Tamino Technical Overview

1. May 2, 2012 Tamino Technical Overview John Fitzgerald Business Integration Technologist

2. Agenda Introductions Tamino Introduction and Overview What is Tamino? Tamino Server Architecture Search and Retrieval Document Management Enterprise Class Features APIs and Tools Demo What you can do Today!

3. What is Tamino? Storage system (DBMS) for ... Semi-structured data XML documents, messages, metadata Stores in native XML format Multiple indexing methods Unstructured data Storage and indexing of non-XML objects Images, video, audio, MS Office files, PDF.. Major Differentiators: Robust & complete for mission-critical enterprise use Built-in Internet File System Superior XML-aware searching Comprehensive developer support Available for offline use

4. Why Use Tamino? Businesses use Tamino � For lowest TCO on managing XML and unstructured data Store, find, re-compose, present multi-channel Repurpose to save cost, time & resources To increase development productivity Faster through standards, many APIs & tools Less efforts to adapt to changes To avoid vendor lock-in through open standards Access 'all areas' via XQuery Fit for SOA - eg. UDDI, SOAP For investment protection and mission-critical use Provide secure & trusted access to existing back-end data Deliver robust operation and protect against business outages

5. Tamino in Action Today Approx. 700 customers worldwide Vodafone Electronic Billing (> 1 Terabyte) RTL Highly available news editorial system providing information for TV, news broadcasters Juris � German Legislation XML-based document management system (~600.000 documents) Commerzbank Rule-based transfer of all trading transactions to a standardized view (financial products) Daimler Chrysler Consistent management of all car testing and diagnostics information & fleet management HellerBank Automated handling of monthly reports across multiple channels Vodafone Electronic Billing (> 1 Terabyte) RTL Highly available news editorial system providing information for TV, news broadcasters Juris � German Legislation XML-based document management system (~600.000 documents) Commerzbank Rule-based transfer of all trading transactions to a standardized view (financial products) Daimler Chrysler Consistent management of all car testing and diagnostics information & fleet management HellerBank Automated handling of monthly reports across multiple channels

6. Tamino XML Server Architecture

7. Tamino XML Data Store

8. Tamino Data Map

9. XML Schema Support Complete Support for XML Schema 1.0 Specification Industry Schema Support: Docbook 4.4FpML 4.1METS 1.0NewsML 1.2SVG 1.0UBLVoiceMLWord 2003XBRL 2.1 Full DTD Support

10. Tamino Search and Retrieval W3C XQuery Support User-defined functions If-Then-Else Node-level update XPath Support Extended with text search

11. Tamino Indexing and Retrieval Standard Classical database indexes Index any combination of elements and attributes Supports relational operators, exact comparisons, sorting Text Use in conjunction with text retrieval functions Supports wildcard searches Structure Index declared on the document Registers instances of undeclared nodes Reference Indexes specific sub-trees of a document (e.g. /doc/a/b) Useful for documents of high complexity (multiplicity of sub-trees) Multipath Index any element or attribute that meets an XPath expression Compound Index a combination of two elements (e.g. lastname and firstname)

12. Tamino and Document Management Integrated Internet File System (WebDAV) for document management Drag & drop storage/retrieval Instant document validation Higher performance & scalability Check-In, Check-Out, Workspaces, ... Embedded security via ACLs XQuery for property searches Versioning - on document level via WebDAV "natively" (auto-versioning) Non-XML Indexer Microsoft Office, PDF, ZIP... Indexing is extensible RFC 2518 � WebDAV base specification file system view on data HTTP 1.1: PUT / GET / DELETE / OPTIONS / HEAD COPY / MOVE / MKCOL / REPORT properties (PROPFIND / PROPPATCH) locking RFC 3253 � Versioning in WebDAV basic features VERSION-CONTROL, CHECKOUT, CHECKIN, LABEL histories, workspaces, working resources advanced features UPDATE (fork) RFC 3744 � WebDAV-ACL ACLs and ACEs similar to Tamino Security with hierarchical inheritance � but instance-based defines no authentication authentication like in HTTP protocol users and groups from Tamino are used WebDAV Search (Internet Draft) defines a search grammar for searching on properties protocol is extendable � maybe XQuery? Tamino supports DAV:basicsearch-grammar Querying on WebDAV metadata is possible using XQueryRFC 2518 � WebDAV base specification file system view on data HTTP 1.1: PUT / GET / DELETE / OPTIONS / HEAD COPY / MOVE / MKCOL / REPORT properties (PROPFIND / PROPPATCH) locking RFC 3253 � Versioning in WebDAV basic features VERSION-CONTROL, CHECKOUT, CHECKIN, LABEL histories, workspaces, working resources advanced features UPDATE (fork) RFC 3744 � WebDAV-ACL ACLs and ACEs similar to Tamino Security with hierarchical inheritance � but instance-based defines no authentication authentication like in HTTP protocol users and groups from Tamino are used WebDAV Search (Internet Draft) defines a search grammar for searching on properties protocol is extendable � maybe XQuery? Tamino supports DAV:basicsearch-grammar Querying on WebDAV metadata is possible using XQuery

