  1. Coming to Your Network Soon! Windows 7 John Brumley Lowell Furman Brent Moberly Sheryl Swinson

  2. Presentation Agenda • The User Interface – Sheryl Swinson • Performance Enhancements – John Brumley • Security – Dr. Brent Moberly • Networking – Lowell Furman • Questions at the presentation's end, except for Networking; Interruptions are encouraged in Networking.

  3. Coming to Your Network Soon! Windows 7 The User Interface Sheryl Swinson – Indiana University

  4. Task Bar • Hmmm… This looks pretty familiar…

  5. Task Bar • Relocate • Hover • Jumplists

  6. System Tray • The “mystery meat” is gone • The foggy little appendix (we’ll come back to it later)

  7. Desktop and Window Management • Peeking • Gadgets • Gestures

  8. Coming to Your Network Soon! Windows 7 Performance Enhancements John Brumley – Indiana University

  9. Performance Enhancements • Power-Management • Processing Enhancements • Graphic Enhancements • Solid-State Drive Optimization • Media distribution / HomeGroup • New Gadgets, Programs and Abilities

  10. Power-Management • Reduced power consumption • Idle resource utilization by Timer-Coalescing API

  11. Power-Management Continued • Device power management • -Adaptive Display brightness • -Low-power audio • -Bluetooth & network power improvements

  12. Processing Enhancements • - Processor Power-Management (PPM) driver support • Hyper-threading Utilization • HT works with multi-core CPUs • Timer-Coalescing API

  13. Graphic Enhancements - New algorithms for 3D graphics and for Desktop performance - GDI concurrency - Reduced memory footprint - Optimized for multi-core CPUs

  14. Solid-state Drive Optimization • Reduce frequency of writes and flushes • Disk defragmentation disabled for SSD • Supports Trim • Disables Superfetch, ReadyBoost, as well as boot and application prefetching. • - Bitlocker encryption is optimized for SSD

  15. Media Distribution / HomeGroup - Supports Network Media Devices (NMDs) following Digital Living Network Alliance (DLNA) standard. - Based on the “family-home” concept - “Play To” ability

  16. Media Distribution / HomeGroup

  17. Media Distribution / HomeGroup - Internet access to home media using @Live account - New NAT traversal technology - Media format conversion for unsupported codecs - Printers install across all HomeGroup PCs.

  18. New Gadgets, Programs & Abilities • Improved calculator • Problem Steps Recorder • Built-in ISO burner utility • Math Input Panel • Sticky Notes • PowerShell 2.0

  19. Coming to Your Network Soon! Windows 7 Security Dr. Brent Moberly – Indiana University

  20. Security Outline • Compatibility • Security – background • We will not debate Mac vs. PC slide – there is only one slide for this discussion • User Access Controls • Mandatory Integrity Control (MIC) • AppLocker • Future Reading List

  21. Compatibility Tab • Windows 7 compatibility tab fools programs into thinking they are running under earlier versions ofWidows.

  22. Windows XP Mode • Windows XP mode is a virtual machine running a fully-licensed version of Windows XP. • Demo

  23. Windows XP Mode - Download • Windows XP Mode is not included by default. • Users will have to download it from Microsoft. • http://www.microsoft.com/windows/virtual-pc/download.aspx

  24. Security Intro, UAC, and Fun Programs

  25. First Year of VulnerabilitiesXP vs. Vista From “Windows Vista Security One Year Later,” Windows Security Blog (http://blogs.msdn.com/windowsvistasecurity/archive/2008/01/23/windows-vista-security-one-year-later.aspx)

  26. Infected Machines: June – December 2007 “In fact, from June – December 2007, using proportionate numbers, the MSRT found and cleaned malware from 60.5% fewer Windows Vista-based computers than from computers running Windows XP with Service Pack 2 installed. How about Windows 2000?  Using proportionate numbers, MSRT found and cleaned malware from 44% fewer Windows Vista-based computers than Windows 2000 SP4 computers and 77% fewer than from computers running Windows 2000 SP3.” From “Windows Vista and Malware,” Windows Security Blog (http://blogs.msdn.com/windowsvistasecurity/archive/2008/05/09/windows-vista-windows-2000-and-malware.aspx)

  27. Infection Rates - all Windows Versions: July-Dec. 2008. From “The Latest Microsoft Security Intelligence Report,” Microsoft Malware Protection Center (http://www.microsoft.com/security/portal/sir.aspx)

