  1. /* GPRS-PPP.C Here is a quick sample of the GPRS - PPP connection procedure: For standard GPRS connections use yourAPN = internet ( vodafone ) and with blank username and password use if ((pppcom = _open("ppp:" PPPCOM, _O_RDWR | _O_BINARY)) == -1) instead of if ((pppcom = _open("ppp:" PPPCOM "/" PPPUSER "/" PPPPASS, _O_RDWR |_O_BINARY)) == -1) For the function "WebServer" you can cut and paste httpserv.c from: * * Register our device for the file system. */ NutRegisterDevice(&devUrom, 0, 0); onwards. Hope this will help you. */ #include <inttypes.h> #include "gsm_ppp.h" #include "configuration.h" #include "utils.h" #include <dev/uartavr.h> #include <dev/ppp.h> #include <dev/chat.h> #include <dev/debug.h> #include <sys/heap.h> #include <sys/thread.h> #include <sys/socket.h> #include <sys/timer.h> #include <arpa/inet.h> #include <netdb.h> #include <net/if_var.h> #include <net/route.h> #include <netinet/ppp_fsm.h> #ifdef NUTDEBUG #include <net/netdebug.h> #endif #include <stdlib.h> #include <string.h> #include <fcntl.h> #include <io.h> #include "httpserv.h" #include "web.h" /* * PPP user and password. */ #define PPPUSER "yourUser" #define PPPPASS "yourPass" /* * Modem chat script */ #define PPPCHAT "'' AT+CGDCONT=1,\"IP\",\"yourAPN\" OK ATD*99***1# CONNECT" #define DISCONNECT "'' ATH OK" /* * PPP device settings. */ #define PPPDEV devUart0 /* Use standard UART driver. */ #define PPPCOM "uart0" /* Physical device name. */ #define PPPSPEED 115200 /* Baudrate. */ #define PPPRXTO 1000 /* Character receive timeout. */ extern u_char ppp_hackup; //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /** * Initializes the GSM/GPRS module and opens a PPP connection to the ISP. */ void PPPConnect(void) { int pppcom = -1; FILE * comm_phone = NULL; PPPDCB *dcb; u_long lctl; int ppp_attempts = 0, rc; // Register the UART device NutRegisterDevice(&PPPDEV, 0, 0); printf_P(PSTR("Open uart...")); comm_phone = fopen(PPPCOM, "r+"); if(!comm_phone) { printf("Failed to open " PPPCOM "\n"); for(;;); } printf_P(PSTR("done\n")); lctl = PPPSPEED; _ioctl(_fileno(comm_phone), UART_SETSPEED, &lctl); // Register PPP NutRegisterDevice(&devPpp, 0, 0); dcb = devPpp.dev_dcb; #ifdef NUTDEBUG /* * Optionally enable PPP trace. */ NutTracePPP(stdout, 1); //NutTraceTcp(stdout, 1); #endif NutSleep(5000); /* * PPP connection loop. */ for (;;) { if ((pppcom != -1) && (dcb->dcb_ipcp_state != PPPS_CLOSED)) { if (_close(pppcom) == 0) { ppp_hackup = 0; pppcom = -1; } DisconnectCall(comm_phone); } /* * Connect using a chat script. We may also set any * required hardware handshake line at this stage. */ printf_P(PSTR("Connecting...")); if ((rc = NutChat(_fileno(comm_phone), PPPCHAT)) != 0) { printf("no connect, reason = %d\n", rc); continue; } printf_P(PSTR("done\n")); if (pppcom == -1) { if ((pppcom = _open("ppp:" PPPCOM "/" PPPUSER "/" PPPPASS, _O_RDWR | _O_BINARY)) == -1) { printf_P(PSTR("Failed to open " PPPCOM "\n")); for (;;); } /* * Set PPP line speed. */ lctl = PPPSPEED; _ioctl(pppcom, UART_SETSPEED, &lctl); /* * The PPP driver doesn't