Presentation Transcript


No slide title

AquaZEL

High PerformanceFilter Media

CLEARLY THE BEST


No slide title

What is AquaZEL?

  • AquaZEL is manufactured from ‘clinoptilolite’, a premium natural zeolite mineral. Environmentally safe. AquaZEL is non toxic and does not involve the use of chemicals.

  • AquaZEL is a natural blotting paper due to its cage-like lattice structure, AquaZEL captures pollutants such as ammonium in an ion-exchange natural process.

Compare the complex natural structure of AquaZEL with that of smooth silica sand.

Sand Smooth

AquaZEL Porous


No slide title

The base material for the manufacture of AquaZELwas formed by volcanic activity over 300 million years ago.

For the technically minded it is a complex hydrated aluminosilicate mineral characterised by networks of pores that carry a negative charge balanced by exchangeable cations.

How was AquaZEL originally formed?

Crystal Structure for Clinoptilolite

  • This cage-like network of pores creates a very high surface area of around 20–30 square metres per gram, equivalent to the area of a football field per teaspoon.


No slide title

AquaZEL is processed and graded to a uniform standard to achieve optimum filtration performance

Rigorous QA/QC procedures ensure consistent product quality.

AquaZEL is packed in convenient25kg bags (equivalent in volume to 32kg sand)

How is AquaZEL made?


No slide title

Here’s how AquaZEL works

  • AquaZEL’s unique microscopic pores trap and hold larger quantities of contaminants, reducing backwashingand saving water.

  • Because of its lighter, porous structure, AquaZEL allows water to flow through more freely, so reducing system pressure.

  • AquaZEL’s unique ion-exchange process actually adsorbs positively charged ions, molecules and particles. As a result of this, an AquaZEL bed removes contaminants both by physical separation and by the chemical cation adsorption mechanism.


No slide title

AquaZEL OUTFILTERS SAND

USA Tests

AquaZEL°

DIATOMACEOUS EARTH (DE)*

FILTER MEDIA

SAND*

20

15

10

5

3

MICRONS

*NSW Swimming Pool Association

°USA Figures


No slide title

AquaZEL OUTFILTERS SAND

University of Adelaide Tests

AquaZEL°

DIATOMACEOUS EARTH (DE)*

FILTER MEDIA

SAND*

20

15

10

5

3

1

MICRONS

* NSW Swimming Pool Associati0n

º University of Adelaide Tests


No slide title

AquaZEL vs. Filter Sand

University Tests

  • Backwashed AquaZEL’s performance in capturing fine (small micron) particles is far superior to Filter Sand.Note: AquaZEL captured particles even below one micron at an efficiency of over 70%

  • AquaZEL performs more effectively than Filter Sand at higher concentrations of particulates (higher filter loadings)

  • AquaZEL filter backwashes particularly well (effectively) while Filter Sand does not recover nearly as well.


No slide title

Single auto Tank System


No slide title

Typical twin bank system for process water in a mine site


No slide title

Multi Bank Systems are available for Larger Jobs


No slide title

Australian Water Filter

CONTACTING US:-

Factory: 3 Doonan Trading Centre

Fellowship Road

DOONAN QLD 4562

PO Box 1196 NOOSAVILLE 4566

Jim Atkinson M.A.O.Q.C., Grad I.I.S. JP(Qual), Director Mobile 0419 499477

Peter Stuart Director Mobile 0412 715440

Phone 07 54491424 Fax 07 54491494

e-mail [email protected]

www.awf.net.au