  28. Detected Infections @IUAug 2008 – Present

  29. Buts we Roxors teh OS X…. “It's quite easy to write an exploit for Firefox on OS X compared to Firefox on Vista….” “… It's getting pretty hard to do a lot of this stuff on Windows Vista and Windows 7," Nils said. "Especially when a lot of people who stayed with [Windows XP] switch to Windows 7 because they didn't want Vista, the bad guys may start to figure out they can more easily exploit these bugs more reliably on a Mac.” From “Mac OS X Top Target in Browser Beatdown,” Security Fix Blog(http://voices.washingtonpost.com/securityfix/2009/03/mac_os_x_top_target_in_browser.html)

  30. Least User Access (LUA) • Underlying principle behind Win 7 (and Vista) security is that of least privilege or Least User Access (LUA). • Namely, users should run under the minimum set of privileges required to perform a given task and elevate only if they require additional privileges.

  31. Windows 7 User Modes • Standard User • Administrator • Administrator-Approval

  32. User Access Control (UAC) Windows VistaUAC Control Panel (1 option) Windows 7UAC Control Panel (4 options)

  33. User Access Control (UAC) • Standard Users cannot auto-elevate

  34. User Access Control Prompts Windows 7Unsigned Application Windows VistaUnsigned Application

  35. User Access Control Prompts Windows 7Signed Application Windows VistaSigned Application

  36. Setting and auditing UACProgrammatically • HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows\CurrentVersion\Policies\System

  37. Setting UAC via Security Policies • Security Settings > Local Policies > Security Options

  38. UAC Under the Hood Q: How does Windows know when to elevate? A: Three main factors1) Mandatory Integrity Control (MIC)2) DACLS (to some extent)3) Manifests

  39. Manifests • Manifests allow applications to request specific privileges. • Ideally, manifests are embedded into an application’s resource tree. • But they can also be added as stand-alone files in an application’s directory.

  40. Sample Manifest File <?xml version="1.0" encoding="utf-8"?> <asmv1:assembly manifestVersion="1.0" xmlns="urn:schemas-microsoft-com:asm.v1" xmlns:asmv1="urn:schemas-microsoft-com:asm.v1" xmlns:asmv2="urn:schemas-microsoft-com:asm.v2" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"> <assemblyIdentity version="1.0.0.0" name="MyApplication.app"/> <trustInfo xmlns="urn:schemas-microsoft-com:asm.v2"> <security> <requestedPrivileges xmlns="urn:schemas-microsoft-com:asm.v3"> <requestedExecutionLevel level=" requireAdministrator " uiAccess="false" /> </requestedPrivileges> </security> </trustInfo> </asmv1:assembly> <requestedExecutionLevel level=" requireAdministrator " uiAccess="false" />

  41. RequestedExecutionLevel • asInvoker – runs with the same access token as the parent process. • highestAvailable – runs with the highest privileges the current user can obtain. • requireAdministrator - runs only for administrators; requires application to be launched with the full access token of an administrator.

  42. UIAccess • False – the program does not need to drive input to other applications on the desktop • True – the program drives input to other applications on the desktop.* * This setting requires that the application be signed with an Authenticode Cert and that the application must reside in a protected location in the file system.

  43. Select Windows Utilities • Utilities like taskmgr.exe include “<autoElevate>true</autoElevate>” in their manifests

  44. Legacy Applications • Applications without manifests are consider “unmarked” and are virtualized. • Virtualized means that they run against a temporary version of the windows registry, etc. • Demo: Old Yeller

  45. UAC Caveats • Standard user mode is more secure than admin-approval mode. • In admin-approval mode, always-prompt mode is more secure than auto-elevate. • Not running a program is more secure than running a program, even if you don’t elevate the program. • Once you elevate a program, that program can do almost anything it wants.

  46. Mandatory Integrity Control (MIC) • Restricts less trustworthy processes and applications in the same user context • Works in addition to (and before) Discretionary Access Control Lists (DACLS)

  47. MIC Levels • Low • Medium (default) • High • System

  48. MIC Rules • No write-up: objects with lower security levels cannot modify those with higher security levels • Medium = default: if an object does not have an explicit integrity level, its level is medium

  49. MIC Demos • Using Sysinternal’s Process Explorer to view MIC levels. • Using icacls.exe to modify MIC levels • Internet Explorer 8

  50. AppLocker • “White list” of programs allowed to run • New to Windows 7 • Targets enterprise deployment (uses GPO). • Demo: Gremlins
