  1. AMPL AMathematical Programming Language Presentation #2

  2. Outline • Reasons for using two files • Sets • Format of .dat files • Example • Logical Operators

  3. Limitations • In a LP with many constraints, it’s a hassle to add new variables • It may be difficult to find a coefficient that needs to be changed • Files can get very large • Solution: Use a .dat file

  4. Sets

  5. Advantages • It’s easy to add extra parameters • It’s more natural, notation-wise, in that you can use summation notation • It allows the data to be changed easily, or it even allows the model to be run with different sets of data

  6. Definition • A set is defined at the beginning of the model (.mod) file as: set SETNAME; • Nothing else needs to be added; the size and the members of the set are declared in a different place

  7. Implementation • Now we want to use the set in the model. • To declare a parameter that takes on a value for each member of the set: param PARAMETER {i in SETNAME}; • Or, even better: param PARAMETER {SETNAME}; • These parameters can then be accessed just like an array in other programming languages

  8. Summations • While writing an objective function, it is more compact to write it as a sum. • If the set is declared above, then the syntax is very intuitive: param cost {SETNAME}; var MAKE {SETNAME}; maximize COST: sum {i in SETNAME} cost [i]*MAKE [i]; • Notice that there are no parenthesis around the objective function; the * operator has higher precedence than the sum operator.

  9. Constraints • If you need to base the number of constraints on the elements of the set, say if there is an upper bound on each variable (VAR): subject to UPPERBOUND {i in SETNAME }: VAR [i] <= UB [i]; • This will create |SETNAME | constraints.

  10. A very simple example set CHARS; param worth {CHARS} >=0; param avail {CHARS} >=0; param totalAvail >=0; var hours {i in CHARS} >=0, <= avail[i]; maximize WORK: sum {i in CHARS} hours[i]*worth[i]; subject to AVAILIABLE: sum {i in CHARS} hours[i] <= totalAvail;

  11. No Numbers?! • You may have noticed that the previous slide had no numbers. • So how does the solver know which values we intend for the parameters? • We have to create a data file, a file with extension .dat

  12. General Format • A lot of the data in a data file is presented in tables. • The naming convention has to be identical, down to case because AMPL is case sensitive. • Start a data file by naming all sets used in the model. set CHARS := Homestar StrongMad Trogdor; • Note that there are no commas, and it ends with a semicolon

  13. General Format (Cont) • Then any parameters need to be defined. param: worth avail := Homestar 7 8 StrongMad 2 16 Trogdor 10 3; • The parameter names go along the top and the set elements are along the side.

  14. General Format (Cont) • Finally, any parameters that are independent from the set are declared: param totalAvail := 14;

  15. Put it all together... set CHARS := Homestar StrongMad Trogdor; param: worth avail := Homestar 7 8 StrongMad 2 16 Trogdor 10 3; param totalAvail := 14;

  16. Into AMPL • We know how to input model files into AMPL. How do we do data files? • The same way! model Homestar.mod; data Homestar.dat; • If there is an error in the data file, the compiler will let you know.

  17. Output • After executing our simple example, AMPL outputs: ampl: model Homestar.mod; ampl: data Homestar.dat; ampl: solve; MINOS 5.5: optimal solution found. 3 iterations, objective 92

  18. Display • It is easier to display the variable values when a set is declared. • Instead of typing display hours[Homestar] hours[StrongMad] hours[Trogdor]; • We can just type ampl: display hours; hours [*] := Homestar 8 StrongMad 3 Trogdor 3 ;

  19. The power of sets • Now, say we want to add one character to our previous example. • Before sets, this would have been very difficult. • Now, it’s a breeze.

  20. Adding Marzipan • All we need to do is change the .dat file: set CHARS := Homestar StrongMad Trogdor Marzipan; param: worth avail := Homestar 7 8 StrongMad 2 16 Trogdor 10 3 Marzipan 9 4; • That’s it!

  21. Output • After running the same model with the new data, we get: MINOS 5.5: optimal solution found. 3 iterations, objective 115 ampl: display hours; hours [*] := Homestar 7 Marzipan 4 StrongMad 0 Trogdor 3 ; • We could have kept the same session of AMPL open, and used the command reset data; This would allow us to use the same model with different data.

  22. Logical Operators • Simple logical statements are common in problems • AMPL allows us to use simple logical statements such as: • Binary variables (true or false) • IF-THEN • IF-THEN-ELSE

  23. Logical Example • Say that all of the variables have a fixed upper bound, but one of the variables has twice that. • Then you can use the IF-THEN-ELSE to introduce this constraint. subject to UB {i in SETNAME }: variable[i] <= 10*(if i=1 then 2 else 1);
