  1. ACM-HK - CollegiateProgramming Contest (ACM-HK CPC) Tutorial 3 Data structures

  2. Data Structures Basic data types: Integral: integer, character, boolean Floating-point types: float, double, long double Data structures are methods of organizing large amounts of data. Array List, Stack, Queue, Dequeue Trees: binary tree, binary search tree, AVL tree Priority Queues Hash table Set Graph COMP1200: Data Structures and Algorithms

  3. Elementary Data Structures • Data type is a set of values and a collection of operations on those values • Basic data types in C and C++ • Integers (ints) • short int, int, long int, • Floating-point numbers (floats) • float, double • Characters (chars) • char • Structure in C and C++

  4. Example 1: Basic Data Types #include <iostream> #include <stdlib.h> #include <math.h> using namespace std; typedef int Number; Number randNum() { return rand(); } int main(int argc, char *argv[]) { int N = atoi(argv[1]); float m1 = 0.0, m2 = 0.0; for (int i = 0; i < N; i++) { Number x = randNum(); m1 += ((float)x) / N; m2 += ((float)x*x) / N; } cout << "RAND_MAX.: " << RAND_MAX << endl; cout << "Avg.:" << m1 << endl; cout << "Std. dev.: " << sqrt(m2 - m1 * m1) << endl; } This program computers the average and standard deviation of a sequence of integers generated by the library function rand( ). Question: how can you modity the program to handle a sequence of random floating-point numbers in the range of [0, 1]?

  5. Example 2: Structure /* return the distance between two points */ float mydistance(mypoint a, mypoint b) { float dx = a.x - b.x; float dy = a.y - b.y; return sqrt(dx*dx + dy*dy); } /* convert from Cartesian to polar coordinates */ mypolar (mypoint p, float *r, float *theta) { *r = sqrt(p.x*p.x + p.y*p.y); *theta = atan2(p.y, p.x); } #include <iostream> #include <stdlib.h> #include <math.h> using namespace std; struct mypoint { float x; float y; }; float mydistance(mypoint, mypoint); mypolar (mypoint, float *r, float *theta); int main(int argc, char *argv[]) { struct mypoint a, b; a.x = 1.0; a.y = 1.0; b.x = 4.0; b.y = 5.0; cout << " Distance is " << mydistance(a, b); float r, theta; mypolar(a, &r, &theta); cout << "r : " << r << endl; cout << “theta: " << theta << endl; } Result: Distance is 5 r : 1.41421 theta: 0.785398

  6. Arrays • Array is the most fundamental data structure • An array is a fixed collection of same-type data that are stored contiguously and are accessible by an index • It is the responsibility of the programmer to use indices that are nonnegative and smaller than the array size • Two ways to create an array • Static allocation: size known to and set by the programmer • Dynamic allocation: size unknown to the programmer and set by the user at the execution time

  7. Example: Sieve of Eratosthenes #include <iostream> using namespace std; static const int N = 1000; int main( ) { int i, a[N]; /* initialization */ for (i = 2; i < N; i++) a[i] = 1; for (i = 2; i < N; i++) if (a[i] ) /* sieve i’s multiples up to N-1*/ for(int j = i; j*i < N; j++) a[i*j] = 0; for (i = 2; i < N; i++) if (a[i]) cout << " " << i; cout << endl; } Sieve of Eratosthenes is a classical method to calculate the table of prime numbers. Basic idea: Set a[i] to 1 if i is prime, and 0 if i is not a prime.

  8. Dynamic Memory Allocation int main(int argc, char *argv[]) { int N = atoi(argv[1]); int *a = new int[N]; if (a == 0) { cout << “out of memory " << endl; return 0; } … delete [] a; } • C language • malloc( ) and free( ) • C++ language • use operator new and operator delete

  9. Array of Structures /* return the distance between two points */ float mydistance(mypoint a, mypoint b) { float dx = a.x - b.x; float dy = a.y - b.y; return sqrt(dx*dx + dy*dy); } /* return a random number between 0 and 1 */ float randfloat( ) { return 1.0 * rand() / RAND_MAX; } #include <iostream> #include <stdlib.h> #include <math.h> using namespace std; struct mypoint { float x; float y; }; float mydistance(mypoint, mypoint); float randfloat( ); int main(int argc, char *argv[]) { float d = atof(argv[2]); int i, cnt = 0, N = atoi(argv[1]); mypoint *a = new mypoint[N]; for( i = 0; i < N; i++) { a[i].x = randfloat(); a[i].y = randfloat(); } for( i = 0; i < N; i++) for(int j = i+1; j < N; j++) if (mydistance(a[i], a[j]) < d) cnt++; cout << cnt << " pairs within " << d << endl; delete [] a; } This program calculates the number of pair of points whose distance is shorter than a threshold.

