Presentation Transcript


Day 7 excel chapter 4

“Two roads diverged in a wood, and I took the one less traveled by, and that has made all the difference. ”–Robert Frost


Day 7 excel chapter 4

Day 7:Excel chapter 4

CS 101

[email protected]

September 10th, 2014


Homework 1

Homework #1

  • Due this Friday 09/12 by midnight

  • 20% penalty for each day late

  • Only accepted through the CS101 website

  • You must set-up your analysis questions tab correctly!


Day 7 excel chapter 4

?

What is a visual representation of numerical data?

A CHART!


Why use a chart

Why use a chart?

  • “A picture is worth a thousand words”

    Charts often more effectively communicate data

  • Charts can contain enough data to be useful, but not overwhelm people


Chart basics

Chart basics

The four (most common) chart types:

  • Column – compares data vertically

  • Bar – compares data horizontally

  • Line – uses a line to connect data points

  • Pie – shows each data point in proportion to the whole data series


Chart elements

Chart elements

Chart Area

Plot Area

Category Axis(X Axis)

Value Axis

(Y Axis)


Column charts

Column charts

  • Displays data vertically in columns

  • More effective with a limited of number of categories (too many and the columns run together)

    Example: Compare revenue among different cities for one year.


Cluster column chart

Cluster column chart

Clusters of columns side by side for easy comparison.


Stacked column chart

Stacked column chart

Shows the relationship of individual data points to the whole category, one column per category.


100 stacked column chart

100% stacked column chart

Compares the percentage each data point contributes to the total for each category.


3 d column chart

3-d COLUMN CHART

Looks pretty.


Bar charts

Bar charts

  • Displays data horizontally in rows. (bars)

  • Similar to column charts, they can be stacked, clustered, 100% stacked…


Line charts

Line charts

  • Displays lines connecting data points to show trends over equal time periods.

  • The category axis represents time

  • The value axis represents the value


Single data series

Single data series


Multiple data series

Multiple data series


Pie charts

PIE Charts

  • Shows each data point in a proportion to the whole data series.

  • The larger the slice, the larger the percentage.


Basic pie chart

Basic pie chart


Exploded 3d pie

Exploded 3d pie


Stop project time

Stop: Project time

In Class Chart Demo


Chart design

Chart design

Changing the chart type:

  • Select the chart

  • Click the Design tab

  • Click Change Chart Type in the Type group

  • Select the desired type, click OK


Changing adding deleting data series

Changing/Adding/deleting data series

  • Select Chart

  • Design Ribbon

  • Data Group -> Select Data

  • Remove/Add/Delete


Switching rows columns

Switching rows/columns

  • Select Chart

  • Design Ribbon

  • Data Group -> Switch Row/Column


Chart styles

Chart styles

Can be applied to already made charts.

  • Select Chart

  • Design Ribbon

  • Chart Style Group -> Select Style


Embed an excel chart

Embed an Excel chart

  • Insert Ribbon

  • Click Object

  • Create New

  • Microsoft Excel Chart

  • Click OK

  • Replace the Sample Data in Sheet 1


Sample chart

Sample chart


You can also copy paste

You can also, copy/paste


Supplemental content

Supplemental content

Deals with horizontal axes.


Trendlines

Trendlines

Trendlines are useful because they can be used to predict future or past values by extrapolating the lines already plotted on a chart.


Trendline types

Trendline types

  • Linear Trendline

  • Exponential Trendline

  • Linear Forecast Trendline

  • Two Period Average Trendline


Adding trendlines

Adding trendlines

Select Data Series (In this case C grades)


Adding trendlines cont d

Adding trendlines - cont’d


The trendline

The trendline


Predicting the future past with trendlines

Predicting the future/past with trendlines

  • Right-click on the trendline you want to predict the values into the future or past

  • Click on Format Trendline

  • Forecast Group -> Set Periods

  • You can click on the different Trend types to view how they will predict the data

    (If you see it predicts negative gasoline prices, for instance, you may want to change trend types)


R squared values

R-Squared values

Gauge the accuracy of how a trendline fits the underlying data.

They range from 0 to 1, with higher numbers (closer to 1) being better fits, but you will likely never get a value of 1.


Viewing the r squared values

Viewing the r-SquareD values

At the bottom of the Format Trendline dialog box, click on “Display R-squares value on chart”.

You can then select between the different chart types to view which fits the data the best.


Trendline equations

Trendline equations

Under the Format Trendline dialog box, you can also view the trendline equations.


Due dates

Due dates

  • Homework I: 09/12/2014

  • MyITLab B: 09/15/2014

  • Homework II: 09/19/2014


Next class

next class

  • Excel Chapter 5 / Chapter 6

  • Look over Supplemental Content discussed today
