Work and Mechanical Energy

Work and Mechanical Energy. Formula and Transitions. Work. Formula: _______ , where θ is the angle between the force and the direction of motion: E.g. A box on a frictionless surface is pushed with a force of 13N for a distance of 3.5 m. How much work was done: W = . Work (cont.).

dillan
Download Presentation

Work and Mechanical Energy

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Work and Mechanical Energy Formula and Transitions

  2. Work • Formula: _______, where θ is the angle between the force and the direction of motion: • E.g. A box on a frictionless surface is pushed with a force of 13N for a distance of 3.5 m. How much work was done: • W =

  3. Work (cont.) • A toboggan is being dragged as shown below. If the dude does 350J of work over what 12m, how much force did he apply? • W=Fdcosθ • F = • d = = 30°

  4. Gravitational Potential Energy • ΔEp = ___________ • Example: A 2.5kg book is given 45J more of potential energy by lifting it up from a chair to a book shelf. If the chair is 70cm high, how high is the book shelf? • ΔEp = mg Δh • Δh == ____m • Hbookshelf =

  5. Gravitational Potential Energy (cont.) • Continuing on from the previous example: • How much work was done to lift the book from the chair to the shelf? • Since the work done = __________ (work-energy theorem, isolated system), and all the energy change is gravitational potential, W = 45J • What force was applied to do this? W = Fdcosθ • F=

  6. Kinetic Energy • Ek = ______________ • A 1200kg car has 260kJ of kinetic energy. How fast is it going in km/h? • v =

  7. Kinetic energy (cont.) • The trucker applies the brakes which apply a frictional force of 1.50kN to slow the truck to 50 km/h. How much distance did this take to accomplish? • Using the work-energy theorem, the change in energy of the truck = work done: ΔEk= ________ • Ekf – Eki = Fdcosθ • ½mvf2 - ½mvi2 = Fdcosθ • ½m(vf2 - vi2) = Fdcosθ • d = • d = (note θ = 180 because the force (friction) is opposite to the direction of motion!) • d = 50km/hr = 13.8889m/s

  8. Elastic (spring) Potential Energy • Eps= ____where k is the spring constant in N/m and x = distance spring is compressed or stretched from its resting (equilibrium) position! • Example: if a spring requires15N of force to stretch it25 cm from equilibrium, what is its spring constant? • Since W = Epsin this case, then _________ = ½kx2 • x = d (the distance the force is applied is the stretching distance!) • So Fcosθ = • k =
