C y cyle safe

CYcyle Safe

Visit our site:

http://seniord.ece.iastate.edu/may1211


C y cyle safe

The Team – May1211

Team Leader

John Sedig

Communications / Documentation

Kevin Nennig

Webmaster / Software Design

Matt Graves

Hardware / Electrical Design

Josh Mandich

Software Design

Alex Wesenberg

Team Advisor

ArunSomani

Visit our site:

http://seniord.ece.iastate.edu/may1211


C y cyle safe

The Story


C y cyle safe

The Story


C y cyle safe

Problem Statement

Many bicyclists are injured due to car related accidents on the road each year.

If a bicyclist could be warned of rear approaching vehicles, this could greatly reduce number of bicyclist involved in accidents.

Primary Goal - To design and develop a low cost vehicle alert accessory for cyclists


C y cyle safe

Concept Sketch


C y cyle safe

Functional Specs

The device must communicate via the ANT+ protocol to an Edge 500 Garmin head unit

Must be able to detect cars going from speeds 10mph-70mph

Must detect vehicles within 100m behind the rear of the bicycle


C y cyle safe

Non-Functional Specs

The device should be mounted under the bicycle seat

The device will reduce accidents for both cyclists and vehicles by promoting awareness of road conditions to the cyclist

The enclosure hosts the device and batteries behind the bicycle


C y cyle safe

Market Survey

Mirror

Basic solution for viewing cars behind bicycle

Not aerodynamic

Requires user to orient correctly

Cerevellum Digital Bike Camera

Rear-facing digital video camera

Does not detect vehicles, only displays them

Allows user to record what is behind them

Useful for determining faults of vehicle accidents


Laser radar sonar image processing

General Sensors

LaserRadar SonarImage Processing


C y cyle safe

Our Design

Power


C y cyle safe

Hardware

ANT+ Transceiver

1000mAh 7.4 V Li-Po battery

Edge 500 Head Unit

Beagleboard -XM

Logitech WebCam


C y cyle safe

Power Module

  • BeagleBoard voltage input: 5V

  • Average current Draw : 700mA

  • Power Consumption : 3.5 W

  • Rechargeable and mobile system


C y cyle safe

Power Module

  • 1000mAh Lithium-ion polymer 2S 7.4V battery

  • Switching Voltage Regulator

  • Minimum 1.25 hour life cycle


C y cyle safe

Case / Interlock


C y cyle safe

Capture Module

  • Went from 5M Aptinacamera board to Logitech c310

  • Emphasis changed later on in semester to focus on algorithms and car detection

5M MT9P031 Camera Board

Logitech WebCam


Previous sobel hough pca optical flow

Algorithm Module

Previous

Sobel

Hough

PCA

Optical Flow


C y cyle safe

Sobel Edge Detection


C y cyle safe

Sobel Edge Detection


C y cyle safe

Hough Line Detection


C y cyle safe

Hough Line Detection


C y cyle safe

Principal Component Analysis (PCA)

Averaged Image

=


C y cyle safe

Principal Component Analysis (PCA)

Averaged Image

=


Actual optical flow haar object detection haartraining

Algorithm Module

Actual

Optical Flow

Haar Object Detection

HaarTraining


C y cyle safe

Optical Flow on BB


C y cyle safe

Haar Object Detection

  • Uses a precompiled cascade classifier

  • Scans the ROI for the object


C y cyle safe

HaarTraining


C y cyle safe

ANT+

  • Communicate with ANT+ Transceiver over USB, using USB Serial LKM

  • Use of high Heart Rate signal due to lack of programming interface on the head unit


C y cyle safe

Defining Success

  • Be able to successfully detect a car in our worst case (car going 70mph, detection distance of 100m)

    • Be able to detect each car at least once within this interval


C y cyle safe

Test Results

  • Cyclist Performance

  • Module

  • Platform

  • System

  • Requirements


C y cyle safe

Test Results

  • First Detection

  • Worst Case Detection Time

  • Algorithm Time


C y cyle safe

Test Results

  • Reaction Time

  • ANT+ High Heart Rate Time

  • Total Time

    .459 + 2.07 + 2.2 = 4.7 seconds < 5.07 seconds


C y cyle safe

Product Profitability

  • Gross margin : 33%

  • Does not account for increase in inventory, capital, staff, or marketing


C y cyle safe

Lessons Learned

  • Know your team’s abilities

  • Bottlenecks in the development process

  • Ask the right questions
