  1. Ionic Compounds: Naming

  2. Naming Binary Ionic Compounds • Always name metal (the cation/+ ion) first 2. Write stem of nonmetal (the anion/ - ion) 3. Add ending “ide” to nonmetal

  3. Nitr Ox Fluor Phosph Sulf Chlor Arsen Selen Brom Tellur Iod Hydr is the stem for H Stems of nonmetals

  4. The First Step in Naming • Find metal on PT • If metal has only one oxidation state it’s easy • If metal has more than one oxidation state, there’s an extra step

  5. Metals with one oxidation state • CaO • BaS • AlN • LiCl • Al2Se3 • Na2O • K3N • MgF2 Calcium Oxide Barium Sulfide Aluminum Nitride Lithium Chloride Aluminum Selenide Sodium Oxide Potassium Nitride Magnesium Fluoride

  6. Metals with > 1 oxidation state • Use formula to figure out which oxidation state metal ion has • Ex: Fe can be Fe+2or Fe+3 • Name FeO and Fe2O3 • two different compounds • cannot name both iron oxide • every formula has 1 name only

  7. FeO and Fe2O3 • Compounds are electrically neutral • Oxygen is -2 1 O which is -2 FeO so Fe must be +2 Name: Iron (II) oxide (roman numeral II = charge on Fe)

  8. Each Fe is +3 Iron (III) oxide FeO and Fe2O3 • Compounds are electrically neutral • Oxygen is -2 Each O is -2 Fe2O3 There are 3 O’s 3 X (-2) = -6 Total negative charge Total positive charge must be +6

  9. Name the following Titanium (III) chloride • TiCl3 • Mn2O4 • Co2O3 • PdBr2 • AuCl3 • MoN • MnO • TiO Manganese (IV) oxide Cobalt (III) oxide Palladium (II) bromide Gold (III) chloride Molybdenum (III) nitride Manganese (II) oxide Titanium (II) oxide

  10. SO42- CO32- PO43- OH- POLYATOMIC IONS • group of covalently bonded atoms that have a charge • Table E: (+)’ve or (–)’ve • polyatomic ions have “names” • (-) polyatomic ions can form ionic bonds with (+) metal ions

  11. Ternary Compounds • contain 3 or more elements • usually contain a polyatomic ion • if polyatomic is (+) it’s bonded to a nonmetal • if polyatomic is (–) it’s bonded to a metal • sometimes 2 polyatomics are bonded together

  12. Formulas with polyatomics • What’s the formula for the compound formed from Al+3 and SCN-1? • The charges must add up to zero, so write the symbols, positive first! AlSCN3

  13. Try a few more: NaOH • Na+1 and OH-1 • K +1 and HCO3-1 • Mg+2 and CO3-2 • Li +1 and NO3-1 • Ca+2 and SO4-2 KHCO3 MgCO3 LiNO3 CaSO4

  14. These are more challenging: Mg3(PO4)2 • Mg+2 and (PO4)-3 • Al+3 and (NO3)-1 • Fe+2 and OH-1 • Hg2+2 and SCN-1 • Mg+2 and HCO3- • Al+3 and C2O42- Al(NO3)3 Fe(OH)2 Hg2(SCN)2 Mg(HCO3)2 Al2(C2O4)3

  15. Some of the most challenging are Zn(NO3)2 • Zinc + Nitrate ion • Magnesium + Hydroxide ion • Lithium + Carbonate ion • Potassium + Sulfate ion • Calcium + Phosphate ion • Beryllium + Chlorate ion Mg(OH)2 Li2CO3 K2SO4 Ca3(PO4)2 Be (ClO3)2

  16. Naming compounds with polyatomics • polyatomic ions have names (Table E) • naming is parallel to binary naming • positive always written first • if (+)’ve ion is a metal, check to see how many oxidation states it has • if > 1 then name must have roman numeral • if (–)’ve is polyatomic - 2nd part of name is name of polyatomic (don’t modify ending)

  17. Name the following Sodium hydroxide • NaOH • KHCO3 • LiNO3 • CaSO4 • Al(NO3)3 • Fe(OH)2 • CuSO4 • CuSCN Potassium hydrogen carbonate Lithium nitrate Calcium sulfate Aluminum nitrate Iron (II) hydroxide Copper (II) sulfate Copper (I) thiocyanate

  18. Summary for Binary Ionic Compounds • Compounds are electrically neutral • Formula: positive first • If metal has more than 1 oxidation state, name has roman numeral • Name = metal + stem of nonmetal + ide
