Presentation Transcript


Understanding corn processing co products use in livestock feeds

Understanding Corn Processing Co-products Use in Livestock Feeds

John D. Lawrence, Iowa State University

Darrell Mark, University of Nebraska


Outline

Outline

  • Trend in corn processing

  • Implications for corn prices

  • Cellulosic ethanol potential

  • Types of corn processing

  • Coproducts and nutritional values

  • Factors to consider before feeding

  • Summary


Us ethanol production june 2006

US Ethanol ProductionJune 2006

StatusPlantsB/Gal

  • Operational1024.75

  • Construction 323.03

  • Announced1278.21

  • Potential total26115.99

  • Potential corn use: 5.3-5.9 B/bu

  • Some estimates are higher

Source: National Corn Growers Association


Implications for corn prices

Implications for Corn Prices

  • Increased demand for corn is expected to:

    • Increase corn prices

    • Increase corn acres

  • Long run price impact will depend on

    • Price of oil and energy value of ethanol

    • Timing and cost efficiency of biomass to ethanol

    • Inclusion rates of co-product feeds in livestock diets

  • Short term price impact could be significant

    • Weather induced shortages

    • Mismatch of acres and ethanol plants


Biomass ethanol

Biomass Ethanol

  • Interest in low nitrogen using perennials

  • Switchgrass, wood, municipal waste and exotic plants like kanaf, crotalaria, etc.

  • Also can use corn stover and coproducts like distillers grains and corn gluten feed

  • May reduce demand and acreage of corn

  • Technology “5-years away”, but plant announced to operate in 2009


Two types of processing

Two Types of Processing

  • Wet mills

    • Very large and costly to construct

    • Multiple products

      • High Fructose Sweetener, corn oil, ethanol

      • Corn gluten meal, corn gluten feed and others

  • Dry mills

    • Generally smaller and less costly

    • Two products

      • Ethanol

      • Distillers grains and solubles


Wet milling corn gluten feed

Wet Milling-Corn Gluten Feed

STEEP

CORN

GRIND

WASH WATER

SEPARATION

STARCH, SWEETNER, ALCOHOL

GLUTEN MEAL

CORN OIL

STEEP

CORN BRAN

SEM, screenings, dist solubles

WET CORN GLUTEN FEED

DRY CORN GLUTEN FEED


Products of wet corn milling

Products of Wet Corn Milling

  • One bushel of corn yields

    ProductPounds

    • Starch31.5

      Further processed into 33# of sweetener

      or 2.5 gallons of ethanol.

    • Gluten feed 13.5

    • Gluten meal 2.5

    • Corn meal1.6


Corn gluten feed cgf

Corn Gluten Feed (CGF)

  • Corn bran + steep

  • Can be wet or dry

  • Moderate crude protein, CP = 16-23%

    • 80% of CP is DIP (ruminally degradable)

  • Low fat, moderate fiber, TDN = 80

  • 101-115% of energy value of dry-rolled corn

  • Product variation is significant within and across plants due to amount of steep added back to the corn bran

  • Looks like oatmeal


Dry milling distillers grains solubles

Dry Milling-Distillers Grains + Solubles

CORN

GRIND, WET, COOK

FERMENTATION

YEAST, ENZYMES

STILL

ALCOHOL & CO2

STILLAGE

DISTILLERS GRAINS

WDG, DDG

DISTILLERS SOLUBLES

WDGS

DDGS


Products of dry corn milling

Products of Dry Corn Milling

  • One bushel of corn yields

    • Ethanol 2.7 gallons

    • Distillers grains & solubles17-18 pounds

      • DGS are one third the weight of the corn and all but the starch is concentrated into this one-third

      • Sulfur is concentrated and may have been used in the fermenting process

      • Mycotoxins, if they existed in the corn are also concentrated 3:1


Distillers grains solubles dgs

Distillers Grains + Solubles (DGS)

  • About 65% Distillers Grains & 35% Solubles (DM basis)

  • May be wet or dried

  • Higher crude protein, CP = 30%

    • 65% UIP (undegraded, “bypass”, protein)

  • High fat (11%), low fiber, TDN = 70-110

  • Concentrates nutrients 3-fold from corn

    • 0.8% P, 0.35-1.0% Sulfur (variable)

  • WDGS looks like mashed potatoes


New combination products

New “Combination” Products

  • Modified wet DGS are available

    • (35-65% DM)

  • Hybrid wet & dry plant combining corn bran and distillers solubles  bran cake

    • Example: Dakota Bran Cake


Nutrient composition of selected corn milling co products

Nutrient Composition of Selected Corn Milling Co-Products


Factors to consider before feeding coproducts

Factors to Consider Before Feeding Coproducts

  • Nutrients only have value if needed

    • High protein or energy may not be needed

  • Abrupt changes may put animals off feed

  • Darker brown color indicates it may have been overheated, ties up lysine

  • Upper limits on inclusion rates for some livestock types and weights

  • Excess sulfur possible at high levels and high water levels of sulfur

  • Phosphorous concentration in manure


Factors to consider before feeding coproducts1

Factors to Consider Before Feeding Coproducts

  • Storage issues, dry product

    • Additional storage bin

    • Problems with flow ability in bulk bins

  • Storage issues, wet product

    • Wet product will spoil in 7-14 days depending on temperature and storage method

    • Wet product can freeze

    • Requires good bunk management


Challenges

Challenges

  • DGS is most available in late summer

    • Seasonally cheapest then too

    • Seasonally fewest cattle on feed then too

  • Storing wet DGS product

    • Material exposed to air spoils in 7-14 days depending on temperature

    • Has low pH and does not ensile but will keep in air-tight storage for long periods

    • Spoilage loss stored in silage bags (Walker et al)

      • 20% loss opened and fed day 78-112 post-sealing

      • 28% loss opened and fed day 190-257 post sealing


When wdgs price is lowest

When WDGS Price Is Lowest


Storing wdgs

Storing WDGS

  • Storing wet DGS product

    • Often delivered in truck load lots

    • Can store wet DGS in bunker, silage bag or in pile covered with plastic to protect from air

    • Should mix with tub-ground forage and stored in bunker or bag

    • Have to have the “mix” right…


Minimum levels of roughage to mix in wdgs for storage

Minimum Levels of Roughage To Mix in WDGS For Storage

BaggingaBunker

Grass hay15%30-40

Wheat straw12.525-32

Alfalfa hay22.545-55?

DDGS50---

ADMCGF60---

a300 PSI.

Source: Erickson & Klopfenstein


Summary

Summary

  • Increased corn demand and prices

    • Implications for crop acres and land prices

    • Higher feed cost pressures feeder animal price

    • Biomass may reduce need for corn, but also reduce coproduct supply

  • Often coproducts will reduce ration cost

  • Limits on maximum inclusion rates in diets

  • Technical issues with storages and handling


Resources

Resources

  • http://beef.unl.edu

  • www.iowabeefcenter.org

  • http://www.ddgs.umn.edu/
