Identifying and Encrypting Personal Information

1. Identifying and Encrypting Personal Information Using Cornell Spider and Pointsec for PC Benjamin Stein Doreen Meyer cybersecurity@ucdavis.edu

2. Overview • What is personal information? • Searching for personal information using Cornell Spider • Mitigating risk of exposure of personal information • Encryption Policy, Encryption Options • Whole disk encryption using Pointsec for PC • Questions

3. Personal Information and HIPAA • HIPAA: Health Information Portability and Accountability Act • Psychological Services • Medical Records • http://www.hhs.gov/ocr/hipaa/

4. Personal Information: CA SB1386 and Civil Code 1798 • Account access number and password • Bank/financial account number • California identification card number • Credit/debit card number • Driver’s license number • Social Security number • http://www.privacy.ca.gov/code/ipa.htm

5. Personal Information: FERPA • Family Education Rights and Privacy Act of 1974 (FERPA) • Class level, class schedule, academic status, grades, instructors, transcripts • Student ID number, Social Security number • Fees paid, loan collection records, financial aid records, etc. • http://www.ed.gov/policy/gen/guid/fpco/ferpa/index.html

6. Searching for personal information • Data focus: credit card numbers and Social Security numbers • UCD supported products: Cornell Spider and PowerGREP

7. Mitigating Risk of Exposure of Personal Information • Higher cost (time, tools) for administering a system containing personal information. • IET supports the Cyber-safety program and a number of tools that assist in protecting personal information, including Tripwire, Spider/PowerGREP, self-directed Nessus scans, and Pointsec.

8. Maintain a list of systems containing sensitive data • Catalog the system name, IP, owner, type of service running on the system, type of sensitive data residing on the system • Share this information with the technical support staff and the unit administrative managers • Confirm and update this information on a regular basis

9. Monitor when the data is accessed or modified • Use Tripwire to identify file and directory changes. • Write logs to a central logging server (syslogng, snare, MOM). • Turn on auditing of successful and unsuccessful logins. • Read your logs on a regular basis.

10. Restrict access to the system and its sensitive data • No group accounts (cannot audit access) • Access system and data using encrypted protocols such as ssh (sftp, scp), ssl (https), rdp, ipsec • Evaluate physical security • Use host-based and hardware firewalls

11. Use, share, or transfer restricted data in a safe manner • Do not use email to send unencrypted restricted data. • Do not use restricted data as a key in a database. • Do not use restricted data on a test or development system. • When sharing restricted data, ensure that users are aware that the data should be handled carefully and in compliance with policies.

12. Cornell Spider Demo

13. Encryption Policy • UC Davis whole disk encryption policy draft: http://security.ucdavis.edu/encryption_policydraft.pdf • UCOP protection of personal information policies: http://www.ucop.edu/irc/itsec/infoprotect.html

14. Encryption Options • Windows OS

15. Encryption Options • Mac OSX

16. Encryption Options • Linux

17. Pointsec for PC at UCD • http://security.ucdavis.edu/encryption.cfm

18. Pointsec for PC • If a drive is lost or stolen, the encrypted partitions and everything on them are reasonably secure. • Meets certain legal requirements

19. What it isn’t • Pointsec for PC is not a complete encryption solution • Currently limited to 2000 and XP • Only encrypts partitions • Does not encrypt network drives

20. Features • Whole disk encryption • Multiple user access • Configuration options • Recovery tools • Enterprise management • Logging • Enforceable policies • Permissions

21. Experience • Login screen at boot • System tray icon • Transparent to OS • Minimal performance impact

22. Example:

24. System Tray Icon: • While encrypting: • Fully encrypted:

25. How to install • Available to individuals and departments • Check requirements • Request license from IET Security • Decide on default or custom configuration • Get install media • Return recovery file • After encryption completes return log file

26. Requirements • Windows 2000, XP and Vista soon • No dual boot • No servers • No fancy disk configurations

27. Preparing the System • Backup! • Defrag • Scan for viruses, etc • Uninstall and disable the unnecessary services • Check the disk(s)

28. Installing the Software • Use administrative account • Launch installer • Reboot • Login to Pointsec • Login to OS • Grab recovery file • Encryption begins

29. Demo

30. Encryption Process • Encryption proceeds at 10-20GB/hr • Depends on disk size not amount of data • System can be used, shut down or rebooted • After encryption completed grab log file

31. Support • Remote password reset • Managing users • Uninstall • Updates and upgrades • Recovery disk • Bart’s disk

32. Managing Users • Types of users • Normal, Service, Temp • Types of permissions • Privileged and plain permissions • Creating additional users

33. Uninstall • Requires two accounts with rights • Can be faster to clone or recover than decrypt

34. Updates, Upgrades and Reinstalls • Updates • Change users, passwords, certs or settings • Upgrades • Major product upgrade? • Reinstalls • Add additional partitions or disks

35. Recovery Disk • Create from recovery file or target computer • Requires two admin accounts • Decrypts

36. Bart’s PE with Plug-in • Requires version specific plug-in • Must boot and login • Ctrl + F10 for alternative boot menu • Bart’s then has full access to disk

37. Customizing • Default configuration will meet most needs, however, there are lots of options… • Configuration worksheet • Alternative profiles

38. Review • Whole Disk Encryption • Low overhead • Quick default install • Support options • Highly customizable

39. Additional Resources • Product documentation • Pointsec 24 x 7 tech support • IET: cybersecurity@ucdavis.edu

40. Questions & Answers
