  1. Radiotherapy Department Arif Raza

  2. Introduction • Clinical speciality for treatment of cancer • Tissue destroying procedure • Use of ionizing radiation • Single or combined with other therapy • Size of dept depends upon types of services and sophistication of equipments

  3. Introduction • Cobalt unit – used for deep radiation therapy • Linear accelerator – wide range of oncology cases • Simulator – set telegraphy field

  4. Treatment steps • Initial evaluation • Treatment plan • Application • TPS for evaluation and plan

  5. Brachytherapy • Brachy means short distance • Localized, precise and high-tech radiation therapy • Radio-active source is placed in or near the tumour • Increase cure rates and minimum side effects • Radioactive cobalt, caesium or iridium is used in form of needles

  6. Brachytherapy • Completed in short duration and is cost effective • Convenient for patient • Does not require hospitalization

  7. Superficial therapy • Ionizing radiation with energies from 8 to 140 kilovolts • Relatively soft X-rays • Used for non-infiltrating cancers like skin cancers

  8. Orthovoltage therapy • Ionizing radiation with energies 150 to 400 kilovolts • Used in treatment of infiltrating surface malignancies • Intraoral, intervaginal treatment

  9. Megavoltage therapy • Ionizing radiation greater than one million volts • Cobalt therapy and accelerators

  10. Location • Carefully located • Conform to BARC’s shielding requirement • Three foot thick walls and ceilings and access for equipment • Should not block future expansion plan • Ideally on ground floor close to OPD and radiology • Close to vertical transport system • No departments shall be below radiotherapy, thus basement is also a good option

  11. Design • Complex and requires experts advise during planning • Legal requirements in designing • Team of experts including radiation therapist, medical physicist, architects, engineers, equipment supplier and hospital planner shall be deployed • Shall be designed to present a warm, cheerful and pleasant atmosphere

  12. Design • High density materials in walls, ceiling and floor to contain radiation • Floor loading

  13. Facilities and space requirements • Reception-control • Waiting area close to reception • Dressing room • Examination rooms • Physician’s office • Nurses’ station • Therapy rooms and control rooms • Physicists’ room with treatment computers • Staff facilities • Patient toilets • Storage facilities

  14. Elements of desiging • Clinical examination section • Reception area with registration room • Examination and consultation • Room for medical staff and social workers • Waiting areas including trolley bays, storage, toilets • Consultation room shall be separated from treatment area • A darkened cubicle required for examining otolaringological patients

  15. Elements of designing • Treatment section • Treatment planning room • Computer assisted scanner • Simulator • Mould room • Room for machinery

  16. Elements of designing • Access to radiation room • Door with high lead shielding • Door may require motor drive • Maze arrangement preferable but consumes space • Direct viewing window can be given in superficial or orthovolatge installation

  17. Organization • Shall be headed by Radiotherapy Physician assisted by other onco specialist • Physicist who shall develop detail treatment plans for patients as prescribed by the physician • Radiotherapy technicians to calibrate therapy equipment, verify doses, position patients and operate the machines

  18. Organization • Nurses to assist physician in examining patients and help during treatment • Dietician to plan nutritional needs of patients • Others – social workers, secretary, clerk, attendants, housekeeping and security staff

  19. Problem situations • Inefficient scheduling • Lost charges • Down time

  20. Regulatory Processes • Clearance of unit by AERB (Type approved or NOC) • Approval of room layout plan (1:50 scale) • Construction only on basis of approved plan • Any modification shall be re-approved • Appointment of staff • Nomination and approval of radiological safety officer

  21. Regulatory Processes • Procurement of personnel monitors • Measuring and monitoring equipments • Authorization to procure radiation source

  22. Thank you
