An efficient process live migration mechanism for load balanced distributed virtual environments

An Efficient Process Live Migration Mechanism forLoad Balanced Distributed Virtual Environments

BalazsGerofi, Hajime Fujita, Yutaka Ishikawa

Yutaka Ishikawa Laboratory

The University Of Tokyo

IEEE Cluster2010


Outline

Outline

  • Motivation

  • Cluster Server Architecture

  • DVE Software Components

  • Process Live Migration

  • Multiple Socket Migration Optimizations

  • Dynamic Load Balancing

  • Evaluation

  • Conclusion

IEEE Cluster2010


Motivation

Motivation

  • In Distributed Virtual Environments (DVE):

    • Massively Multi-player Online Games (MMPOG)

    • Networked Virtual Environments (NVE)

    • Distributed Simulations such as the High-Level Architecture (HLA)

  • 10,000 ~ 100,000 of clients may be involved

  • Cluster of servers is used for providing services on large scale

    • Zoning (i.e., partitioning the virtual space among servers)

  • Main limitations of application level load-balancing:

    • Client migrations are heavy, server state needs to be transferred, client(s) reconnect, etc..

    • Physical machine limited to neighboring zones

  • Is operating system level load-balancing feasible?

    • Server processes are highly interactive

    • Maintain a massive amount of network connections (clients)

    • Maintain connections with other in-cluster components

    • How to migrate such processes?

IEEE Cluster2010


Outline1

Outline

  • Motivation

  • Cluster Server Architecture

  • DVE Software Components

  • Process Live Migration

  • Multiple Socket Migration Optimizations

  • Dynamic Load Balancing

  • Evaluation

  • Conclusion

IEEE Cluster2010


Cluster server architecture

Cluster Server Architecture

  • Each DVE server is equipped with a public and a private interfaces, same IP address is assigned to the public interfaces

  • Router broadcasts incoming packets to all DVE server nodes

    • Migrating zone server processes does not require any work on the router!

  • Zone server processes are distinguished based on separate port numbers (as opposed to separate IP addresses)

IEEE Cluster2010


Outline2

Outline

  • Motivation

  • Cluster Server Architecture

  • DVE Software Components

  • Process Live Migration

  • Multiple Socket Migration Optimizations

  • Dynamic Load Balancing

  • Evaluation

  • Conclusion

IEEE Cluster2010


Server node software components

Server Node Software Components

  • mig_mod: migration module with live migration and socket support (extension of Berkeley C/R module)

  • cap_trans_mod: packet capturing and address translation kernel module (detailes in paper)

  • transd: translation daemon

  • migd: migration daemon

  • cond: load monitor and load balancer

  • zone_serv: zone server processes

zone_serv1

migd

transd

cond

zone_servn

Linux kernel

mig_mod

cap_trans_mod

IEEE Cluster2010


Outline3

Outline

  • Motivation

  • Cluster Server Architecture

  • DVE Software Components

  • Process Live Migration

  • Multiple Socket Migration Optimizations

  • Dynamic Load Balancing

  • Evaluation

  • Conclusion

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Process Live Migration

Process Image

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Process Live Migration

Process Image

Process Image

Transfer the whole process image in the background without stopping the execution

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Process Live Migration

- dirty memory page

Process Image

Process Image

Track dirty pages for a certain period, process is still being executed

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Process Live Migration

- dirty memory page

Process Image

Stop process (freeze phase), transfer dirty memory, export network connections and transfer data to destination

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Process Live Migration

Note: main goal is short process freeze time!

Process Image

Apply changes and resume execution

network sockets

source host

destination host

network

IEEE Cluster2010


Outline4

Outline

  • Motivation

  • Cluster Server Architecture

  • DVE Software Components

  • Process Live Migration

  • Multiple Socket Migration Optimizations

  • Dynamic Load Balancing

  • Evaluation

  • Conclusion

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Iterative socket migration

(during process freeze phase)

- dirty memory page

Incoming packet loss prevention!

