  1. SECTION VIEW QUIZ Write your name on your paper!

  2. 1.) What is the purpose of Sectional Views?

  3. 2.) Draw a Cutting plane Line

  4. 3.) Where does Sectional Lining go?

  5. 4.) Where does the sectional view go in relationship to the Cutting Plane Line?

  6. 5.) What is it called when we only show the inside of half the view?

  7. 6.) When looking at a section of an assembly, how can I tell that it is made of more than one material?

  8. 7. ) In mechanical drawing, what is the furthest apart the lines should be in sectional lining?

  9. 8.)Which type of line should be the heaviest, darkest, and stand out the most on your paper?

  10. 9.) What angle does the path of the Cutting Plane turn for an Offset Section?

  11. 10.) What must you do to place the section view any where other then in the adjacent view behind the arrows of the CPL? ?

  12. BONUS.) Where does the left side view go in relationship to the the Front side view? ?

  13. Sectional Views Quiz Exchange quiz’s w/ someone sitting next to you • Check to see their name and period is on top • Place your initials on the bottom • Clearly mark any unanswered question wrong before we get started

  14. 1.) What is the purpose of Sectional Views? • Show the inside to avoid confusion

  15. 2.) Draw a Cutting plane Line

  16. 3.) Where does Sectional Lining go? • on surfaces that touch the Cutting Plane.

  17. 4.) Where does the sectional view go in relationship to the Cutting Plane Line? • In the adjacent view behind the arrows! (or a clearly labeled removed view)

  18. 5.) What is it called when we only show the inside of half the view? • Half Section

  19. 6.) When looking at a section of an assembly, how can I tell that it is made of more than one material? • The Sectional Lining is at different angles for each material (or different Hatch patterns for each material)

  20. 7. ) In mechanical drawing, what is the furthest apart the lines should be in sectional lining (aka cross hatch)? • 3/16”

  21. 8.)Which type of line should be the heaviest, darkest, and stand out the most on your paper? • Cutting Plane Line

  22. 9.) What angle does the path of the Cutting Plane turn for an Offset Section? 90° turn

  23. 10.)What must you do to place the section view any where other then in the adjacent view behind the arrows of the CPL? • label the drawing & reference it behind/or alongside the arrows of the CPL and the page # if on a different page

  24. BONUS.) Where does the left side view go in relationship to the the Front side view? • DIRECTLY TO THE LEFT
