.addInternalComponent(truckUrl);

par.addInternalComponent(rentalUrl);

ChargeCreditCard

RevokeCharge

OrderGarage

CancelGarage

<<saga>>

CarRental

OrderTowTruck

OrderRentalCar

RedirectRentalCar

CancelTowTruck


Car repair specification saga10 l.jpg
Car repair specification: SAGA

<<saga>>

CarRepair

ChargeCreditCard

RevokeCharge

OrderGarage

CancelGarage

<<saga>>

CarRental

OrderTowTruck

OrderRentalCar

RedirectRentalCar

CancelTowTruck

Saga saga = factory.createSaga(sagaUrl);

TransactionalSequence seq =

factory.createSequence(sequenceUrl);

seq.addInternalComponent(creditUrl);

seq.addInternalComponent(garageUrl);

seq.addInternalComponent(parallelUrl);

saga.addInternalComponent(sequenceUrl);


The lower layer l.jpg
The lower layer

Signal Calculus

(SC)

  • Middleware: collection of Java APIs implementing the SC primitives.

    • lowerlayer for describing coordination logics on services

    • Specialized to implement Long Running Transactions

Programming Model

  • Event Notification paradigm

    • common programming paradigm to model service coordination

    • distribute the coordination tasks among involved services (choreography)

    • dynamic interface publication

    • dynamic topology of service connections

  • Process Calculus with asynchronouscommunication facilities

  • Event topics to describe coordinationpolicies

Java Signal Core

Layer

(JSCL)



The main concepts components l.jpg
The main concepts: components

R

a

F

  • Is uniquely identified by a name.

  • A component:

Component

Name


The main concepts components14 l.jpg
The main concepts: components

R

a

F

  • Declares event topics for which it is interested to have notifications

    • The reactions define a binding among signals of a well defined topic to an handling task to execute internally upon a new notification receptionv

  • A component:

  • Is uniquely identified by a name.

Reaction


The main concepts components15 l.jpg
The main concepts: components

R

a

F

  • Declares event topics for which it is interested to have notifications

    • The reactions define a binding among signals of a well defined topic to an handling task to execute internally upon a new notification reception

  • A component:

  • Is uniquely identified by a name.

  • Defines its outgoing connections through the “Flow” structureF.

    • The connections among components are realized through signal links, which are tuples of the form (topic, emitter, handler).

    • F stores all the signal links having a as emitter.

Flow


The main concepts signal emission l.jpg
The main concepts: signal emission

R

a

F

  • Signal Calculus Primitives:

  • Signal emission

    • notifies the occurrence of an event

    • events are classified into schemata identified by their name 1, 2

    • signals are uniquely identified by their name s

s:


The main concepts reaction update l.jpg
The main concepts: reaction update

R

a

B

F

  • Signal Calculus Primitives:

  • Signal emission

  • Reaction Update

    • adds a new reaction to the component interface

    • checks the well-formeness of the resulting reaction

    • defines the behavior “B” to activate at the reception of signals of schema , and the variable binding

+


The main concepts flow update l.jpg
The main concepts: flow update

R

a

F

b

  • Signal Calculus Primitives:

  • Signal emission

  • Reaction Update

  • Flow Update

    • adds a new outgoing connections to the component

    • defines the set of component names to which deliver signals of schema 

    • checks the well-formeness of the resulting flow


The main concepts networks l.jpg
The main concepts: networks

  • Signal Calculus Primitives:

  • Signal emission

  • Reaction Update

  • Flow Update

  • Network

    • describes the component distribution

    • carries envelopes containing signals exchanged among components

s:

Signal envelop

Reaction enabled



Jscl architectural overview l.jpg
JSCL – Architectural overview

Inter-Object

Communication

Layers

[email protected]


Iocl primitives l.jpg
IOCL primitives

  • Each IOCL implements:

    • the data serialization (e.g. SOAP message envelops for WSs, etc.) and the deployment phase (e.g. stub generation, dynamic proxy binding, etc.).

    • Moreover each IOCL plugin defines the way components are identified by extending the basic interface ComponentAddress.

iocl instantiation

IOCLPluginLoader loader =

new IOCLPluginLoader(

new IOCLAddress ("jscl.core.IOCL.XSoap.IOCLImpl"));

IOCLPluginI iocl = loader.getIOCLInstance();

iocl.startup(ioclPort);


Iocl primitives23 l.jpg
IOCL primitives

  • Each IOCL implements:

    • the data serialization (e.g. SOAP message envelops for WSs, etc.) and the deployment phase (e.g. stub generation, dynamic proxy binding, etc.).

    • Moreover each IOCL plugin defines the way components are identified by extending the basic interface ComponentAddress.

