1. Management of cardiovascular system
2. On completion of this chapter, the learner will be able to:
1. Describe the pathophysiology, clinical manifestations, and treatment of coronary atherosclerosis.
2. Describe the pathophysiology, clinical manifestations, and treatment of angina pectoris.
3. Use the nursing process as a framework for care of patients with angina pectoris.
4. Describe the pathophysiology, clinical manifestations, and treatment of myocardial infarction.
5. Use the nursing process as a framework for care of patients with myocardial infarction (acute coronary syndrome).
6. Describe the nursing care of a patient who has had an invasive interventional procedure for treatment of coronary artery disease.
7. Describe coronary artery revascularization procedures.
8. Describe the nursing care of the patient treated with cardiac surgery.
3. Anatomy of the Heart
4. Assessment of Cardiovascular Function - Cardiac output: Amount of blood pumped by each ventricle in liters per minute.
* Normal cardiac output 5L/min in resting.
- Stroke volume: Is the amount of blood ejected per heart beat.
* The average stroke volume is about 70 ml.
Cardiac output = Stroke volume x Heart beat.
= 70 ml X (60-80) b/min.
5. Control of stroke volume: - Stroke volume: Is primarily determined by three factors:
Preload: It’s the degree of stretch of cardiac muscle fibers at end of diastole.
Afterload: The pressure the ventricular myocardium must overcome to eject blood during systole.
Contractility: is a term used to denote the force generating by contracting myocardium under any given condition.
6. I-Assessment: 1- Health history and clinical manifestation:
* Cardiac Symptoms:
- Chest discomfort.
-Shortness of breath or Dyspnea.
- Edema and weight gain.
- Palpitation (dysarrythmias).
- Dizziness and syncope.
7. I-Assessment: 2- Nutrition and metabolism:
Diets that are restricted in sodium, fat, cholesterol, and calories.
3- Activity and Exercise:
If symptoms develop during exercise, what are nature of exercise.
8. I-Assessment: 4- Physical examination:
-The examination, which proceeds logically from head to toe can
be performed in about 10 min.
a- General appearance:
- The nurse observes the patients level of consciousness, and thought process as an indication of the hearts ability to
propel oxygen to the brain.
b- Inspection of skin:
Pallor, cyanosis, Temp, reduce skin turgor, wounds.
c- Blood Pressure.
d- Arterial pulses:
Pulse rate, rhythm, and volume.
9. II- Cardiac Auscultation: Heart Sounds:
The normal heart sounds, S1, S2, are produced primarily by the closing of the heart values.
a- S1= Closure of mitral and tricuspid valves.
b- S2= Closure of aortic and pulmonic valves.
10. II- Cardiac Auscultation: c- Gallop:
S3: Occurring during rapid ventricle filling is impeded during diastole. e.g MI, CHF.
S4: When the ventricle is enlarged or hypertrophied and therefore resistant to filling. e.g. CAD, aortic stenosis.
Note: S4 heard by bell of stethoscope only, they are heard best at
Are created by the turbulent flow of blood, the causes
turbulence may be a critically narrowed valve or regurgitation of valves.
11. III- Diagnostic Evaluation: 1- Laboratory Tests:
e.g Cardiac enzyme , blood chemistry (urea, creatinine,
serum electrolyte, coagulation studies, lipid profile.)
2- Chest x-ray and fluoroscopy.
3- Cardiac stress test:
To detect the ischemia, by increasing the metabolic demands for oxygen.
Is non invasive ultrasound test used to examine the size, shape and motion of cardiac structures.
5- Cardiac Catheterization:
Is an invasive diagnostic procedure in which radiopaque
arterial and venous catheters are introduced into selected blood vessels of the right and left sides of the heart.
12. III- Diagnostic Evaluation:
6-Electro cardiography. (ECG)
Normal Components of the EKG Waveform
13. Normal Components of the EKG Waveform P wave
Indicates atrial depolarization, or contraction of the atrium.
Normal duration is not longer than 0.11 seconds (less than 3 small squares)
Indicates ventricular depolarization, or contraction of the ventricles.