set any receive timeout, but * may require it. */ lctl = PPPRXTO; _ioctl(pppcom, UART_SETREADTIMEOUT, &lctl); } printf_P(PSTR("Configure PPP...")); /* * We are connected, configure our PPP network interface. * This will initiate the PPP configuration negotiation * and authentication with the server. */ if (NutNetIfConfig("ppp", 0, 0, 0)) { printf_P(PSTR("failed\n")); // If we can't establish PPP 3 times in a row reboot ppp_attempts ++; ///if (ppp_attempts >= 3) //CDCS_Reboot(); continue; } printf_P(PSTR("ok\n")); /* * Set name server and default route. Actually the PPP interface * should do this, but the current release doesn't. */ dcb = devPpp.dev_dcb; NutDnsConfig2(0, 0, dcb->dcb_ip_dns1, dcb->dcb_ip_dns2); NutIpRouteAdd(0, 0, dcb->dcb_remote_ip, &devPpp); /* * Display our IP settings. */ printf_P(PSTR(" Local IP: %s\n"), inet_ntoa(dcb->dcb_local_ip)); printf_P(PSTR(" Remote IP: %s\n"), inet_ntoa(dcb->dcb_remote_ip)); printf_P(PSTR(" Primary DNS: %s\n"), inet_ntoa(dcb->dcb_ip_dns1)); printf_P(PSTR("Secondary DNS: %s\n"), inet_ntoa(dcb->dcb_ip_dns2)); printf_P(PSTR("Available mem: %u\n"),NutHeapAvailable()); // No DNS was supplied. if (dcb->dcb_ip_dns1 == 0) { printf_P(PSTR("No DNS supplied. Reconnect.\n")); ppp_attempts ++; continue; } // Execute the HTTP server. WebServer(); } } //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /** * Disconnect the GPRS call */ void DisconnectCall(FILE * comm_phone) { NutChat(_fileno(comm_phone), DISCONNECT); } //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /* GPRS-PPP.C Here is a quick sample of the GPRS - PPP connection procedure: For standard GPRS connections use yourAPN = internet ( vodafone ) and with blank username and password use if ((pppcom = _open("ppp:" PPPCOM, _O_RDWR | _O_BINARY)) == -1) instead of if ((pppcom = _open("ppp:" PPPCOM "/" PPPUSER "/" PPPPASS, _O_RDWR |_O_BINARY)) == -1) For the function "WebServer" you can cut and paste httpserv.c from: * * Register our device for the file system. */ NutRegisterDevice(&devUrom, 0, 0); onwards. Hope this will help you. */ #include <inttypes.h> #include "gsm_ppp.h" #include "configuration.h" #include "utils.h" #include <dev/uartavr.h> #include <dev/ppp.h> #include <dev/chat.h> #include <dev/debug.h> #include <sys/heap.h> #include <sys/thread.h> #include <sys/socket.h> #include <sys/timer.h> #include <arpa/inet.h> #include <netdb.h> #include <net/if_var.h> #include <net/route.h> #include <netinet/ppp_fsm.h> #ifdef NUTDEBUG #include <net/netdebug.h> #endif #include <stdlib.h> #include <string.h> #include <fcntl.h> #include <io.h> #include "httpserv.h" #include "web.h" /* * PPP user and password. */ #define PPPUSER "yourUser" #define PPPPASS "yourPass" /* * Modem chat script */ #define PPPCHAT "'' AT+CGDCONT=1,\"IP\",\"yourAPN\" OK ATD*99***1# CONNECT" #define DISCONNECT "'' ATH OK" /* * PPP device settings. */ #define PPPDEV devUart0 /* Use standard UART driver. */ #define PPPCOM "uart0" /* Physical device name. */ #define PPPSPEED 115200 /* Baudrate. */ #define PPPRXTO 1000 /* Character receive