Hope microelectronic company

HOPE Microelectronic Company

website: www.hoperf.com


Hope microelectronic company

HP203B

(1) Direct Output Reading: Pressure, Altitude, Temperature.

(2) Pressure range:300mbar~1200mbar.

(3) Programmable Events and Interrupt Controls.

(4) Altitude Resolution: 0.1meter.

(5) Pressure Resolution:0.01mbar.

(6) TemperatureResolution:0.01℃.

(7) Pressure Accuracy: +/-1.5mbar.

(8) High-speed I2C Digital Output Interface.

(9) Supply Voltage: 1.8V to 3.6V.

(10) Stand by current<0.1uA, low conversion power, 2uA at 1 sample/sec.

(11) Operation temperature:-40~85℃.

(12) Small Size: 3.6 mm X3.8 mm X1.2 mm.

website: www.hoperf.com


Hope microelectronic company

HP206C

(1) Direct Output Reading : Pressure, Altitude, Temperature.

(2) Pressure range: 300mbar~1200mbar.

(3) Programmable Events and Interrupt Controls.

(4) Altitude Resolution: 0.1 meter.

(5) Pressure Resolution: 0.01 mbar.

(6)TemperatureResolution:0.01℃.

(7) Pressure Accuracy: +/-1.0mbar.

(8) High-speed I2C Digital Output Interface.

(9)Supply Voltage: 1.8V to 3.6V.

(10)Standby current<0.1uA, low conversion power, 2uA at 1 sample/sec.

(11)Operation temperature:-40~85℃.

(12)Waterproof 100 meters.

(13)Wide application for the Altimeter, Barometer, Thermometer.

website: www.hoperf.com


Hope microelectronic company

Application

What is the application of HP203B,HP206C?

Weather forecast application

1. Small size with SMD and the port just need two IO.

2. Built-in compensation algorithm, application MCU does not need any calculation.

3. It has low average current.

website: www.hoperf.com


Hope microelectronic company

Application

What is the application of HP203B,HP206C?

GPS application

1. Small size with SMD and standard IIC port,

2. High precision altitude and relation altitude accuracy

is 20CM.

website: www.hoperf.com


Hope microelectronic company

Application

What is the application of HP203B,HP206C?

Smartwatch application

1. Use the Sensor and fitbit app for iPhone and Android to track steps, distance, calories, stairs climbed, active minutes, and sleep. Stay motivated with ongoing goal progress.

website: www.hoperf.com


Hope microelectronic company

Application

What is the application of HP203B,HP206C?

Model airplane application

Stabilize the altitude of the model airplane to proof the precision of set point control.

The speed of advance and lifting can be measured.

Light in weight.

website: www.hoperf.com


Hope microelectronic company

Application

What is the application of HP203B,HP206C?

Indoor navigation application

Through the change of relative altitude to provide the floor of the user.

Other sensor can’t provide the altitude directly, and it must be through the app. MCU to calculated, it has slightly inaccurate.

website: www.hoperf.com


Hope microelectronic company

Application

What is the application of HP203B,HP206C?

Elevator production application

It can measure the speed of the elevator in building and supermarket also it can provide the altitude change and relative altitude.

website: www.hoperf.com


Hope microelectronic company

Application

What is the application of HP203B,HP206C?

Sport watch application

The sensor read the data from IIC adopt pressure, altitude and temperature which are floating-point calculate included, it reduces the application of MCU resource and improve the battery service time.

website: www.hoperf.com


Hope microelectronic company

Application

What is the application of HP203B,HP206C?

Electronic consumptive product application

With sensor’s high integration that reduce the application of MCU resource.

The sensor can through SMT machine that reduces the costing of production’s system.

website: www.hoperf.com


Hope microelectronic company

Application

What is the application of HP203B,HP206C?

Fan application

Detecting the pressure of air intake and wine tunnel to adjust it and judge it normal or not.

Altimeter application

Lowest-power and can provide the accurate altitude.

website: www.hoperf.com


Hope microelectronic company

Hope Microelectronic Company

Thank you for your interest, if you want to have more information, please contact:TOP-electronics

+31 180 580 492

[email protected]