Normally not longer than .10 seconds in duration
Indicates ventricular repolarization
Indicates early ventricular repolarization
Indicates AV conduction time
Duration time is 0.12 to 0.20 seconds
14. Management of Patient with Coronary Vascular Disease Coronary Artery Disease:
The most prevalent type of cardiovascular disease is coronary artery disease (CAD).
Is an abnormal accumulation of lipid , or fatty substances and fibrous tissue in the vessel wall.
Atheroma: Begins as fatty streaks, lipids that are deposite on the intima of the arterial wall.
15. Management of Patient with Coronary Vascular Disease Risk factors for (CAD):
Non modifiable risk factors:
* Family history.
* Increasing age.
Modifiable risk factors:
* High blood cholesterol. * Obesity.
* Smoking. * Stress.
* Diabetes mellitus.
16. Management of Patient with Coronary Vascular Disease Angina Pectoris:
Is a clinical syndrome usually characterized by episodes or paroxysm of pain or pressure in the anterior chest, the cause is usually insufficient coronary blood flow.
- Factors those are associated with a typical angina pain:
* Physical exertion.
* Exposure to cold.
* Eating a heavy meal.
* Stress or any emotion- provoking situation.
17. Angina: Pathophysiology • Temporary and reversible> partial occlusion, spasm, or thrombus
• Cells deprived of oxygen
• Cell membranes release histamines, kinins,specific enzymes stimulating nerve fibers in cardiac muscle that send pain impulses to CNS
• Pain radiates to upper body
• <30 minutes ischemia: adequate nutrients/oxygen
clears waste products
• > 30 minutes ischemia: irreversible damage
18. Angina Types: • Stable Angina
– Most common and predictable; occurs with predictable amount of activity or stress
– Occurs when work of heart is increased by physical exertion, exposure to cold, stress
– Relieved by rest and nitrates
• Prinzmetal’s (variant)
– Atypical angina occurs unpredictability; not related to activity and often at night
– Caused by spasm of coronary artery with or without atherosclerotic lesion
19. Angina Types: • Unstable Angina
– Occurs with increasing frequency, severity, duration
– Pain is unpredictable and occurs with rest, low activity, stress
– At risk for myocardial infarction
• Silent Angina
– Asymptomatic ischemia, thought to very common with CHD
– May occur with activity or mental stress
20. Angina Pectoris: Clinical Manifestation:
* Chest pain. (Retrosternal pain).
* Weakness or numbness in the arms.
* Shortness of breath.
* Pallor, diaphoresis, dizziness or
* Nausea, Vomiting.
21. Medical Management: 1-Pharmacologic Therapy:
a-Nitroglycerine: To decrease workload of the heart, and
coronary artery vasodilation.
b- Beta-adrenergic blocking agents: Such as propranolol (Inderal),and atenolol(tenormine).To decrease heart rate,
blood pressure and myocardium contractility.
c- Calcium channel blocking agents: Such as nipedipia, verpamil, and diltiazem.To decrease heart rate, decrease workload of heart, and increase coronary artery perfusion.
d-Antiplatlates and anticoagulant medication.
* Aspirin prevent platelets aggregation.
* Heparin prevents the formation of new blood clots.
22. Medical Management: 2- Invasive intervention and surgical management:
a- Percautanouse transluminal coronary angioplasty (PTCA).
b- Coronary artery stent.
d- Coronary artery bypass graft. (CABG).
23. Myocardial Infarction:
Definition: Is a death of heart tissue caused by prolonging ischemia.
- Necrosis of myocardial cells; life-threatening event
– Loss of functional myocardium affects heart’s ability to maintain effective cardiac output
– AMI and other ischemic heart diseases cause majority of deaths
– Majority of AMI deaths occur during initial period post symptoms: 60% within first hour, 40% prior to hospitalization
24. MI: Pathophysiology •
Develops from atherosclerotic plaques in coronary arteries
• Occurs when blood flow blocked>prolonged tissue ischemia and irreversible cell damage
• Prolonged ischemia> irreversible damage
• Cellular metabolism shifts from aerobic to anaerobic metabolism producing hydrogen ions and lactic acid
• Dysrhythmias and decreased myocardial contractility cause decreased stroke volume, cardiac output, blood pressure
and tissue perfusion
25. MI: Pathophysiology • Areas of heart
– Particular coronary artery occluded determines area of damage
– The specific infarct site predicts possible complications and dictates appropriate therapy
– Specific artery and affected area of heart
• Left anterior descending artery: anterior wall of left ventricle and part of interventricularseptum
• Left circumflex artery: lateral MI
• Right coronary artery: right ventricle, inferior and posterior infarct
• Left main coronary artery: entire left ventricle
26. Myocardial Infarction: Clinical Manifestation:
* Sudden chest pain.