  10. List A general list of elements: A1, A2, …, AN, associated with a set of operations: Insert: add an element Delete: remove an element Find: find the position of an element (search) FindKth: find the kth element Each element has a fixed position Two different implementations: Array-based list Linked list

  11. List Linked list: Linked list with a header: Doubly linked list:

  12. Sample C Implementation of Linked List with a Header • Header files: • tutorial3-code/fatal.h • tutorial3-code/list.h • Source file: • tutorial3-code/list.c

  13. Circular List Example • Josephus problem: N people decided to elect a leader as follows: • Arrange themselves in a circle • Eliminate every Mth person around the circle • The last remaining person will be the leader

  14. Simulation of Josephus problem int main(int argc, char *argv[]) { int i, N = atoi(argv[1]), M = atoi(argv[2]); /* create the first node */ mylink t = new mynode(1, 0); t->next = t; mylink x = t; /* insert the next N-1 nodes */ for( i = 2; i <= N; i++) x = (x->next = new mynode(i, t)); /* simulate the election process */ while (x != x->next) { for (i = 1; i < M; i++) x = x->next; /* delete the next node */ t = x-> next; x->next = t->next; delete t; } cout << x->item << endl; } #include <iostream> #include <stdlib.h> using namespace std; struct mynode { int item; mynode* next; /* constructor */ mynode(int x, mynode* t) { item = x; next = t; } }; typedef mynode *mylink;

  15. Stacks A stack is a list with the restriction that insertions and deletions can be performed at the end of the list, called the top. LIFO: last in, first out Operations: Push(x, s) Pop(s) MakeEmpty(s) IsEmpty(s) Top(s)

  16. Stack Implementations • Using a linked list • tutorial3-code/stackli.h • tutorial3-code/stackli.c • Using an array • tutorial3-code/stackar.h • tutorial3-code/stackar.c • Remark: you need to define the maximum stack size when creating the stack

  17. Queues A Queue is a list with the restriction that insertion is done at one end, whereas deletion is done at the other end. FIFO: first in, first out Operations: CreateQueue(x): create a queue with maximum size of x Enqueue(x, q): insert an element x at the end of the list Dequeue(q): return and remove the element at the start of the list IsEmpty(q) and IsFull(q)

  18. Queue Implementation • Implemented by a circular array • Need to specify the maximum size of the queue when creating the queue • One variable for the front of the queue, another one for the rear of the queue • Sample code • tutorial3-code/queue.h • tutorial3-code/queue.c

  19. Priority Queues A priority queue is a data structure that allows the following operations: Insert(x, p): insert item x into priority queue p Maximum(p): return the item with the highest priority in priority queue p ExtractMax(p): return and remove the item with the highest priority in p Note: Each element contains a key which represents its priority

  20. Sets A set is a collection of unordered elements drawn from a given universal set U. Operations: Member(x, S): is an item x an element of set S? Union(A, B) Intersection(A, B) Insert(x, S) Delete(x, S)

  21. Dictionaries Dictionaries permit content-based retrieval. Operations: Insert(x, d) Delete(x, d) Search(k, d): return an item with key k Note Dictionaries can be implemented by lots of techniques, like linked list, array, tree, hashing, etc.

  22. C++ Standard Template Library The C++ STL provides implementations of lots of data structures Reference: http://www.sgi.com/tech/stl/ http://www.cppreference.com/ Data structures: (Containers in C++) Sequential containers (see Workshop 7) Vectors, Lists, Double-ended Queues Associative containers (see Workshop 7) Sets, Multisets, Maps, Multimaps Container adaptors Stacks, Queues, Priority Queues

  23. List in C++ • List is implemented as a doubly linked list of elements • Each element in a list has its own segment of memory and refers to its predecessor and its successor • Disadvantage: Lists do not provide random access. General access to an arbitrary element takes linear time. • Hence lists don’t support the [ ] operator • Advantage: insertion or removal of an element is fast at any position • http://www.cplusplus.com/reference/stl/list/