Process Image

Process Image

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Iterative socket migration

(during process freeze phase)

- dirty memory page

Process Image

Process Image

Extract remote IP and port number, set up a filter at the destination node to capture incoming packets and disable socket

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Iterative socket migration

(during process freeze phase)

- dirty memory page

Process Image

Process Image

Migrate socket data to destination node

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Iterative socket migration

(during process freeze phase)

- dirty memory page

Process Image

Process Image

Inject any packets that were captured on the destination node and attach socket to the process

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Iterative socket migration

(during process freeze phase)

- dirty memory page

Process Image

Process Image

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Iterative socket migration

(during process freeze phase)

- dirty memory page

Process Image

Process Image

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Iterative socket migration

(during process freeze phase)

Note: requires several synchronization steps

with short writes following each other!

- dirty memory page

Process Image

Process Image

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Collective socket migration

(during process freeze phase)

- dirty memory page

Process Image

Process Image

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Collective socket migration

(during process freeze phase)

- dirty memory page

Process Image

Process Image

Extract remote IP and port number for all sockets, set up filters to capture incoming packets and disable sockets

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Collective socket migration

(during process freeze phase)

- dirty memory page

Process Image

Process Image

Extract socket data into one unified buffer and transfer everything in one go

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Collective socket migration

(during process freeze phase)

Note: the amount of socket data transferred can

be still large!

- dirty memory page

Process Image

Process Image

Attach sockets, inject packets.

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Incremental collective socket migration

(during dirty-logphase)

- dirty memory page

Process Image

Process Image

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Incremental collective socket migration

(during dirty-log phase)

- dirty memory page

Process Image

Process Image

All socket data are transferred asynchronously and tracking structures are allocated for each connection

network sockets

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Incremental collective socket migration

(during dirty-log phase)

- dirty memory page

Process Image

Process Image

Some pages are dirtied and some sockets’ state change are detected

network sockets

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Incremental collective socket migration

(during dirty-log phase)

- dirty memory page

Process Image

Process Image

Dirty pages transferred and modified sockets’ state are updated, tracking loop timeout is decreased

network sockets

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Incremental collective socket migration

(during dirty-log phase)

- dirty memory page

Process Image

Process Image

When number of dirty pages or tracking timeout goes below a pre-defined limit, enter process freeze phase

network sockets

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Incremental collective socket migration

(during dirty-log phase)

- dirty memory page

Process Image

Process Image

Transfer dirty pages and set up packet capture filter

network sockets

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Incremental collective socket migration

(during dirty-log phase)

Note: transferred socket data in freeze phase is

much less than the overall socket representation!

- dirty memory page

Process Image

Process Image

Update sockets that have changed in the last iteration and disable sockets on the source machine

network sockets

network sockets

source host

destination host

network

IEEE Cluster2010


An efficient process live migration mechanism for load balanced distributed virtual environments

Incremental collective socket migration

(during dirty-log phase)

- dirty memory page

Process Image

Process Image

Inject packets and re-enable sockets on the destination machine

network sockets

source host

destination host

network

IEEE Cluster2010


Outline5

Outline

  • Motivation

  • Cluster Server Architecture

  • DVE Software Components

  • Process Live Migration

  • Multiple Socket Migration Optimizations

  • Dynamic Load Balancing

  • Evaluation

  • Conclusion

IEEE Cluster2010


Dynamic load balancing

Dynamic Load Balancing

  • Decentralized middleware

  • Load balancing is sender initiated performing a hand-shake with the receiver

  • Transfer policy:

    • Threshold driven (if load exceeds a certain value)

  • Location policy:

    • Based on knowledge of load on the rest of the nodes, preferring a node that is on the opposite side of the cluster load average

  • Selection policy:

    • Prefers a process that consumes as much CPU power as much the difference between the given node’s load and the cluster load average

  • Information policy:

