SMERT: Energy-Efficient Design of a Multimedia Messaging System for Mobile Devices

Lin Zhong Rice University

Bin WeiA&T Labs-Research

Michael Sinclair Microsoft Research


Multimedia messaging l.jpg
Multimedia Messaging System for Mobile Devices

1

Compelling media sources

1

2

Relevant pieces constructed

3

Rich content imposes more challenges on power usage

?

3

2

Tuesday, May 28, 2006 8:31PM

TeleComm(96 seconds)

In carefully worded statement, BellSouth, AT&T, and now Verizon have challenged a report that said the companies gave tens of millions of consumers' phone records to the National Security Agency as part of the war on terrorism after 9/11.

news program

text, images, audio, and video


Energy cost l.jpg

Device power profile System for Mobile Devices

Communications

1600mW, GPRS

System

370mW, Busy

User interfaces

212mW, Display

Messaging service

Energy Cost

Message Text KFrames Video

Size 140 10K 696K

Auto Dnld (J) ~0.03 ~1.2 ~80

Manu Dnld (J) ~0.08 ~1.7 ~114

Consum. cost (J) ~5 ~10 ~48

Our Goal:

Optimizing multimedia messaging services,given the constraint of battery lifetime


Our approach l.jpg
Our Approach System for Mobile Devices

  • Reconstruct message content

    • Different levels

    • Selective and incremental, instead of all-or-none

  • Utilize low-power user interface device

    • A wrist-worn low-power user interface device

    • Limited content with control interface

  • Reduce user interruptions

    • Battery-aware message fetching

    • Automatic downloading without energy consumption on display


Smert a smart alert messaging system l.jpg

MediaAlert messaging system System for Mobile Devices

Watch

SMS

Notification

Fetching

Media-alerts of different qualities/formats

Web server

Mobile device

SMERT: A hierarchical multimedia messaging system for mobile users

SMERT: A SMart alERT Messaging System


Smert sms vs mms sms l.jpg
SMERT SMS vs. MMS/SMS System for Mobile Devices

  • 140 Bytes

  • Short description of the message

  • URL to richer content

    • Different from conventional MMS/SMS

      • SMS: short message + control information

      • MMS: more detailed content

    • The device can choose when to download the content with which wireless interface

      • MMS is limited to the use of cellular networks

      • Our device can choose to use Wi-Fi, which can consume 10 times less energy than GPRS in data transfer if available


Cache watch l.jpg
Cache-Watch System for Mobile Devices

  • Cache-Watch

    • Caches messages from phone

      • Data cache

    • Low-power secondary interface to phone

      • Interface cache

  • 100 X 132 Dot Matrix LCD

  • Three series of touch sensors

    • 1: mode switching

    • 2 and 3: displayed content manipulation

  • Browse/delete/confirm cached information

    • Synchronized with the phone periodically

Cache-watch 1.0


Watch with invisible technology l.jpg
Watch with Invisible Technology System for Mobile Devices

  • Tech-heavy watches yet to prove wide social acceptance

Invisible text

Fossil Palm Watch

SPOT/MSN-Direct Fossil

  • A watch with usual appearance but one line of digital text display

    • Short text messages

    • Caller IDs


New development at rice l.jpg

2x8 character low-power LCD System for Mobile Devices

Debugging board

Both software and hardware will be OPEN-SOURCE!

New Development at Rice


Energy efficiency benefit l.jpg

3 System for Mobile Devices

Equivalent # of 20-second phone SMS access per hour

2.3

2

# of phone SMS accesses

1.4

1

0.7

0.6

0.5

0

0.5

1

3

5

10

Phone-CacheWatch synchronization interval (minute)

Energy Efficiency Benefit

  • Phone outsources simple-yet-frequent interactive tasks to Cache-Watch

    • Display usage reductionenergy reduction

One reduction in phone text message accesses per two hour will justify Bluetooth connection every 10 minutes

Benefit increases if lower power wireless personal-area technologies are used


Smert fetching and notification l.jpg

MediaAlert Messaging system System for Mobile Devices

Watch

SMS

Notification

Fetching

Media-alerts of different qualities/formats

Web server

Mobile device

SMERT: Fetching and Notification

  • Fetching and Notification

    • Prioritize messages

    • Battery awareness (Evaluate battery)

  • Adaptive synchronization scheme


Message prioritization l.jpg
Message Prioritization System for Mobile Devices

  • Priority is determined by match quality and quantity

    • Keywords are grouped in levels of different urgency

    • Matches are counted across groups; higher level dominates lower ones; more matches contribute more.

