第 8 章 信号发生器

第 8 章 信号发生器. 8.4 测量结果的表示及有效数字的处理. 8.4.1 测量结果的表示 测量结果一般以数字方式或图形方式表示。图形方式可以在测量仪器的显示屏上直接显示出来,也可以通过对数据进行描点作图得到。测量结果的数字表示方法有以下几种: 1 .测量值 + 不确定度。 2 .有效数字 3 .有效数字 + ( 1 ~ 2 )位的安全数字。 上述方法表示出的结果是测量报告值。 8.4.2 有效数字的处理 有效数字的处理包括有效数字位数的取舍及有效数字的舍入。 1. 有效数字及其位数的取舍 2. 数字修约规则 “ 四舍六入五留双 ” 。

cora-briggs
Download Presentation

第 8 章 信号发生器

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. 第8章 信号发生器

  2. 8.4测量结果的表示及有效数字的处理 8.4.1 测量结果的表示 测量结果一般以数字方式或图形方式表示。图形方式可以在测量仪器的显示屏上直接显示出来,也可以通过对数据进行描点作图得到。测量结果的数字表示方法有以下几种: 1.测量值+不确定度。 2.有效数字 3.有效数字+(1~2)位的安全数字。 上述方法表示出的结果是测量报告值。 8.4.2 有效数字的处理 有效数字的处理包括有效数字位数的取舍及有效数字的舍入。 1.有效数字及其位数的取舍 2.数字修约规则 “四舍六入五留双”。 具体的做法是,当尾数≤4时将其舍去;尾数≥6时就进一位;如果尾数为5而后面的数为0时则看前方:前方为奇数就进位,前方为偶数则舍去;当“5”后面还有不是0的任何数时,都须向前进一位,无论前方是奇还是偶数,“0”则以偶数论。 0.53664→0.5366 0.58346→0.5835 10.2750→10.28 16.4050→16.40 27.1850→27.18 11.06501→11.07 必须注意:进行数字修约时只能一次修约到指定的位数,不能数次修约,否则会得出名正错误的结果。