* Nausea and vomiting.
* Cool, pale.
* Laboratory test. eg. Cardiac enzyme
27. Medical Management: The goal of medical management is to minimize myocardial damage, preserve myocardial function and prevent complication.
a- Emergent PTCA or stent.
b- Pharmacological therapy.e.g thrombolytics: the purpose is to dissolve and lyses the thrombus in coronary artery. (Reperfusion)
e.g. TPA (Tissue plasminogen activate), Streptokinase.
d- Oxygen administration.
28. Myocardial Infarction: Nursing intervention:
* Relieving chest pain.
* Improving respiratory function.
* Promoting adequate tissueperfusion.
* Reducing anxiety.
* Managing and monitoring potential
29. Management of Patients With Complications From Heart Disease LEARNING OBJECTIVES
On completion of this chapter, the learner will be able to:
1. Describe the management of patients with chronic heart failure.
2. Use the nursing process as a framework for care of patients with heart failure.
3. Describe the management of patients with acute heart failure.
4. Develop teaching plans for patients with heart failure.
5. Describe the management of patients with cardiogenic shock.
6. Describe the management of patients with thromboembolic episodes, pericardial effusion and cardiac tamponade, and myocardial rupture.
7. Demonstrate the techniques of cardiopulmonary resuscitation.
30. Cardiac Failure: Congestive heart failure :( CHF) Referred to as a cardiac failure, is the inability of the heart to pump sufficient blood to meet the needs of the tissue for
oxygen and nutrient.
- The term “congestive heart failure” is most commonly used
when referring to Lt- sided and right-sided heart failure.
- Cardiac failure commonly occurs with disorders of cardiac
muscle that result in decrease contractile properties of the
heart, lead to decrease myocardial contractility include.
Myocardial dysfunction (especially from coronary
atherosclerosis), arterial hypertension, and valvular
31. Left –Sided Cardiac failure:
Pulmonary congestion occurs when the left ventricle cannot pump the blood out of the chamber. This increase pressure in the left ventricle and decrease the blood flow from the left atrium. The pressure in the left atrium increase, which decrease the blood flow coming from the pulmonary vessels. The result increase in pressure in the pulmonary circulation forces fluid into the pulmonary tissue and alveoli.
Sings & Symptoms:
* Dyspnea on exertion. * Pulmonary Crackles.
* Orthopnea. * Restlessness and anxiety.
* Cough. * Tachycardia.
32. Right sided heart failure:
The right side of the heart cannot eject blood, and thus can not accommodate all the blood that normally returns to it from the venous circulation.
Sings & Symptoms;
* Edema of the lower extremities.
* Wight gain.
* Hepatomegally (enlargement of the liver).
* Distended neck vein.
* Ascites (an accumulation of fluid in the peritoneal cavity).
* Anorexia and nausea.
* Pitting edema.
33. Heart Failure Diagnostics: • Electrolytes.
• UA, BUN, creatinine
34. Hemodynamic Monitoring • Intra-arterial pressure (art line; a line)
Direct and continuous monitoring of systolic,
diastolic, mean arterial pressure; arterial blood
• Central venous pressure (CVP)
Measures blood volume/venous return; reflects
right heart filling pressures
• Pulmonary artery pressure (PA; Swan-Ganz
Evaluate left ventricular and overall cardiac
35. Medical Management:
The basic objectives in treating patients with congestive heart failure are the following:
* Reducing the workload on the heart.