13. Indexes proprietary Office Documents on storage Depending on MIME type e.g. Word 2003, RTF, StarOffice, OpenOffice, PDF, MP3, ZIP, ... Further arbitrary formatsindexable via new, extensibleInfrastructure (Server Extension w/ open Java interface) Stores XML-converted "shadow"documents in parallel to originals Content searchable via XQuery Original documents additionallystored 1:1 Modification with Tamino not supported Non-XML Indexer Non-XML Indexer: Server extension which accepts non-XML documents as input and creates so-called XML shadow documents. Just like any other XML document, these shadow documents can be stored, indexed, and queried in Tamino. For doctypes that make use of the Non-XML Indexer querying is performed on the shadow documents. Once a query has retrieved a document's ino:id or its ino:docname you can access the non-XML document itself via plainURL addressing. Indexing supported by plugins for PDF, Microsoft Word, Rich Text Format and Star Office.The generated shadow documents conform to the OASIS schemas Microsoft Office files: Microsoft Word / Excel OpenOffice files: OpenOffice Writer/ Calc StarOffice files: StarOffice Writer/ Calc Adobe PDF files Plain text files (UTF-8) / Plain text files MPEG Audio files (often known as MP3 files) RTF (Rich Text Format) files Zip files With Tamino version�4.4, the Non-XML Indexer implementation has been opened for extracting application-specific information from non-XML documents (e.g. GIF, JPG, etc.) via added custom plugins Furthermore, the Non-XML Indexer can now deal with text documents that must not be converted within Tamino. Non-XML Indexer: Server extension which accepts non-XML documents as input and creates so-called XML shadow documents. Just like any other XML document, these shadow documents can be stored, indexed, and queried in Tamino. For doctypes that make use of the Non-XML Indexer querying is performed on the shadow documents. Once a query has retrieved a document's ino:id or its ino:docname you can access the non-XML document itself via plainURL addressing. Indexing supported by plugins for PDF, Microsoft Word, Rich Text Format and Star Office.The generated shadow documents conform to the OASIS schemas Microsoft Office files: Microsoft Word / Excel OpenOffice files: OpenOffice Writer/ Calc StarOffice files: StarOffice Writer/ Calc Adobe PDF files Plain text files (UTF-8) / Plain text files MPEG Audio files (often known as MP3 files) RTF (Rich Text Format) files Zip files With Tamino version�4.4, the Non-XML Indexer implementation has been opened for extracting application-specific information from non-XML documents (e.g. GIF, JPG, etc.) via added custom plugins Furthermore, the Non-XML Indexer can now deal with text documents that must not be converted within Tamino.

14. Tamino Enterprise Features Replication Replicate Databases available for parallel read access High Availability (Hot Standby and Failover) Cluster support Used by Schiphol Airport, Euredit, RTL / MaxiMedia, Ideal, Sun,.... Security Support for LDAP and OS Security via Tamino Manager 2 Phase Commit Available both for Java and .NET Network drive support (NAS/SAN)

15. Tamino Tools and APIs Tamino APIs: Java .NET C SOAP UDDI Tamino Tools: Schema Editor X-Plorer XQuery Editor Interactive Interface

16. Performance Highlights & Market Acceptance ~ 1TB of Data in 3 Tamino DBs (Vodafone - Spain) ~ 1.125 billion logical reads / month (~ 430 reads/s at Migros Online - CH) ~ 180 million documents in 8 Tamino DBs (tested by IDEAL Greece)~ 15,000 transactions daily via 400 concurrent users~ 400 transactions daily via 2000 subscribed users~ Tamino internal compression of 1:20 (non-XML), 1:4 (XML) ~ 1-3 sec application response time w/ 420 users querying every 10s (RTL - D) ~ Load 7.2 million docs/hr, 75 MB/s, 16 clients, 1 index/doctype (Commerzbank- D)

17. Tamino Differentiators Integrated high-performance Internet file system (via built-in WebDAV) Built-in versioning (via integrated WebDAV & natively) Standards support: XML, XML Schema, Web services, XQuery, UDDI3 Enterprise features (HA support, Replication, 2-Phase-Commit) Multiple indexes for efficient native XML storage, search, access and retrieval Multiple XML documents & schemas allowed per DB Support for efficient structure changes (schema evolution) Structure-independent retrieval times Rich tool & utilities set (Schema editor, XML-Indexer, text-retrieval, ...) Smart disk space management (compression) Available across multiple OS platforms

18. VODAFONEMulti-Channel Electronic Bills Presentation Mission Allow customer information from disparate systems to be combined together to form a service that is unique -> competitive advantage Solution A system that allows customers and internal users to see their invoices and the billing information via Internet Using XML, Tamino XML Server, Web-Logic and IXOS products Result Access invoices from the web in diverse formats (HTML, XML, PDF and Excel) Minimize paper and mail delivery Send billing information to clients through SMS Feed Vodafone�s System Data Warehouse

19. VODAFONEMulti-Channel Electronic Bills Presentation Performance Data Cluster solution HP11i-64 4 CPU, 2GB RAM Total of >> 1 TB on 3 DBs [>250 .. 350 GB each] 1:40h backup or restore time for 250 GB DB 30 million docs, avg.~ 35kB [min. 9kB .. max. 180MB] > 2.5 million bills / month (split into to 1MB chunks), 1 Doctype w/ 200 elements & 200 attribs. > 9h loading for 250GB DBs; Server response times: 0.1 - 1 sec

20. For More Information Feel Free to Contact me John.Fitzgerald@SoftwareAGUSA.com (703) 391-8177 Visit Our Website http://www.softwareagusa.com Download a FREE trial Copy http://www.xmlstarterkit.com/
