  1. Products and Technologies of PZL-Świdnik Rzeszów, June 28-29th, 2010 Autor:ZenonWitkowski Wytwórnia Sprzętu Komunikacyjnego

  2. PZL-Swidnik Sales structure 2% 8% 58% 13% 12% 7%

  3. Company Profile Customer support Helicopters Cooperation Training R&D

  4. Main Products PZL W-3A SOKOL PZL SW- 4 The PZL W-3A Sokółis a medium-light, twin engine, single main rotor, multipurposehelicopter with conventional design. Characteristics: -two engines PZL-10W with 900shp power each, -14 seats (including 2 pilot seats), MTOW=6400kg. The PZL SW-4 is a single turbine, light, multipurpose helicopter designed to carry up to 4 passengers and a pilot. The helicopter has a conventional rotor system and is powered by single Rolls-Royce Allison 250 C20-R/2(SP) engine rated at 457shp (336kW).

  5. Industrial Cooperation – Helicopter Structures AGUSTAWESTLAND AW139 Fuselage EUROCOPTER EC145 Cowlings AGUSTAWESTLAND AW109/119 Fuselages BELL M 412 Tail Boom

  6. Industrial Cooperation – Fixed Wing Structures EADS SOGERMA ATR-72 Centre Wing Box Assembly CESSNA Seat Frames & Engine Mounts EUROCOPTER AIRBUS A320 Belly Fairings PILATUS PC-12 Fuselage structure& Wings GKN AEROSPACE HTF7000 Nacelle Components

  7. Industrial Cooperation – Aircraft Components LATECOERE AIRBUS A 320 Passenger Door Mechanisms RATIER - FIGEAC Cable Tension Regulators EUROCOPTER AIRBUS A320 Aircraft Components

  8. Industrial Cooperation – Newest

  9. Industrial Cooperation – Newest Pilatus Programme Turnover Forecast

  10. Manufacturing Capabilities – Mechanics Machining Plant is equipped with the most modern 3 and 5 axis CNC machines dedicated for aluminium, steel, copper alloys and titanium materials. Machined components for all products of PZL-Swidnik are manufactured in this plant. The final assembly of mechanical assemblies, such as landing gears and main hubs, is also carried out there.

  11. Manufacturing Capabilities - Composites Composite Plant manufactures composite elements and bonded assemblies, including helicopter rotor blades, fuselage structures and fairings. The plant is equipped with the cutting edge equipment, such as: autoclaves, CNC machines for prepregs cutting, CNC 5 axis milling machines for trimming, A- and C-scan NDT equipment, and laser projectors Virtek.

  12. Manufacturing Capabilities – Surface Treatment Surface Treatment & Coating Plant performs coating treatments of aluminium, steel, copper alloys, titanium and other materials. Processes carried out in this Plant fulfil the requirements of the latest and highest quality, technical and environment protection standards.

  13. R&D PZL-Swidnik has been involved in the design, development, and certification of helicopters for over 50 years. The activity of Research and DevelopmentCentre comprises designing (on the basis of ANSYS, MSC/PATRAN, MSC/NASTRAN,ADAMS, ABAQUS, FLUENT, CATIA UNIGRAPHICS); ground tests, flight tests, integration of weapons, navigation and communication systems on helicopters manufactured by PZL-Swidnik, and upgrading of primary helicopter units. AGUSTAWESTLAND AW 139 Fuselage EUROCOPTER EC 145 Cowlings

  14. Manufacturing Capabilities - Aerostructures Structures and sub-assemblies are put together at Aviation Plant. There are located final assembly lines of helicopters and structural components of fixed wings and helicopters. For the running programs only, we have delivered close to 1100 shipsets of AgustaWestland helicopter complete fuselages and tail booms, 300 shipsets of ATR-72 Centre wing box skeletons, more than 2000 shipsets of doors for Airbus aircraft, 170 Bell 412 helicopter tail booms, nearly 560 engine nacelles for Challenger 300 aircraft and a variety of Cessna aircraft components.

  15. Customers

  16. for Aeronautics & Air Transport Joint Technology Initiative Clean Sky European Projects ON-WINGS

  17. JTI The program is devided in 7 areas: GRC1 – Innovative blades GRC2 – Drag reduction GRC3 – Innovative ElectricalSystem GRC4 – Installation Diesel Engine on Light H/C GRC5 – Environmental Flight Paths GRC6 – Eco-design GRC7 – Technology Evaluator Time schedule: July 2008 ~ 2015 (2017) PZL budget is 8.47mln €

  18. Superior Purposeof JTI

  19. Quality Policy of the Company PZL-Swidnik SA implemented and continuously develops Quality System, which covers the following elements: • Quality Policy • Quality System Documentation • Company Organisation Structure

  20. Quality Policy of the Company PART 21 Design Organisation PART 145 Maintenance Organisation PART 21 Production Organisation

  21. Many ThanksFor Your Attention zenon.witkowski@pzl.swidnik.pl Wytwórnia Sprzętu Komunikacyjnego „PZL-Świdnik” Spółka Akcyjna an AgustaWestland Company al. Lotników Polskich 1, 21-045 Świdnik