* Increasing the force and efficiency of myocardial contraction.
a-ACE (Angiotinsin converted enzyme) inhibitors:
ACE inhibitors promote vasodilation and diuresis by decreasing afterload and preload, they decrease the work load of the heart.
c-Digitalis. The most commonly prescribed forms of digitalis for patients with CHF are digoxin (lanoxine) and digotoxin.
- The medication increases the force of myocardial
contraction and slows conduction through the AVnode.
d- Dobutamine (dobutrex):
It stimulates the beta1-adrenergic receptor, and its major
action to increase cardiac contractility.
e- Other Medication. e.g Anticoagulant, Beta-adrenergic blockers (propranolol,atenolol)
Is an abnormal widening or ballooning of apportion of a blood vessel, the blood vessel wall becomes weaker in this location.
Causes and Risks:
* Aneurysms are either congenital or acquired.
* Atherosclerosis disease.
* Pregnency, associated with formation and or rupture
of splenic artery aneurysms.
Signs & Symptoms:
* Swelling with a pulsatile (throbbing) mass at site of
aneurysms are often seen.
* In case of rupture, hypotesion, high heart rate and
light headedness are seen; the risk of death from
rupture is high.
38. Aneurysm: Sings and Tests:
* Physical Examination.
* Ultrasound Examination.
* CT-scan. (Abdomen).
* Surgical excision is generally recommended.
39. Management of Patients With Structural, Infectious, and Inflammatory Cardiac Disorders On completion of this chapter, the learner will be able to:
1. Define valvular disorders of the heart and describe the pathophysiology, clinical manifestations, and management of patients
with mitral and aortic disorders.
2. Describe types of cardiac valve repair and replacement procedures used to treat valvular problems and the care needed by patients who undergo these procedures.
3. Describe the pathophysiology, clinical manifestations, and management of patients with cardiomyopathies.
4. Describe the pathophysiology, clinical manifestations, and management of patients with infections of the heart.
5. Describe the rationale for prophylactic antibiotic therapy for patients with mitral valve prolapse, valvular heart disease, rheumatic endocarditis, infective endocarditis, and myocarditis.
40. Infectious Disease of the Heart: Rheumatic Endocarditic:
- It is results directly from rheumatic fever caused by group A
- The disease affects all bony joint, producing polyarthritis; the
heart is also a target organ and is where the most serious
- Rheumatic endocarditis are not infectious in origin rather they
represent reaction occurring in response to hemolytic streptococci, Leukocytes accumulate in the affected tissue and
forms nodules, which are replaced by scars, gradually thicker
than normal and preventing them from closing completely
result in leakage, a condition called valvular regurgitation.
- The most common site of valvular regurgitation is the mitral
41. Rheumatic Endocarditic:
Prevention and Treatment:
- Early and adequate treatment of streptococcal infections.
- Long term antibiotic therapy is the treatment of choice.
- Penicillin administered parentally remains the medication of choice.
42. Infectious Disease of the Heart:
Is an inflammation process involving the myocardium.
- Myocarditis can cause heart dilatation, thrombi on the heart wall.
- Antibiotic Therapy (penicillin).
- Same used for congestive heart failure.
Refers to an inflammation of the pericardium, the membrane
sac enveloping the heart.
- Sever pain may be felt beneath the clavicle and in the neck
and left scapular region. Pericardial pain is aggravated by breathing.
- Antibiotic therapy.
- Analgesic and NSAID. e.g indomethacin(indocin).
Regurgitation: blood flow backward through the valve. (valve do not close completely).
Prolapse: stretching the valve leaflet into the atrium during systole.
Stenosis: narrowing or obstruction of a cardiac valve’s orifice.
Medical Management :
*Valve replacement VALVUALR HEART DISEASE
44. Cardiomyopathies Is a heart muscle disease associated with cardiac dysfunction.
Dilated cardiomyopathy (dilation of the ventricles)
Hypertrophic cardiomyopathy (increase in size and mass of heart muscle)
Restrictive cardiomyopathy (diastolic dysfunction caused by rigid ventricular walls)
45. Medical Management Heart transplantation
Mechanical assistive devices
46. Assessment and Management of Patients With Hypertension LEARNING OBJECTIVES ?
On completion of this chapter, the learner will be able to:
