INDUCTION MOTOR No-load and blocked rotor tests

SEE 3433 MESIN ELEKTRIK. INDUCTION MOTOR No-load and blocked rotor tests. NO-LOAD AND BLOCKED ROTOR TESTS. Tests performed to determine the per phase equivalent circuit. - conducted in SEE 3742. Equivalent to open circuit and short circuit tests in transformers. T. Operation at no-load,

daphne-ayers
Download Presentation

INDUCTION MOTOR No-load and blocked rotor tests

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. SEE 3433 MESIN ELEKTRIK INDUCTION MOTORNo-load and blocked rotor tests

  2. NO-LOAD AND BLOCKED ROTOR TESTS Tests performed to determine the per phase equivalent circuit - conducted in SEE 3742 Equivalent to open circuit and short circuit tests in transformers

  3. T Operation at no-load, s very small  NO-LOAD AND BLOCKED ROTOR TESTS No-load test - No mechanical load applied - Machine run at rated voltage and frequency - Power and current measured

  4. NO-LOAD AND BLOCKED ROTOR TESTS No-load test - No mechanical load applied - Machine run at rated voltage and frequency - Power and current measured Operation at no-load, s very small R2’/s >> Xm Losses is only due to rotational

  5. NO-LOAD AND BLOCKED ROTOR TESTS No-load test INL + VNL  RNL jXls jXm ZNL obtained from VNL and INL RNL obtained from measured power Therefore Xls + Xm can be calculated

  6. NO-LOAD AND BLOCKED ROTOR TESTS Blocked-rotor test • - Rotor is locked or blocked (does not move, m = 0) • Voltage at Frequency at reduced frequency applied so that • rated current flows • - Power measured

  7. NO-LOAD AND BLOCKED ROTOR TESTS Blocked-rotor test IBR X’ls X’lr + VBR  Rs R’r RBR = R1+R2’obtained from measured power,, hence R2’ determined ZBR calculated and XBR = Xls + Xlr’ can be determined Assuming Xls = Xlr’ , Xm can be calculated

  8. NO-LOAD AND BLOCKED ROTOR TESTS SEE EXAMPLE 5.3
