Presentation Transcript


100kw electric vehicle controller inverter software design

100KW Electric Vehicle Controller/InverterSoftware Design

Tony Ahmann

5/6/09


General system design

General System Design

  • Microchip dsPIC30F6010A

  • 7.37MHz

  • 12kB EEPROM

  • 7kB RAM


Kernel choice

Kernel Choice

  • Continuous loop dependent on PWM

  • Worse case PWM period 10ms

  • Execution time 4ms


Tasks

Tasks

  • Startup Task

  • Run Motor Task


Startup task

Startup Task

  • Flux angle control reset

  • Clear RPM buffer

  • Initialize CAN bus

  • Get PID Parameters

  • Initialize user parameters


Run motor task

Run Motor Task

  • Pull button for start/stop motor

  • Update LCD

  • Send RPM, torque and flux to LabVIEW


Interrupts

Interrupts

  • ADC ISR

  • Calculates speed and executes vector update loop

  • ADC sample and conversion triggered by the PWM period


Module overview

Module Overview


Module overview continued

Module Overview continued


Module overview continued1

Module Overview Continued