  • Delay-Tolerance Score (DTS)

  • Priority score is (1-DTS) which is between 1 (most urgent) and 0 (least urgent).

Informative (5-0)

Deferrable (10-0)

Critical (1-0)

l

m

n

∑ C + E * ∑ I + F * ∑ D

i

i

i

i = 1

i = 1

i = 1

DTS =

d *(l + m + n)

Critical: 1/10, 1/20, 1/30, 1/40, …

Informative: 5/10, 9/20, 12/30, 14/40,…

Deferrable: 10/10, 19/20, 27/30, 33/40…


Battery evaluation l.jpg
Battery Evaluation System for Mobile Devices

  • Energy Optimism Score (EOS)

  • Battery-aware policies need information from both angles.

    • Priority score – the application perspective.

    • Energy optimism score – the device perspective.

RBC

EOS =

ECR * EWT

RBC: Remaining battery capacity

ECR: Energy consumption rate

EWT: Expected work time


Battery aware policies l.jpg
Battery-Aware Policies System for Mobile Devices

Messages arrive as SMS

Phone-watch synchronization schedule

Notification policy

Through phone

Send to wrist

Fetching policy

Bluetooth

Decision sent back to phone

User decision

Fetch

Delete

CacheWatch

Default message notification

Message Gator on phone


Battery aware fetching and notification l.jpg

S System for Mobile Devices

6

10

Battery-Aware Fetching and Notification

  • Notification policy depends on priority score and EOS.

    • Ignore low priority messages when EOS is low

    • Notify the user through the phone when priority is high

  • Automatic or user directed fetching

  • Tradeoffs among priority, EOS and message size, as

Y<0, P*EOS <= 0.5: immediate

P*EOS >0.5: k-frames

0<Y<0.5: k-frames

Y>1.5: clip

Fetching Factor (Y) = P * EOS -

P: priority score

EOS: energy-optimism score

S: the size of the smallest video format


Communication need w r t message delay l.jpg
Communication Need w.r.t. Message Delay System for Mobile Devices

1000

900

800

Fixed interval

700

Adaptive-MAX=20, STEP=1

600

Adaptive-MAX=40, STEP=1

Total # of phone-watch communications

500

Adaptive-MAX=40, STEP=2

400

300

200

100

0

0

5

10

15

20

25

30

35

Average message delay (minutes)


Design lessons l.jpg
Design Lessons System for Mobile Devices

  • Looking beyond the mobile device itself

  • Energy efficiency coupled with usability

  • Energy efficiency != less energy consumption

    • Maximize messaging services while achieving the targeted battery lifetime


Conclusion and future work l.jpg
Conclusion and future work System for Mobile Devices

  • SMERT: an energy-efficient multimedia messaging system

  • Targets:

    • Reduce communication requirement

    • Minimize interruptions to the user

  • Methods:

    • Device hierarchy

    • Information richness versus battery usage

  • Future work

    • User studies

    • Multiple wireless networks for higher energy efficiency (supported by SMERT)


Measuring power consumption l.jpg
Measuring power consumption System for Mobile Devices

  • Hardware

    • 0.1 ohm resistor in series inside battery

    • 1 KHz sampling rate

    • USB measurement device


Thermal challenge l.jpg
Thermal challenge System for Mobile Devices

Every One Watt increases surface temperature by about 13 deg C

Simulation using FloTherm

Phone case temperature will be 40 deg C higher for a three-watt SMT5600.

Fuel cell batteries have <50% efficiency: one-watt heat for one-watt electricity


Adaptive communication scheme l.jpg
Adaptive Communication Scheme System for Mobile Devices

  • Dynamically adjust phone-watch communication intervals

  • Traces


Related work l.jpg
Related Work System for Mobile Devices

  • Internet alerts

    • Google alerts, Yahoo alerts, etc.

    • Most of them rely on email

  • Balancing application quality and energy conservation

    • Keeping track of power demand, supply, and usage history

    • Computation offloaded from mobile devices to wall-powered computers

  • Standard messaging framework

    • IMS
