  1. Computer Network 중간발표 Routing Simulator( Wireless Mobile Ad-hoc Network 에서의Routing protocol Simulator program ) 200224159김영한 200624520 이준수 200724465 백수정 200724484 안연주

  2. 목차 • Layout 설명 • 구현기능 설명 • 진행상황 및 계획 • Q&A

  3. Layout ( 1 / 4 )

  4. Layout ( 2 / 4 ) • Node Information • Node들의 정보(Tag, Location, Address) 표시 • Transceiver power 에 의해 전송 범위와 주파수 변경 • Routing Setting • Routing Protocol 설정 • IP Setting • 각 노드의IP address 설정

  5. Layout ( 3 / 4 ) • Tag Setting • CSMA 방식에서의 Backoff-time 설정 • Transmission Setting • Packet의 Size,Bandwidth 및 Destination 설정 • Time Setting • Simulation 시간과 속도 조절

  6. Layout ( 4 / 4 )

  7. 구현 기능 ( 1 / 3 ) • Node의 임의 배치 및 이동성 제공 • 마우스 클릭으로 Node 배치 • Node를 누른 상태로 드래그 하여 이동 • Ctrl +클릭하면 Node 삭제

  8. 구현 기능 ( 2 / 3 ) • 시각적으로 확인 가능한 형태의 Packet 이동 • NEXT 버튼을 누르면 Node의 Range에 들어오는 Node들에 데이터를 전송하는 모습이 보이고, 데이터를 받은 Node는 데이터를 전송하기 위해 Range를 넓히기 시작 • 현재는 한번만 Range를 넓혀서 데이터를 전송 • RESET 버튼을 누르면 처음부터 시뮬레이션 가능

  9. 구현 기능 ( 3 / 3 ) 실행 (NEXT) 노드 생성 (Click)

  10. 진행상황 및 계획

  11. 진행상황 및 계획

  12. Q&A

  13. THE ENDTHANK YOU
