  1. ACTAR GEMs readout proposal with ASIC & ADC per pad.

  2. GEMs pcb Beam Pad readout Cooling for the electronics Serial communications & Power distribution

  3. Board design in progress • Prisma SED with Gassiplex • Single channel development with PreShape32, FREDA.

  4. GASSIPLEX 32 channel board under test. • MAXIM Flash ADC evaluation board with Virtex2 FPGA for readout conversion, and GASSIPLEX control • Parallel connection between the two FPGAs • Virtex2Pro development board on loan from RAL with link to PC via Ethernet. 1 2 3 4 Current Test setup
