Week 07 09 05 13

Week 07 (09/05/13)

USB-serial convert

& terminal forwarding

尚哲


Usb mod install

成功的步驟 (USB mod install)

  • wget http://192.168.1.2/pl2303.o

  • wget http://192.168.1.2/usbserial.o

  • 拔出USB

  • insmod usbserial.o

  • insmod pl2303.o debug=1

  • mknod /dev/ttyUSB0 c 188 0

  • chmod 666 /dev/ttyUSB


Week 07 09 05 13

成功的步驟 (結果圖1)

  • 插入USB

  • dmesg


Week 07 09 05 13

成功的步驟 (結果圖2)


Week 07 09 05 13

嘗試做法

  • getty -L ttyUSB0 -h 115200 ansi

  • getty -L ttyUSB0 -h 115200 vt100

  • picocom -b 115200 /dev/ttyUSB0


About getty

about getty

  • 功能說明:設置終端機模式,連線速率和管制線路。

  • 語  法:getty [-h][-d<組態配置文件>][-r<延遲秒數>][-t<超時秒數>][-w<等待字元串>] [終端機編號][連線速率<終端機類型><管制線路>] 或 getty [-c<定義配置文件>]

  • 補充說明:

    • getty指令是UNIX之類操作系統啟動時所必須的3個步驟之一。

  • 參  數:

  • -c<定義配置文件> 指定定義配置文件,預設為/etc/gettydefs。

  • -d<組態配置文件> 指定組態配置文件,預設為/etc/conf.getty。

  • -h 當傳輸速率為0時就強制斷線。

  • -r<延遲秒數> 設置延遲時間。

  • -t<超時秒數> 設置等待登入的時間。

  • -w<等待字元串> 設置等待回應的字元串。


Getty

嘗試做法: getty (失敗)

  • cd gateway;

  • make menuconfig

  • in busybox, select getty

  • getty -L ttyUSB0 -h 115200 ansi


About picocom

about picocom

  • picocom is a minimal dumb-terminal emulation program. It is ideal for embedded systems since its memory footprint is minimal (less than 20K, when stripped). Apart from being a handy little tool, the source distribution includes a simple, easy to use, and thoroughly documented terminal-management library.


Picocom

嘗試做法 picocom (有希望)

  • mkdir /tmp/tmp

  • mount /tmp/tmp /opt

  • ipkg.sh update

  • ipkg.sh install ipkg

  • ipkg update

  • ipkg install picocom

  • picocom -b 115200 /dev/ttyUSB0

需上網


Picocom b 115200 dev ttyusb0

picocom -b 115200 /dev/ttyUSB0(非預期的結果)


Week 07 09 05 13

(預期結果)


Auto load mod in ap

(嘗試做法)Auto load mod in AP

  • 儲存方法???


Week 07 09 05 13

下兩週進度

  • 完成picocom or others tty forwarding方法

  • 每次開機後自動install的方法

    • save file ( usbserial.o pl2303.o )

    • save initialize script


  • Login