timeout. */ extern u_char ppp_hackup; //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /** * Initializes the GSM/GPRS module and opens a PPP connection to the ISP. */ void PPPConnect(void) { int pppcom = -1; FILE * comm_phone = NULL; PPPDCB *dcb; u_long lctl; int ppp_attempts = 0, rc; // Register the UART device NutRegisterDevice(&PPPDEV, 0, 0); printf_P(PSTR("Open uart...")); comm_phone = fopen(PPPCOM, "r+"); if(!comm_phone) { printf("Failed to open " PPPCOM "\n"); for(;;); } printf_P(PSTR("done\n")); lctl = PPPSPEED; _ioctl(_fileno(comm_phone), UART_SETSPEED, &lctl); // Register PPP NutRegisterDevice(&devPpp, 0, 0); dcb = devPpp.dev_dcb; #ifdef NUTDEBUG /* * Optionally enable PPP trace. */ NutTracePPP(stdout, 1); //NutTraceTcp(stdout, 1); #endif NutSleep(5000); /* * PPP connection loop. */ for (;;) { if ((pppcom != -1) && (dcb->dcb_ipcp_state != PPPS_CLOSED)) { if (_close(pppcom) == 0) { ppp_hackup = 0; pppcom = -1; } DisconnectCall(comm_phone); } /* * Connect using a chat script. We may also set any * required hardware handshake line at this stage. */ printf_P(PSTR("Connecting...")); if ((rc = NutChat(_fileno(comm_phone), PPPCHAT)) != 0) { printf("no connect, reason = %d\n", rc); continue; } printf_P(PSTR("done\n")); if (pppcom == -1) { if ((pppcom = _open("ppp:" PPPCOM "/" PPPUSER "/" PPPPASS, _O_RDWR | _O_BINARY)) == -1) { printf_P(PSTR("Failed to open " PPPCOM "\n")); for (;;); } /* * Set PPP line speed. */ lctl = PPPSPEED; _ioctl(pppcom, UART_SETSPEED, &lctl); /* * The PPP driver doesn't set any receive timeout, but * may require it. */ lctl = PPPRXTO; _ioctl(pppcom, UART_SETREADTIMEOUT, &lctl); } printf_P(PSTR("Configure PPP...")); /* * We are connected, configure our PPP network interface. * This will initiate the PPP configuration negotiation * and authentication with the server. */ if (NutNetIfConfig("ppp", 0, 0, 0)) { printf_P(PSTR("failed\n")); // If we can't establish PPP 3 times in a row reboot ppp_attempts ++; ///if (ppp_attempts >= 3) //CDCS_Reboot(); continue; } printf_P(PSTR("ok\n")); /* * Set name server and default route. Actually the PPP interface * should do this, but the current release doesn't. */ dcb = devPpp.dev_dcb; NutDnsConfig2(0, 0, dcb->dcb_ip_dns1, dcb->dcb_ip_dns2); NutIpRouteAdd(0, 0, dcb->dcb_remote_ip, &devPpp); /* * Display our IP settings. */ printf_P(PSTR(" Local IP: %s\n"), inet_ntoa(dcb->dcb_local_ip)); printf_P(PSTR(" Remote IP: %s\n"), inet_ntoa(dcb->dcb_remote_ip)); printf_P(PSTR(" Primary DNS: %s\n"), inet_ntoa(dcb->dcb_ip_dns1)); printf_P(PSTR("Secondary DNS: %s\n"), inet_ntoa(dcb->dcb_ip_dns2)); printf_P(PSTR("Available mem: %u\n"),NutHeapAvailable()); // No DNS was supplied. if (dcb->dcb_ip_dns1 == 0) { printf_P(PSTR("No DNS supplied. Reconnect.\n")); ppp_attempts ++; continue; } // Execute the HTTP server. WebServer(); } } //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ /** * Disconnect the GPRS call */ void DisconnectCall(FILE * comm_phone) { NutChat(_fileno(comm_phone), DISCONNECT); } //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
