Temple university cis dept cis331 principles of database systems l.jpg

Temple University – CIS Dept.CIS331– Principles of Database Systems

V. Megalooikonomou

Functional Dependencies

(based on notes by Silberchatz,Korth, and Sudarshan and notes by C. Faloutsos at CMU)


General overview l.jpg

General Overview

  • Formal query languages

    • rel algebra and calculi

  • Commercial query languages

    • SQL

    • QBE, (QUEL)

  • Integrity constraints

  • Functional Dependencies

  • Normalization - ‘good’ DB design


Overview l.jpg

Overview

  • Domain; Ref. Integrity constraints

  • Assertions and Triggers

  • Security

  • Functional dependencies

    • why

    • definition

    • Armstrong’s “axioms”

    • closure and cover


Functional dependencies l.jpg

Functional dependencies

motivation: ‘good’ tables

takes1 (ssn, c-id, grade, name, address)

‘good’ or ‘bad’?


Functional dependencies5 l.jpg

Functional dependencies

takes1 (ssn, c-id, grade, name, address)


Functional dependencies6 l.jpg

Functional dependencies

‘Bad’ - why?


Functional dependencies7 l.jpg

Functional Dependencies

  • Redundancy

    • space

    • inconsistencies

    • insertion/deletion anomalies (later…)

  • What caused the problem?


Functional dependencies8 l.jpg

Functional dependencies

… ‘name’ depends on ‘ssn’

define ‘depends’


Functional dependencies9 l.jpg

Functional dependencies

Definition:

‘a’ functionally determines ‘b’


Functional dependencies10 l.jpg

Functional dependencies

Informally: ‘if you know ‘a’, there is only one ‘b’ to match’


Functional dependencies11 l.jpg

Functional dependencies

formally:

if two tuples agree on the ‘X’ attribute,

they *must* agree on the ‘Y’ attribute, too

(e.g., if ssn is the same, so should address)

… a functional dependency is a generalization of the notion of a key


Functional dependencies12 l.jpg

Functional dependencies

‘X’, ‘Y’ can be sets of attributes

other examples??


Functional dependencies13 l.jpg

Functional dependencies

ssn -> name, address

ssn, c-id -> grade


Functional dependencies14 l.jpg

Functional dependencies

K is a superkey for relation R iff K -> R

K is a candidate key for relation R iff:

K -> R

for no a  K, a -> R


Functional dependencies15 l.jpg

Functional dependencies

Closure of a set of FD: all implied FDs – e.g.:

ssn -> name, address

ssn, c-id -> grade

imply

ssn, c-id -> grade, name, address

ssn, c-id -> ssn


Fds armstrong s axioms l.jpg

FDs - Armstrong’s axioms

Closure of a set of FD: all implied FDs – e.g.:

ssn -> name, address

ssn, c-id -> grade

how to find all the implied ones, systematically?


Fds armstrong s axioms17 l.jpg

FDs - Armstrong’s axioms

“Armstrong’s axioms” guarantee soundness and completeness:

Reflexivity:

e.g., ssn, name -> ssn

Augmentation

e.g., ssn->name then ssn,grade-> ssn,grade


Fds armstrong s axioms18 l.jpg

FDs - Armstrong’s axioms

Transitivity

ssn->address

address-> county-tax-rate

THEN:

ssn-> county-tax-rate


Fds armstrong s axioms19 l.jpg

FDs - Armstrong’s axioms

Reflexivity:

Augmentation:

Transitivity:

‘sound’ and ‘complete’


Fds finding the closure f l.jpg

FDs – finding the closure F+

F+ = F

repeatfor each functional dependency f in F+

apply reflexivity and augmentation rules on fadd the resulting functional dependencies to F+for each pair of functional dependencies f1and f2 in F+iff1 and f2 can be combined using transitivitythen add the resulting functional dependency to F+

until F+ does not change any further

We can further simplify manual computation of F+ by using the following additional rules 


Fds armstrong s axioms21 l.jpg

FDs - Armstrong’s axioms

Additional rules:

Union

Decomposition

Pseudo-transitivity


Fds armstrong s axioms22 l.jpg

FDs - Armstrong’s axioms

Prove ‘Union’ from the three axioms:


Fds armstrong s axioms23 l.jpg

FDs - Armstrong’s axioms

Prove ‘Union’ from the three axioms:


Fds armstrong s axioms24 l.jpg

FDs - Armstrong’s axioms

Prove Pseudo-transitivity:


Fds armstrong s axioms25 l.jpg

FDs - Armstrong’s axioms

Prove Decomposition


Fds closure f l.jpg

FDs - Closure F+

Given a set F of FD (on a schema)

F+ is the set of all implied FD.

E.g.,

takes(ssn, c-id, grade, name, address)

ssn, c-id -> grade

ssn-> name, address

}F


Fds closure f27 l.jpg

FDs - Closure F+

ssn, c-id -> grade

ssn-> name, address

ssn-> ssn

ssn, c-id-> address

c-id, address-> c-id

...

