Presentation Transcript
multivariable serial interface

Preliminary

MSI

Multivariable Serial Interface

msi m ultivariable s erial i nterface
MSI - Multivariable Serial Interface

Interfaces Honeywell’s digitally enhanced (DE) field instruments with PLCs, RTUs and PCs.

  • RS-232/485
  • Modbus, etc.

Ganged Network

Single Channel

key features
Key Features
  • Processes all DE communications traffic.
  • Translates DE data into standardized formats.
  • Any DE broadcast mode and format.
  • Expandable channel capacity & multidrop.
  • Provides “BAD PV” protection.
  • Accommodates handhelds and host DCS activity.
