Presentation Transcript


An analysis of browser domain isolation bugs and a light weight transparent defense mechanism l.jpg

An Analysis of Browser Domain-Isolation Bugs and A Light-Weight Transparent Defense Mechanism

Shuo Chen†, David Ross‡, Yi-Min Wang†

†Internet Services Research Center

Microsoft Research

‡ Microsoft Security Technology Unit

October 30th, 2007


Foundation of browser security same origin policy l.jpg

Foundation of Browser Security – Same-Origin Policy

  • A browser can visit pages from benign and malicious websites at the same time.

  • Browser needs to provide an isolation mechanism so that pages from different domains cannot access each other.

    • The policy of such a mechanism is commonly referred to as the same-origin policy (SOP)

    • Otherwise, a foo.com page can do almost anything to a bank.com page

      • Info leak: steal the user’s personal information in myBank.com

      • Request forgery: transfer the user’s money to other places.


Isolation is important but difficult l.jpg

Isolation is important, but difficult

  • Some SOPs are not clearly defined.

    • The industry still needs to define some specific SOPs.

  • However, even for well-defined SOPs, the current implementations of the isolation mechanisms are surprisingly error-prone.

    • IE, Firefox, Netscape, Opera all had bugs in their implementations.

  • Demos: attacks against IE 6 (on WinXP)


How can we eliminate implementation bugs in the isolation mechanism l.jpg

How can we eliminate implementation bugs in the isolation mechanism

  • Keep patching? Not a real solution, not effective for future bugs.

  • Perform a thorough code review of the browser code base?

    • Not realistic. The code base is huge, bugs are much trickier than buffer overruns.

  • What kind of solution do we want?

    • Comprehensive: solve this class of bugs

    • Transparent: no need to change web applications

    • Light-weight: low performance overhead

    • Self-contained correctness: can be implemented correctly with only limited understanding of existing browser code base


Our proposal script accenting l.jpg

Our proposal: Script Accenting

  • In human languages, accent is essentially an identifier of a person’s origin that is carried in communications

  • Script accenting

    • Each domain is associated with an “accent key”.

    • Scripts and HTML object names are represented in their accented forms at the interface between the script engine and the HTML engine.

    • Two frames cannot interfere if they have different accent keys (no need for an explicit check for the domain IDs)


A study of real attacks l.jpg

A Study of Real Attacks


What s so difficult about sop check l.jpg

What's so difficult about SOP check?

  • Frame A’s domain is x, frame B’s domain is y. Isn’t it easy to simply check x==y?

  • No, it’s much more complicated than this

    • There are unexpected execution paths in the system to bypass the check or feed incorrect domain IDs to the check.

    • Exploit scenarios take advantage of many complex mechanisms in the browser.

    • Surprisingly smart ways of exploits!


Exploiting the interactions between ie and windows shell l.jpg

Exploiting the Interactions between IE and Windows Shell

Windows ShellAddress Parser

Window Shell

javascript: doEvil

file: javascript: doEvil

IE

Salary=$1234

Direct deposit settings …

Frame2 = open(“http://payroll”, “frame2”);

open(“file: javascript: doEvil”, “frame2”)

Frame2: URL=http://payroll

Frame1: URL=http://evil


Exploiting function aliasing l.jpg

Exploiting Function Aliasing

(1) Set a timer in Frame2 to execute a statement after 1 second

(2) Frame2.location.assign

=window.location.assign

(3) Navigate Frame1 to http://payroll

After 1 second, execute:

“location.assign(‘

javascript:doEvil’)”

Frame1: URL=http://evil

Frame2: URL=http://evil

Frame1: URL=http://payroll


Exploiting the excessive expressiveness of frame navigation calls l.jpg

Exploiting the Excessive Expressiveness of Frame Navigation Calls

Frame1: URL=http://payroll

Frame2: URL=http://payroll

Frame0 executes a statement:

Frame2.open(“javascript:doEvil”,Frame1)

Frame0: URL=http://evil


Exploiting the semantics of user events l.jpg

Exploiting the Semantics of User Events

document.body.setCapture()

onClick() {

reference to the document in

Frame1 by event.srcElement

}

Frame1: URL=http://payroll

Frame0: URL=http://evil


What we learned from the attacks l.jpg

What we learned from the attacks

  • The causes

    • The SOP check is bypassed in some attack scenarios (the check may not be triggered)

    • The SOP check is a single-point check buried deep in the call stack

      • At the time of check, there are confusions of the domain-IDs.

  • Developers cannot anticipate all these scenarios.

    • Involving too many modules, too complex logic combinations


Implementation of script accenting mechanism l.jpg

Implementation of Script Accenting Mechanism


The implementation l.jpg

The implementation

  • Each domain D is assigned a random number as its accent key KD

  • The current implementation uses  (i.e., XOR)

    • To accent script S in domain D: S  KD

  • Two basic and easy rules in the implementation

    • Rule of script ownership

      • A script is owned by the frame that supplies the source code of the script, and should be accented at the time when its source code is supplied.

    • Rule of object ownership

      • Every object is owned by the frame that hosts the DOM tree of the object, and is always referenced by its accented name.


Accenting script source code l.jpg

Accenting Script Source Code


Accenting object name queries l.jpg

Accenting Object Name Queries


Evaluations l.jpg

Evaluations


Attack 1 revisited l.jpg

Attack 1 Revisited:

Windows ShellAddress Parser

Window Shell

javascript

Filename, not a javascript

javascript: doEvil

file: javascript: doEvil

IE

Frame2 = open(“http://payroll”, “frame2”);

open(“file: javascript: doEvil”, “frame2”)

Unrecognizable script code

Frame2: URL=http://payroll

Frame1: URL=http://evil


Attack 2 revisited l.jpg

Attack 2 Revisited

(1) Set a timer in Frame2 to execute a statement after 1 second

(2) Frame2.location.assign

=window.location.assign

(3) Navigate Frame1 to http://payroll

After 1 second, execute:

“location.assign(‘

javascript:doEvil’)”

Frame1: URL=http://evil

Frame2: URL=http://evil

Frame1: URL=http://payroll

The script is accented using evil’s key, but deaccented using payroll’s key


Attack 3 revisited l.jpg

Attack 3 Revisited

Frame1: URL=http://payroll

Frame2: URL=http://payroll

Frame0 executes a statement:

Frame2.open(“javascript:doEvil”,Frame1)

Frame0: URL=http://evil

The script is accented using evil’s key (Frame0), but deaccented using payroll’s key (Frame1)


Attack 4 revisited l.jpg

Attack 4 Revisited

document.body.setCapture()

onClick() {

reference to

event.srcElement

}

Frame1: URL=http://payroll

Frame0: URL=http://evil

Names of objects under srcElement are deaccented using payroll’s key.


Compatibility and performance l.jpg

Compatibility and Performance

  • Compatibility

    • Existing web applications do not need any changes. They can run normally without knowing the existence of the accenting mechanism.

  • Performance

    • The measurement about end-to-end browsing time did not show any noticeable slowdown.

      • (despite a 3.16% worst-case performance overhead)


Conclusions l.jpg

Conclusions

  • We studied previous browser-isolation bugs, and identified key challenges in eliminating these bugs.

  • We proposed the script accenting approach

    • Easy to reason about its correctness without understanding the complex logic of existing browser code base.

  • Evaluations show its comprehensive protection, compatibility with existing applications, and very small performance overhead.