F+


Fds closure f28 l.jpg

FDs - Closure F+

R=(A,B,C,G,H,I)

F= { A->B

A->C

CG->H

CG->I

B->H}

Some members of F+:

A->H

AG->I

CG->HI


Fds closure a l.jpg

FDs - Closure A+

Given a set F of FD (on a schema)

A+ is the set of all attributes determined by A:

takes(ssn, c-id, grade, name, address)

ssn, c-id -> grade

ssn-> name, address

{ssn}+ =??

}F


Fds closure a30 l.jpg

FDs - Closure A+

takes(ssn, c-id, grade, name, address)

ssn, c-id -> grade

ssn-> name, address

{ssn}+ ={ssn,

name, address }

}F


Fds closure a31 l.jpg

FDs - Closure A+

takes(ssn, c-id, grade, name, address)

ssn, c-id -> grade

ssn-> name, address

{c-id}+ = ??

}F


Fds closure a32 l.jpg

FDs - Closure A+

takes(ssn, c-id, grade, name, address)

ssn, c-id -> grade

ssn-> name, address

{c-id, ssn}+ = ??

}F


Fds closure a33 l.jpg

FDs - Closure A+

if A+ = {all attributes of table}

then ‘A’ is a candidate key


Fds closure a34 l.jpg

FDs - Closure A+

Algorithm to compute a+, the closure of a under F

result := a;while (changes to result) dofor each in F do beginif  result then result := result end


Fds closure a example l.jpg

FDs - Closure A+ (example)

R = (A, B, C, G, H, I)

F = {A B, A C, CG H, CG I, B H}

(AG)+

1.result = AG

2.result = ABCG(A C and A  B)

3.result = ABCGH(CG H and CG  AGBC)

4.result = ABCGHI(CG I and CG  AGBCH)

Is AG a candidate key?

Is AG a super key?

Does AG R?

Is any subset of AG a superkey?

Does A+R?

Does G+R?


Fds a closure l.jpg

FDs - A+ closure

C

A

B

Diagrams

AB->C (1)

A->BC (2)

B->C (3)

A->B (4)


Fds canonical cover fc l.jpg

FDs - ‘canonical cover’ Fc

Given a set F of FD (on a schema)

Fc is a minimal set of equivalent FD. E.g.,

takes(ssn, c-id, grade, name, address)

ssn, c-id -> grade

ssn-> name, address

ssn,name-> name, address

ssn, c-id-> grade, name

F


Fds canonical cover fc38 l.jpg

FDs - ‘canonical cover’ Fc

ssn, c-id -> grade

ssn-> name, address

ssn,name-> name, address

ssn, c-id-> grade, name

Fc

F


Fds canonical cover fc39 l.jpg

FDs - ‘canonical cover’ Fc

why do we need it?

define it properly

compute it efficiently


Fds canonical cover fc40 l.jpg

FDs - ‘canonical cover’ Fc

why do we need it?

easier to compute candidate keys

define it properly

compute it efficiently


Fds canonical cover fc41 l.jpg

FDs - ‘canonical cover’ Fc

define it properly - three properties

every FD a->b has no extraneous attributes on the RHS

same for the LHS

all LHS parts are unique


Fds canonical cover fc42 l.jpg

‘extraneous’ attribute:

if the closure is the same, before and after its elimination

or if F-before implies F-after and vice-versa

FDs - ‘canonical cover’ Fc


Fds canonical cover fc43 l.jpg

FDs - ‘canonical cover’ Fc

ssn, c-id -> grade

ssn-> name, address

ssn,name-> name, address

ssn, c-id-> grade, name

F


Fds canonical cover fc44 l.jpg

FDs - ‘canonical cover’ Fc

Algorithm:

examine each FD; drop extraneous LHS or RHS attributes

merge FDs with same LHS

repeat until no change


Fds canonical cover fc45 l.jpg

FDs - ‘canonical cover’ Fc

Trace algo for

AB->C (1)

A->BC (2)

B->C (3)

A->B (4)


Fds canonical cover fc46 l.jpg

FDs - ‘canonical cover’ Fc

Trace algo for

AB->C (1)

A->BC (2)

B->C (3)

A->B (4)

(4) and (2) merge:

AB->C (1)

A->BC (2)

B->C (3)


Fds canonical cover fc47 l.jpg

FDs - ‘canonical cover’ Fc

AB->C (1)

A->BC (2)

B->C (3)

in (2): ‘C’ is extr.

AB->C (1)

A->B (2’)

B->C (3)


Fds canonical cover fc48 l.jpg

FDs - ‘canonical cover’ Fc

AB->C (1)

A->B (2’)

B->C (3)

in (1): ‘A’ is extr.

B->C (1’)

A->B (2’)

B->C (3)


Fds canonical cover fc49 l.jpg

FDs - ‘canonical cover’ Fc

B->C (1’)

A->B (2’)

B->C (3)

(1’) and (3) merge

A->B (2’)

B->C (3)

nothing is extraneous:

‘canonical cover’


Fds canonical cover fc50 l.jpg

FDs - ‘canonical cover’ Fc

BEFORE

AB->C (1)

A->BC (2)

B->C (3)

A->B (4)

AFTER

A->B (2’)

B->C (3)


Overview conclusions l.jpg

Overview - conclusions

  • Domain; Ref. Integrity constraints

  • Assertions and Triggers

  • Functional dependencies

    • why

    • definition

    • Armstrong’s “axioms”

    • closure and cover