    • Periodic policy, nodes broadcast their load

IEEE Cluster2010


Outline6

Outline

  • Motivation

  • Cluster Server Architecture

  • DVE Software Components

  • Process Live Migration

  • Multiple Socket Migration Optimizations

  • Dynamic Load Balancing

  • Evaluation

  • Conclusion

IEEE Cluster2010


Evaluation experimental framework

Evaluation: experimental framework

  • Dedicated single IP address cluster

  • 5 DVE server nodes + a MySQL server

  • 2.4GHz Dual-Core AMD Opteron

  • 2 GB RAM

  • Gigabit Ethernet for both in-cluster and public network

IEEE Cluster2010


Evaluation openarena server

Evaluation: OpenArena server

  • OpenArena is an open-source multi-player online game based on the Quake III engine [1]

  • Uses UDP for client-server communication

  • ~20 messages (updates) per second

  • Live migrated when 24 clients were participating in a session

  • Based on tcpdump’s result on the client machines ~25ms service downtime due to migration

[1] http://openarena.ws/smfnews.php

IEEE Cluster2010


Evaluation dve simulation

Evaluation: DVE simulation

  • DVE simulation with communication characteristics resembling real-world MMOPGs using TCP connections

  • Client state update: 20 msgs / sec, 256~512 bytes message size [2]

  • DVE server processes maintain MySQL to local DB server

  • CPU consumption grows proportionally with number of clients in a given zone, 10,000 clients involved

  • Virtual space consists of 10x10 zones, each DVE server node is assigned to 20 zones initially

  • 15 minutes simulation during which clients are instructed to move to the up-left and bottom-right corner of the virtual space

  • Files are assumed to be available on each node

[2] Traffic characteristics of a massively multi-player online role playing game, NetGames’05

IEEE Cluster2010


Live migration process downtime

Live migration process downtime

IEEE Cluster2010


Socket data transferred during process freeze phase

Socket data transferred during process freeze phase

IEEE Cluster2010


Load distribution during simulation without load balancing

Load distribution during simulation without load balancing

  • node1, node2 and node5 becomes overloaded when clients move to zones maintained by these nodes

IEEE Cluster2010


Load distribution during simulation with load balancing

Load distribution during simulation with load balancing

  • Load stays balanced throughout the simulation

IEEE Cluster2010


Number of zone server processes on each node during the simulation

Number of zone server processes on each node during the simulation

  • Lighter processes are migrated over to node3 and node4 in order to balance the overall load of the system

IEEE Cluster2010


Outline7

Outline

  • Motivation

  • Cluster Server Architecture

  • DVE Software Components

  • Process Live Migration

  • Multiple Socket Migration Optimizations

  • Dynamic Load Balancing

  • Evaluation

  • Conclusion

IEEE Cluster2010


Conclusion

Conclusion

  • Process live migration

    • Optimizations for migrating a massive amount network connections

    • No modifications to the TCP protocol or to the client side network stack

  • Dynamic load balancing engine exploiting process live migration

  • DVE simulation for demonstrating load balancer and live migration

  • Other possible scenarios:

    • Fault tolerance (IEEE NCA2010)

    • Power management

IEEE Cluster2010


Thank you for your attention questions

Thank you for your attention!Questions?

IEEE Cluster2010


Related work

Related Work

  • Connection Migration:

    • NEC’s distributed Web Server arch: each session has its own virtual IP address

    • SockMi, Tcpcp: TCP migration with IP layer forwarding, don’t decouple the process from the source machine

    • TCP Migrate option: extension to the TCP protocol

  • Process migration and incremental checkpointing:

    • V-System, Amoeba, Mach, Sprite, MOSIX – limited connection migration support

    • BLCR: no support for connection and incremental checkp.

    • Zap’s VNAT: support required on client side as well

  • Load balancing DVEs:

    • Several studies addressing application level solutions

    • MOSIX: home-node approach leaves residual dependencies

IEEE Cluster2010


  • Login
