  1. 10. Key Management

  2. Contents • Key Management • Public-key distribution • Secret-key distribution via public-key cryptography

  3. Key Management • Public-key distribution • Public announcement • Public available directory • Public-key authority • Public-key certificates

  4. Public Announcement • Public announcement of public keys • Any participant can send his/her public key to any participants or broadcast to the community.

  5. Public Announcement • Weakness • Anyone can forge a public announcement • Some user could pretend to be user A and send a public key to another participant or broadcast such a public key. C

  6. Public Available Directory • Publicly available directory • A trusted authority maintains a directory with a {name, public key} entry for each participants. • Each participant registers a public key with the directory authority.

  7. Public Available Directory • A participant may replace the existing key with a new some at any time. • Periodically, the authority publishes the entire directory or updates to the directory.

  8. Public Available Directory • Participants could also access the directory electrically. For this purpose, secure, authenticated communication from the authority to the participant is mandatory.

  9. Public Available Directory • This scheme is more secure, but still has vulnerabilities. • If an opponent get the private key of the directory authority, the opponent could counterfeit public keys in the directory.

  10. Public-key Authority • Public-key Authority • Stronger security for public-key distribution can be achieved by providing tighter control over the distribution of public keys from the directory.

  11. Public-key Authority • A sends a timestamped message to the public-key authority containing a request for the current public key of B.

  12. Public-key Authority • The authority responds with a message that is encrypted using the authority’s private key, KRauth.

  13. Public-key Authority • A stores B’s public key and also use it to encrypt a message to B containing an identifier of A(IDA) and a nonce(N1).

  14. Public-key Authority 4,5 B retrieves A’s public key from the authority in the same manner as A retrieved B’s public key.

  15. Public-key Authority • B sends a message to A encrypted with KUa and containing A’s nonce(N1) as well as a new nonce generated by B(N2).

  16. Public-key Authority • A returns N2, encrypted using B’s public key, to assure B that is correspondent is A.

  17. Public-key Authority • Drawbacks • A total of seven messages are required. • However, the initial four messages need be used only infrequently because both A and B can save the other’s public key for future use. • Public-key authority could be a bottleneck in the system, because a user must access the authority for the public key for every other user that it wishes to contact. • As before, the directory is vulnerable to tampering.

  18. Public-key Certificates • Public-key certificates • Certificates are used to exchange keys without contacting a public-key authority. • A certificate consists of a public key, an identifier of the key owner, and more information with the signature of the whole block signed by a trusted third party.

  19. Public-key Certificates • Certificate generation • Each user sends his/her public key to a certificate authority (CA) in a secure manner. • The CA generates a certificate for the user using his/her private key.

  20. Public-key Certificates • Public-key exchange • A and B sends their certificates to each other. • Each verify the certificate using the CA’s public key.

  21. Secret-Key Distribution • Secret-key distribution via public-key cryptography • Simple secret key distribution • Secret key distribution with confidentiality and authentication • A hybrid scheme

  22. Simple Secret Key Distribution • Simple Secret Key Distribution • If A wishes to communicate with B, • A generates a public/private key pair {KUa, KRa} and transmits a message to B consisting of KUa and an identifier of A, IDA. • B generates a secret key, Ks, and transmits it to A, encrypted with A’s public key. • A computes DKRa[EKUa[Ks]] to recover the secret key. • A discards KUa and KRa and B discards KUa.

  23. Simple Secret Key Distribution • A and B can now securely communicate using conventional encryption and the session key Ks. • However, this protocol is vulnerable to an active attack. • Man-in-the-middle attack • An opponent E can compromise the communication without being detected.

  24. (1) KUa||IDA (2) KUe||IDA A E B (4) EKUa[Ks] (3) EKUe[Ks] Simple Secret Key Distribution • Man-in-the-middle attack • A generates a public/private key pair {KUa, KRa} and transmits a message intended for B consisting of KUa and IDA. • E intercepts the message, creates its own public/private key pair {KUe, KRe} and transmits KUe||IDA to B.

  25. (1) KUa||IDA (2) KUe||IDA A E B (4) EKUa[Ks] (3) EKUe[Ks] Simple Secret Key Distribution • Man-in-the-middle attack • B generates a secret key Ks, and transmits EKUe[Ks]. • E intercepts the message and learns Ks by computing DKRe[EKUe[Ks]]. • E transmits EKUa[Ks] to A.

  26. Simple Secret Key Distribution • Man-in-the-middle attack • Both A and B know Ks and are unaware that E knows Ks. • Knowing Ks, E can decrypt all encrypted messages between A and B.

  27. Secret Key distribution with Confidentiality and Authentication • Secret Key Distribution with Confidentiality and Authentication • Assume that A and B have exchanged public key

  28. Secret Key distribution with Confidentiality and Authentication • A uses B’s public key to encrypt a message to B obtaining an identifier of A (IDA) and a nonce (N1), used to identify this transaction uniquely. • B sends a message to A encrypted with KUa and obtaining A’s nonce(N1) as well as a now nonce generated by B(N2).

  29. Secret Key distribution with Confidentiality and Authentication • A returns N2, encrypted using B’s public key, to assure B that its correspondent is A. • A selects a secret key Ks and sends M = EKUb[EKRa[Ks]] to B. Encryption of this message with B’s public key ensures that only B can read it; Encryption with A’s private key ensures that only A could have sent it. • B computes DKUa[DKRb[M]] to recover the secret key.

  30. Secret Key distribution with Confidentiality and Authentication • This approach provides protection against both active and passive attacks. • Note that the first 3 step of this scheme are the same as that last 3 steps of Public-key authority scheme. • This scheme ensures both confidentiality and authentication in the exchange of a secret key.

  31. Hybrid Scheme • A Hybrid Scheme • The use of a key distribution center (KDC) that shares a secret master key with each user and distributes secret session keys encrypted with the master key. • A public key scheme is used to distribute the master keys.

  32. Hybrid Scheme • Performance • Distribution of session key by public-key encryption could degrade overall system performance. • With a 3-level hierarchy, public-key encryption is used only occasionally to update the master key between a user and the KDC. • Backward Compatibility • The hybrid scheme is easily overlaid on an existing KDC scheme, with minimal disruption or software changes.
