  1. CEDIA 2011 • Tradeshow booth emphasizes HDMI Solutions selling • HDMI over CAT • HDMI over Coax • HDBASET • HDMI over Fiber • Intelix joins Liberty AV Solutions • Termination station demos of HDMI & Fiber • SnapRax and ETN Rack Display • Hands on demos of new Liberty Edge Online • New Products Display Include: • Intelix • DIGI-HDE Demo • HD Termination System

  2. BOOTH LAYOUT

  3. BOOTH LAYOUT

  4. BOOTH LAYOUT: Arial View 20’ 30’

  5. BOOTH LAYOUT: Rack Promo & Mounts • MOUNT PROMO • EP60F Fixed Wall Mount: $19 • IC60T Tilt Wall Mount: $99 • IC60S2A2 Articulating Wall Mount: $149 • WEB Orders Only • Promo Code: CEDIA • Shopping cart check out • Non-Returnable • Stainless Steel ETN • Snaprax Mounts will be on display

  6. INTELIX JOINS LIBERTY

  7. HDMI Distribution Solutions Wall

  8. HDMI Distribution Solutions Wall To show how our products work/sell together, we will have a HDMI Solutions Wall where customers can see a working model of each solution. • HDMI Over Cat • HDMI Over Coax • HDBASET • HDMI over Fiber Each product in the solutions demo will also be on static display

  9. HDMI OVER CAT SOLUTION • Intelix Matrix Switcher (tier-1 price) • 4x2; $725 • 4x4; $1460 • 8x8; $4720 • DIGI-HD-IR2 ($281/set) • HDMI & IR over dual Cat • DIGI-HD-UHR2 ($249/set) • HDMI over Single Cat • DIGI-HD-UHR2-R (receiver only); $166 • 1080P up to 150ft over Cat6 • 1080P up to 100ft over Cat5e

  10. HDMI OVER COAX SOLUTION • DIGI-HD-COAX • Send Unit: $206 (tier-1) • Receive Unit: $268 • Ideal for retrofits • Daisy chain up to 5 links • 1080P Resolution • 300ft over RG6 • 250ft over RG59

  11. HDBASET SOLUTION: HMDI Meets Ethernet • DIGI-HDE (Dealer price: $378/set) • Available early September • Not compatible with current 8x8 • 8x8 HDMI output may be connected to HDBASET transmitter • HDBASET 8x8 –Under Study • HDMI, ETHERNET, IR, and RS-232 OVER SINGLE CAT CABLE • Lengths up to 300ft over Cat5e • 100Mb Ethernet • Deliver streaming Internet video to display • IP control • Compatible with structured cabling installs (patch panel/outlet jack)

  12. HDBASET Diagram From IR Receiver Ethernet To IR Emitter HDMI DIGI-HDE TRANSMITTER DIGI-HDE RECEIVER 300ft Twisted Pair Cable HDMI In Ethernet Internet

  13. HDMI OVER FIBER SOLUTION • HDMI up to 100 meters • Supports Multi-Channel Audio • Transmit & Receive unit each require power supply (included) • Multimode Fiber • Dealer-1: $627

  14. HD TERMINATION SYSTEM • Field Terminable HDMI • Available late September • Cable sold 250/500ft Reel/Box • Connectors sold in 10Packs • Cable is not in-wall rated • CL2/in-wall rating in development • Late Fall • Typical 1080p distance up to 30ft (55ft with extender) • 250ft Reel: $364 (Dealer-1) • 10Pk Connectors: $77 (Dealer-1)

  15. Tripp-Lite PDU Remote Web Access Demo

  16. Rack Display • ETN RACK • Stainless Steel Demo • Solid Side Panels • 12,250lb Static Load • SnapRax • Assembles in minutes • Up to 600lb Static Load (depending upon configuration)

  17. LIBERTY EDGE ONLINE • Full release at InfoComm 2011 • New Product Menu Tree • New Smart Search • New Plate Selector • New My Pricelist Creation • Salespeople can log in as a customer code to: • Demo website features as customer • Access account, order & tracking info • Create WebBlox parts for customers
