Presentation Transcript


3953944

河南省教育科研网运行汇报

河南 郑州大学

2003-08-08


3953944

目录

  • 河南省教育科研网发展

  • 运行情况汇总

  • 网络服务


Hernet

HERNET的发展


Hernet1

HERNET一期建设

  • 入网高校47所,前期绝大多数学校和地市以2M接入

  • 建设高速骨干城市节点7个,全部2.5G连接,并局部构成环路,在网络层上实现线路冗余

  • 利用2.5GPOS和EDFA技术实现远距离(最远洛阳-郑州180公里)IP数据传输

  • 以千兆/百兆光纤方式接入当地教育城域网的学校逐步达到37所

  • 全省出口流量增长至300兆以上,国际流量也大幅度增加


Hernet2

HERNET二期主干网


Hernet3

HERNET二期建设

  • 新增高速城市节点9个,全部以2.5G 互联,并在全省范围内构成四个路由环路,保障骨干网络的畅通

  • 全省入网高校达到61所,其中有多所合并高校

  • 提供所有地市入网单位1000兆的接入能力

  • 全省范围年内开通组播服务,实现更广泛的多媒体资源共享

  • 全面推动河南省高校数字化校园的建设


3953944

典型网络结构

省主干网

城市节点骨干网交换机

城市节点接入产品

入网高校


3953944

网络运行情况(全省出口流量)


3953944

网络运行情况(全省至武汉出口流量)


3953944

城市节点流量分布(新乡)


3953944

城市节点流量分布(周口)


3953944

接入高校流量分布(郑州航空管理学院)


3953944

郑州市城域网流量分布(教育厅节点)


3953944

网络异常时流量表现(病毒及网络侵入造成进出流量不均衡)


3953944

网络故障统计

网络故障主要由以上三种组成,另由CERNET主干线路故障引起的网络中断有三次


3953944

网络故障统计

2002年7月1日-2003年7月1日,累计发生网络故障15次,累计时间44小时,所统计的故障都是影响到至少一所接入高校,甚至一个接入地市的,各接入单位内部原因引起的故障未计入在内。


3953944

主干网络路由(OSPF)

  • E2 202.196.236.64 [110/20] via 210.43.146.18, 00:35:45, POS4/0

  • [110/20] via 210.43.146.22, 00:35:45, POS6/0

  • O E2 202.196.236.32 [110/20] via 210.43.146.18, 00:35:45, POS4/0

  • [110/20] via 210.43.146.22, 00:35:45, POS6/0

  • O E2 202.196.236.0 [110/20] via 210.43.146.18, 00:35:45, POS4/0

  • [110/20] via 210.43.146.22, 00:35:45, POS6/0

  • O IA 210.43.26.0/24 [110/15] via 210.43.146.26, 00:35:45, POS3/0

  • 210.43.147.0/24 is variably subnetted, 2 subnets, 2 masks

  • O E2 210.43.147.0/25

  • [110/1] via 210.43.146.118, 00:35:45, GigabitEthernet8/0

  • O E2 210.43.147.128/29

  • [110/1] via 210.43.146.118, 00:35:45, GigabitEthernet8/0

  • 202.196.237.0/26 is subnetted, 4 subnets

  • O E2 202.196.237.192 [110/20] via 210.43.146.18, 00:35:45, POS4/0

  • [110/20] via 210.43.146.22, 00:35:45, POS6/0

  • O E2 202.196.237.128 [110/20] via 210.43.146.22, 00:35:45, POS6/0

  • [110/20] via 210.43.146.18, 00:35:45, POS4/0

  • O E2 202.196.237.64 [110/20] via 210.43.146.18, 00:35:45, POS4/0

  • [110/20] via 210.43.146.22, 00:35:45, POS6/0

  • O E2 202.196.237.0 [110/20] via 210.43.146.18, 00:35:45, POS4/0

  • [110/20] via 210.43.146.22, 00:35:45, POS6/0

  • O IA 210.43.27.0/24 [110/15] via 210.43.146.26, 00:35:45, POS3/0

  • 202.196.238.0/24 is variably subnetted, 10 subnets, 2 masks


3953944

骨干路由OSPF路由信息

  • i 192.168.1.4 [3] via 210.43.146.18, POS4/0, ABR/ASBR, Area 0, SPF 102

  • I 211.67.191.129 [2] via 210.43.146.26, POS3/0, ASBR, Area 0, SPF 102

  • i 210.43.146.14 [1] via 210.43.146.14, POS5/0, ABR/ASBR, Area 0, SPF 102

  • i 210.43.146.34 [2] via 210.43.146.22, POS6/0, ABR, Area 0, SPF 102

  • i 210.43.146.34 [2] via 210.43.146.18, POS4/0, ABR, Area 0, SPF 102

  • i 210.43.146.33 [1] via 210.43.146.22, POS6/0, ASBR, Area 0, SPF 102

  • i 210.43.146.65 [1] via 210.43.146.118, GigabitEthernet8/0, ABR/ASBR, Area 1.1.1

  • .1, SPF 5

  • i 210.43.146.114 [2] via 210.43.146.18, POS4/0, ABR/ASBR, Area 0, SPF 102

  • i 210.43.146.113 [1] via 210.43.146.18, POS4/0, ASBR, Area 0, SPF 102

  • i 210.43.146.118 [4] via 210.43.146.18, POS4/0, ABR/ASBR, Area 0, SPF 102

  • I 210.43.146.126 [2] via 210.43.146.6, POS2/0, ASBR, Area 0, SPF 102

  • i 210.43.146.130 [2] via 210.43.146.14, POS5/0, ASBR, Area 0, SPF 102

  • i 210.43.146.129 [1] via 210.43.146.6, POS2/0, ABR, Area 0, SPF 102

  • I 210.43.146.138 [2] via 210.43.146.2, POS1/0, ASBR, Area 0, SPF 102

  • i 210.43.146.137 [1] via 210.43.146.2, POS1/0, ABR, Area 0, SPF 102

  • i 210.43.146.142 [3] via 210.43.146.14, POS5/0, ASBR, Area 0, SPF 102

  • I 202.196.239.158 [3] via 210.43.146.22, POS6/0, ASBR, Area 0, SPF 102

  • I 202.196.239.158 [3] via 210.43.146.18, POS4/0, ASBR, Area 0, SPF 102

  • i 210.43.146.166 [5] via 210.43.146.14, POS5/0, ABR/ASBR, Area 0, SPF 102

  • i 210.43.146.166 [5] via 210.43.146.26, POS3/0, ABR/ASBR, Area 0, SPF 102

  • i 210.43.146.169 [4] via 210.43.146.26, POS3/0, ABR/ASBR, Area 0, SPF 102

  • i 210.43.146.170 [3] via 210.43.146.26, POS3/0, ABR/ASBR, Area 0, SPF 102


3953944

网络状态监控


3953944

网络故障状态记录


3953944

网络运行服务

  • 网络传输线路状态监控

  • 安全运行监控

  • 网络侵入、病毒预警

  • 网络安全服务网

  • IP电话服务

  • 全省教育网络信息发布

  • 值班电话:

    7767135 7762463 37100119(运行值班)

    5062463 37100110(24小时值班)

    5112668 37100070(客户服务)


3953944

谢谢!

郑州大学

2003-08-08
