Presentation Transcript


Slide1 l.jpg

UNDP – Government of Malaysia ProjectSupport for the development of accessible public transport in Penang

Kit Mitchell


Peninsula malaysia l.jpg

Viet Nam

Thailand

Penang

Island

Peninsula Malaysia

Rest of Pulau

Pinang

Singapore


Penang island l.jpg

Tourist beach area

George Town World Heritage Site

Penang Island

Mountain

10 miles

Industrial areas

Airport


Slide4 l.jpg

Penang IslandArea285 sq. km.Total population500,000+Old George Town220,000Greater urban area400,000Mainland part of StateArea753 sq. km.Population800,000


Old george town is mainly low rise l.jpg

Old George Town is mainly low-rise


Old george town is mainly low rise6 l.jpg

Old George Town is mainly low-rise


George town is a world heritage site l.jpg

George Town is a World Heritage Site


George town is a world heritage site8 l.jpg

George Town is a World Heritage Site


George town is a world heritage site9 l.jpg

George Town is a World Heritage Site


There was an excellent network of colonnaded pedestrian thoroughfares l.jpg

There was an excellent network of colonnaded pedestrian thoroughfares


Pedestrian colonnades l.jpg

Pedestrian colonnades


Slide12 l.jpg

The 12-month project aims to support the development of a fully accessible public transport system for Penang State, as a pilot for the rest of Malaysia.


Slide13 l.jpg

The project focuses on access audits of public transport facilities, capacity building and awareness raising activities.


In 2000 i felt that the main access problems were poor or no pedestrian footways and elderly buses l.jpg

In 2000, I felt that the main access problems were poor or no pedestrian footways, and elderly buses


George town street 2000 l.jpg

George Town street, 2000


Some things are still the same in 2009 l.jpg

Some things are still the same in 2009


Slide18 l.jpg

But a new bus operator is very professional, using modern vehicles, has well-trained staff, and has a purpose built bus terminal in Georgetown.


Slide24 l.jpg

A number of accessible sections of pedestrian footway have been built, and one street converted to space sharing


Existing accessible footways and crossings l.jpg

Existing accessible

Road crossings

Existing accessible footways and crossings

Bus and ferry terminal


Slide28 l.jpg

The improvements are having an effectBy December 2009, you could see wheelchairs and baby strollers in central George TownBus passengers have increased from 1,100,000 to 1,800,000 per four week period


Slide31 l.jpg

But:- Accessible footways are not well connected or continuous;- Main bus and ferry terminals do not connect to accessible footways;- Construction is often not to correct standards;- Maintenance is sometimes poor;- Enforcement of traffic and parking regulations is almost wholly lacking.


Lack of continuity of accessible footway at entrance to government building l.jpg

Lack of continuity of accessible footway at entrance to Government building


Kerb ramp less than 70 cm wide l.jpg

Kerb ramp less than 70 cm wide


Poor maintenance l.jpg

Poor maintenance


Kerb ramp blocked by incense burner l.jpg

Kerb ramp blocked by incense burner


Pedestrian colonnades blocked l.jpg

Pedestrian colonnades blocked


Ramp blocked by mppp flowerpot l.jpg

Ramp blocked by MPPP flowerpot


Footway and ramp blocked by parked vehicles l.jpg

Footway and ramp blocked by parked vehicles


Motorcycle following a blind pedestrian l.jpg

Motorcycle following a blind pedestrian


Slide40 l.jpg

From December 2009, cruise ships have been able to dock alongside in George Town There is no safe pedestrian link from the pier to the Heritage Site


Exit from pier for cruise ships l.jpg

Exit from pier for cruise ships


Slide43 l.jpg

Improvements the UNDP study will recommend include:- Connectivity of footways; - Connect bus and ferry terminal to footway network; - Pedestrian link to pier for cruise ships;- Start work on demonstration bus corridor.


World heritage site priorities for improvements to footways l.jpg

World Heritage Site: priorities for improvements to footways


Improvements to footways and road crossings l.jpg

Existing accessible

1st priority

Improvements to footways and road crossings

Road crossings

Pier

Bus and ferry terminal


Slide46 l.jpg

The first priority improvements (shown red) are estimated to cost 814,000 MR (about $230,000 US)Work on improvements started in December 2009


Installing kerb ramps kerb height 12 inches l.jpg

Installing kerb ramps (kerb height 12 inches)


Slide48 l.jpg

I now feel that providing accessible infrastructure and vehicles is relatively easy, but institutional problems are very difficult - When ramp kerbs are fitted, motorcycles ride along the footway; - Police do not enforce traffic and parking regulations;- Buses do not stop close to the kerb.


Motorcycle behaviour l.jpg

Motorcycle behaviour


Parking at bus stops l.jpg

Parking at bus stops


Failing to stop close to the kerb l.jpg

Failing to stop close to the kerb


Failing to stop close to the kerb52 l.jpg

Failing to stop close to the kerb


Failing to stop close to the kerb53 l.jpg

Failing to stop close to the kerb


Failing to stop close to the kerb54 l.jpg

Failing to stop close to the kerb


Failing to stop close to the kerb55 l.jpg

Failing to stop close to the kerb


Failing to stop close to the kerb56 l.jpg

Failing to stop close to the kerb


The reasons bus drivers stop away from the kerb are l.jpg

Stops are often blocked by parked vehicles;- Stops have railings that prevent passengers boarding and alighting;- Geometry of stops in lay-bys makes it impossible for drivers to get close;- Bus stop shelter roofs overhang kerb.

The reasons bus drivers stop away from the kerb are:


Slide58 l.jpg

I have suggested the use of bus stop boarders (bus stop bulbs) without railings to make it easy for drivers to stop close to the kerb, and to prevent vehicles driving through the line of passengers


Accessible bus stops consider using kerb extensions at bus stops bus boarders l.jpg

Accessible bus stopsConsider using kerb extensions at bus stops(bus boarders)


Bus boarder in belfast l.jpg

Bus boarder in Belfast


Slide61 l.jpg

Because traffic does not stop at pedestrian crossings, I have suggested the use of median pedestrian refuges at crossings


For lower priority pedestrian crossings median pedestrian refuges offer benefits l.jpg

For lower priority pedestrian crossings, median pedestrian refuges offer benefits

Pedestrian refuge on 40mph (64kph) suburban road, Britain


Slide63 l.jpg

Perhaps most important, I am urging a long-term programme of institutional change, involving education and enforcement, to support the excellent engineering already in place


Slide64 l.jpg

This includes changes within the local authority, to encourage regular inspection and maintenance of footways, control of retail intrusion onto footways, and control of unapproved construction on footways and blocking colonnades.


Slide65 l.jpg

Only time will tell whether the improvements in accessibility can be protected from road user behaviour, lack of enforcement and lack of inspection and maintenance.


Slide66 l.jpg

This project has made me realise that, as experts on accessibility, we are not paying enough attention to the social differences between countries, and the need to design transport to be suitable for local situations.


I hope this raises an issue for discussion l.jpg

I hope this raises an issue for discussion.