1. Define blood pressure and identify risk factors for hypertension.
2. Explain the difference between normal blood pressure and hypertension and discuss the significance of hypertension.
3. Describe the treatment approach for hypertension, including lifestyle changes and medication therapy.
4. Use the nursing process as a framework for care of the patient with hypertension.
5. Describe the necessity for immediate treatment of hypertensive
It is a systolic blood pressure greater than 140 mmHg and a diastolic pressure 90 mmHg based on average two or more readings
Primary Hypertension (essential hypertension): high blood pressure of unidentified cause
Secondary Hypertension: high blood pressure from an identified cause
48. Identifiable causes of hypertension Sleep apnea
Drug induced or related causes
Chronic kidney disease
49. Clinical manifestation Often no signs and symptoms
Late signs are retinal hemorrhages, arteriolar narrowing, cotton-wool spots, papilledema
Pathological changes include coronary artery disease, kidney damage, and cerebrovascular involvement
50. Lifestyle modification to manage Hypertension Weight reduction
Dietary sodium reduction
Moderation of alcohol consumption
51. Medical Management
Goal is to achieve BP 140/90 mm Hg. or lower
Pharmacologic therapy includes: diuretics, beta-blockers, or both
52. Hypertensive Crises
Hypertensive Emergency- BP must be lowered immediately to prevent damage to target organs. E.g. MI, ICH, Aortic aneurysm
Hypertensive Urgency- BP must be lowered within a few hours.
53. Vascular Disorders and Problems of Peripheral Circulation Pump failure
Alterations in blood and lymphatic vessels
Circulatory insufficiency of the extremities
54. Health history and clinical manifestations Intermittent claudication
Rubor, loss of hair, dry skin, ulcerations, and edema
55. Diagnostic Evaluation
Doppler Ultrasound Flow Studies
Computed Tomography and Angiography
Magnetic Resonance Angiography
56. Arterial disorders
Arteriosclerosis: hardening of arteries
Prevention by dietary modifications and exercise to reduce lipid levels
57. Peripheral Arterial Occlusive Disease
Legs are most frequently affected
Hallmark symptom is intermittent claudication
Pharmacologic therapy is to increase RBC flexibility, reduce blood viscosity, inhibit platelet aggregation, inhibit smooth muscle cell proliferation, and increase vasodilation
Surgical management includes vascular grafting or endarterectomy
58. Arterial Embolism and Arterial Thrombosis
Acute vascular occlusion may be caused by trauma or result of invasive interventions
Arterial emboli most often caused by atrial fibrillation, MI, or other heart dysfunction
Medical management is anticoagulation
Surgical management is emergency embolectomy
59. Venous Disorders
I- Varicose Veins:
Are abnormally dilated, tortuous, superficial veins caused by incompetent venous valves.
- In normal veins, valves in the veins keep blood moving
forward toward the heart. With varicose veins, the
valves do not function properly, allowing blood to
remain in vein.
- This process usually occurs in lower extremities (saphenous veins, it can occur else where in the body. e.g. esophageal varices.
60. I- Varicose Veins: Causes:
* Prolong standing.
* A hereditary weakness of vein wall.
* Increasing the pressure within abdomen.
* Dull aches.
* Muscle cramps.
* Increase muscle fatigue.
* Ankle edema.
* Surgery for varicose vein.
61. Venous Disorders
II- Chronic Venous Insufficiency:
Is a condition in which the veins do not efficiently return blood from the lower limbs back to the heart.
- Venous insufficiently involves one or more veins.
- The valves in the vein usually channel the flow
of blood toward the heart .When these are
damaged, the blood leaks and pools in the legs
62. Chronic Venous Insufficiency: - Clinical Manifestation:
* Alterd pigmentation.
* Stasis dermatitis.
- Medical and Nursing Management:
* Elevating the legs.
* Walking should be encouraged.
* Compression of the legs with elastic pressure stocking.
63. Venous Disorders III- Thrombophlebitis:
Is vein inflammation related to a blood clot.
* Local irritation. e.g. IV line.
* Infection in or near vein.
* Tenderness over the vein.
* Pain in the part of the body affected.
* Skin redness.
* Non steroidal anti-inflammatory drugs (NSADs).
