Presentation Transcript
Slide1 l.jpg

Thoracolumbar FractureClassification SystemA New ApproachSpine Trauma Study GroupAlexander R Vaccaro M.D.ProfessorThomas Jefferson UniversityDepartment of Orthopaedicsand the Rothman Institute


Spine trauma study group thoracolumbar classification system three part description l.jpg
Spine Trauma Study GroupThoracolumbar Classification SystemThree Part Description

Fracture Description (Morphometric)

Neurologic Status

Integrity of PLC


Fracture description morphology l.jpg
Fracture Description (Morphology)

  • Compression-axial, flexion,distraction,translation/rotation

  • Distraction- extension,flexion,translation/rotation, compression

  • Translation/Rotation-flexion, distraction


Neurologic status l.jpg
Neurologic Status

  • Intact

  • Nerve Root Injury

  • Cauda Equina Injury

  • Cord Injury-Incomplete, Complete


Posterior ligamentous complex l.jpg
Posterior Ligamentous Complex

  • Intact

  • Disrupted In Tension


Treatment determined by l.jpg
TreatmentDetermined by:

  • Mechanism

  • Neurology

  • Ligament/ bone Integrity


Mechanism point system l.jpg
Mechanism-Point System

Two Component Mechanistic Description

Compression

1

Translation/

Rotation

3

Distraction

3


Neurology point system l.jpg
Neurology-Point System

Intact

0

Nerve root

Cauda equina

1

3

Cord

Incomplete

Complete

3

2


Stability soft tissue point system l.jpg
Stability-Soft Tissue Point System

Ligaments

Intact 0

PLC

Injured 3

Evaluated by MRI


Stability spinal column point system l.jpg
Stability Spinal Column Point System

Spinal Column

Anterior

Posterior

1

1

Middle

1


Next step direct tx l.jpg
Next Step - Direct TX

AssignPoints

Conservative

Surgery


Point system l.jpg
Point System

Ligament

Mechanism

Translation/Rotation - 3

PLC - 3

Distraction - 3

Compression - 1

Neurology

Spinal Column

Cauda equina - 3

Anterior - 1

Incomplete - 3

Middle - 1

Complete - 2

Posterior - 1

Root - 1


Treatment l.jpg
Treatment

  • Fractures with 4 points or less = non operative

  • Fractures with 5 points=Nonop vs Op

  • Fractures with 6 points or more = surgery


Examples anterior compression fx l.jpg
ExamplesAnterior Compression Fx

  • Compression ( mechanism) - 1

  • Intact (neurology) - 0

  • PLC (ligament) no injury - 0

  • Anterior Column - 1

Total 2 points- Non Op


Example stable burst fracture l.jpg
ExampleStable Burst Fracture

  • Compression (mechanism) - 1

  • Intact ( neurology) - 0

  • PLC (ligament) no injury (0)

  • Ant/Middle column 1+1

Total 3 points-Non Op


Example unstable burst complete neuro injury l.jpg
ExampleUnstable Burst-Complete Neuro Injury

  • Compression (mechanism) -1

  • Complete (neurology) - 2

  • PLC (ligament) injury - 3

  • Ant/Middle column -1+1

Total 8 points-Surgery


Example stable burst complete injury l.jpg
ExampleStable Burst-Complete injury

  • Compression-1

  • Complete neurology-2

  • PLC Intact-0

  • Anterior, Middle Column disruption- 1+1

    Points 5-Non Op vs Op


Example fx dislocation l.jpg
ExampleFx Dislocation

  • Translation/rotation - distraction (mechanism) - 3 + 3

  • Complete (neurology) - 2

  • PLC (ligament) injury - 3

  • Anterior column - 1

Total 12 points-Surgery


Surgically indicated patients approach selection l.jpg
Surgically Indicated PatientsApproach Selection

Neurology

Ligament Status

Modifiers


Approach selection l.jpg
Approach Selection

Neurologically Intact

Ligament Injury present

Posterior alone vs.

Anterior alone vs.

Combined


Approach selection21 l.jpg
Approach Selection

Neurologically Incomplete

Ligament Injury

No

Yes

Combined vs

Anterior

Anterior

Modifier – Osteoporosis

Combined


Approach selection22 l.jpg
Approach Selection

Neurologically Complete Injury

Posterior


Thoracolumbar fracture classification system l.jpg
Thoracolumbar Fracture Classification System

  • Point system to determine nonoperative vs operative treatment

  • Neurology, ligamentous status helps determine surgical approach

  • Validation necessary