  24. List Example 1 // list1.cpp #include <iostream> #include <list> using namespace std; int main() { list<char> coll; for (charc = 'a'; c <= 'z'; ++c) coll.push_back(c); while (! coll.empty() ) { cout << coll.front() << ' '; coll.pop_front(); } cout << endl; return 0; } $ g++ list1.cpp $ ./a.out a b c d e f g h i j k l m n o p q r s t u v w x y z $ 24

  25. List Example 2 // list2.cpp #include <iostream> #include <list> using namespace std; int main() { list<char> coll; for (char c='a'; c<='z'; ++c) coll.push_back(c); list<char>::const_iterator pos; for (pos = coll.begin(); pos != coll.end(); ++pos) cout << *pos << ' '; cout << endl; } $ g++ list2.cpp $ ./a.out a b c d e f g h i j k l m n o p q r s t u v w x y z $ 25

  26. List Example 3 // list3.cpp #include <iostream> #include <list> using namespace std; int main() { list<char> coll; for (char c='a'; c<='z'; ++c) coll.push_back(c); list<char>::iterator pos; for (pos = coll.begin(); pos != coll.end(); ++pos) { *pos = toupper(*pos); cout << *pos << ' '; } cout << endl; } 26

  27. Stack in C++ push(): insert an element pop(): remove the first element top(): access the first element size(): return the number of elements empty(): check whether the container is empty Remark: pop() will remove the first element and return nothing. So usually we need to call top() to get the first element, then call pop() to remove it. // stack.cpp #include <iostream> #include <stack> using namespace std; int main() { stack<int> s; for (int i=1; i<=10; ++i) s.push(i); while( !s.empty() ) { cout << s.top() << endl; s.pop(); } return 0; }

  28. Queue in C++ push(): insert an element pop(): remove the first element front(): access the first element back(): access the last element size(): return the number of elements empty(): check whether the container is empty // queue.cpp #include <iostream> #include <queue> using namespace std; int main() { queue<int> s; for (int i=1; i<=10; ++i) s.push(i); while( !s.empty() ) { cout << s.front() << endl; s.pop(); } return 0; }

  29. Queue Example II // queue2.cpp #include <iostream> #include <queue> #include <string> using namespace std; int main() { queue<string> q; q.push(“These “); q.push(“are “); q.push(“more than “); cout << q.front(); q.pop(); cout << q.front(); q.pop(); q.push(“four “); q.push(“words!“); // skip one element q.pop(); cout << q.front(); q.pop(); cout << q.front(): q.pop(); cout << “number of elements in the queue: “ << q.size() << endl; return 0; }

  30. Priority Queue in C++ push(): insert an element pop(): remove the element with the highest priority top(): access the element with the highest priority size(): return the number of elements empty(): check whether the container is empty By default, elements are sorted by operator < in descending order, i.e., the largest element has the highest priority. // pqueue.cpp #include <iostream> #include <queue> using namespace std; int main() { priority_queue<int> s; s.push(5); s.push(4); s.push(8); s.push(9); s.push(2); s.push(7); s.push(6); s.push(3); s.push(10); while( !s.empty() ) { cout << s.top() << endl; s.pop(); } return 0; }

  31. Different Sorting Criterion // pqueue.cpp #include <iostream> #include <queue> using namespace std; int main() { priority_queue<int, vector<int>, greater<int> > s; s.push(5); s.push(4); s.push(8); s.push(9); s.push(2); s.push(7); s.push(6); s.push(3); s.push(10); while( !s.empty() ) { cout << s.top() << endl; s.pop(); } return 0; } Three parameters when defining a priority queue: int: type of element vector<int>: the container that is used internally greater<int>: the sorting criteria (by default, it is less<>)

  32. Java java.util package http://java.sun.com/products/jdk http://java.sun.com/j2se/1.4.2/docs/api/java/util/package-summary.html Stack Stack Queue ArrayList, LinkedList Dictionaries HashMap, hashtable Priority Queue TreeMap Sets HashSet

  33. What to do now? Choose your own weapon C: write a set of data structure C++: learn the STL Java: learn the java.util package Try to solve at least one exercise If you still have time, solve more exercises.

  34. Practice http://acm.uva.es/p/v100/10038.html http://acm.uva.es/p/v100/10044.html http://acm.uva.es/p/v100/10050.html http://acm.uva.es/p/v101/10149.html http://acm.uva.es/p/v102/10205.html http://acm.uva.es/p/v102/10258.html http://acm.uva.es/p/v103/10315.html http://acm.uva.es/p/v8/843.html