Component creation

// Instantiate a component

address = new ServiceAddress ("http://jscl.org:10190/services/Hotel");

component = iocl.createComponent(address);

// Publication

iocl.registerComponent(address, component);


Iocl primitives24 l.jpg
IOCL primitives

  • Each IOCL implements:

    • the data serialization (e.g. SOAP message envelops for WSs, etc.) and the deployment phase (e.g. stub generation, dynamic proxy binding, etc.).

    • Moreover each IOCL plugin defines the way components are identified by extending the basic interface ComponentAddress.

Flow update

iocl.createLink(1001, HotelAddress, CarAddress, null);


Jscl primitives l.jpg
JSCL primitives

  • Each JSCL component can:

    • Declare its reactions

      • The handling task implements the virtual method

        • handleSignal (Signal signal)

Reaction update

component.addReaction (new Reaction (sigT, handlingTask));


Jscl primitives26 l.jpg
JSCL primitives

  • Each JSCL component can:

    • Declare its reactions

      • The handling task implements the virtual method

        • handleSignal (Signal signal)

    • Raise an event

Signal emission

component.emitSignal (new Signal (sigT, data));


Slide27 l.jpg

Part II

How to design JSCL components in Eclipse




Implementation in jscl l.jpg
Implementation in JSCL

Inv

Inv

Rb

  • JTWS ([email protected])

  • Transactional composition of WSs.

  • Fixed set of Signal Schemata:

    • Well defined semantics of components

    • Structural composition (parallel and sequential)

A

Successful execution of A

Unsuccessful execution of A

Executes main activity A

B

Atomic Component definition

AtomicComponent (ComponentAddress addr, AtomicTask A, AtomicTask B)

Request for abort.

Executes B.

Compensation successful executed

Compensation failure


Implementation in jscl31 l.jpg
Implementation in JSCL

Rb

Rb

Exc

  • JTWS ([email protected])

  • Transactional composition of WSs.

  • Fixed set of Signal Schemata:

    • Well defined semantics of components

    • Structural composition (parallel and sequential)

A

B

Compensation successful executed

Request for abort.

Executes B.

Compensation failure

Atomic Component definition

AtomicComponent (ComponentAddress addr, AtomicTask A, AtomicTask B)


Sequence l.jpg
sequence

Inv

P

Q

Sequence

sequence.addInternalComponent (AtomicComponent comp)

In

Out

oCt

iCt

oRb

iRb

oEx

iEx


Sequence33 l.jpg
sequence

Inv

P

Q

In

Out

A

oCt

iCt

oRb

iRb

oEx

iEx


Sequence34 l.jpg
sequence

Inv

P

Q

In

Out

A

oCt

iCt

oRb

iRb

oEx

iEx


Sequence35 l.jpg
sequence

Inv

P

Q

In

Out

oCt

iCt

oRb

iRb

oEx

iEx


Sequence36 l.jpg
sequence

P

Q

Rb

In

Out

oCt

iCt

B

oRb

iRb

oEx

iEx


Sequence37 l.jpg
sequence

P

Q

Rb

In

Out

oCt

iCt

B

oRb

iRb

oEx

iEx


Sequence38 l.jpg
sequence

P

Q

Rb

In

Out

oCt

iCt

oRb

iRb

oEx

iEx


Parallel l.jpg
parallel

In

Out

Inv

Inv

oCt

iCt

oRb

iRb

oEx

iEx

Par (P, Q) ´ P|Q

Dispatcher

P

Q

Collector

Status = (-,-)


Parallel40 l.jpg
parallel

In

Out

Inv

oCt

iCt

oRb

iRb

oEx

iEx

Dispatcher

A

P

A

Q

Collector

Status = (---,---)


Parallel41 l.jpg
parallel

In

Out

Inv

oCt

iCt

oRb

iRb

oEx

iEx

Dispatcher

A

P

A

Q

Collector

Status = (Inv,---)


Parallel42 l.jpg
parallel

In

Out

Inv

oCt

iCt

oRb

iRb

oEx

iEx

Dispatcher

A

P

A

Q

Collector

Status = (Inv,Inv)


Slide43 l.jpg

Part III

Concluding remarks


Jscl sc concluding remarks l.jpg
JSCL/SC: concluding remarks

  • Main features:

    • Basic framework for programming/modeling coordination.

    • Abstraction from the networkoverlay

    • Logicalports permit a simple design of the flow diagrams.

    • The connections (and interfaces) can be dinamically modified.

    • Session management

    • Nocentralization

    • BPEL orchestrations can be mapped and executed in SC/JSCL (straighforward coding)


Future works l.jpg
Future works

  • JSCL and SC programming model

    • UML front-end to design SOA

    • Theoretical based verification tool

    • SC:

      • Dynamic type system to model:

        • Choreographies

        • SLA

  • Programming environment

    • IOCL plugins based on model transformation

    • Eclipse plugin extensions:

      • Nested Orchestrations in order to reuse services in several diagrams.

      • Automatic deploy of the services

      • Debugger and profiler integration



ad
