Area and speed oriented implementations of asynchronous logic operating under strong constraints

Area and Speed Oriented Implementationsof Asynchronous LogicOperating Under Strong Constraints

Igor Lemberski

Baltic InternationalAcademy

Riga, Latvia

e-mail: [email protected]

Petr Fišer

Czech Technical University in Prague

Faculty of Information Technology

e-mail: [email protected]


Outline
Outline

  • Asynchronous circuits model used

  • Motivation & proposed method

  • Experimental results

  • Conclusions

EUROMICRO DSD 2010, Lille


Asynchronous circuits model used
Asynchronous Circuits Model Used

  • Unbounded delay model

    • Gate and wire delays are not limited

    • The circuit is able to recognize the moment when input states have changed

    • Dual-rail encoding

      Positive and negative values of each signal are provided

    • f(0) = 1, f(1) = 0 – log. 1

    • f(0) = 0, f(1) = 1 – log. 0

    • f(0) = 0, f(1) = 0 – space state (spacer)

    • f(0) = 1, f(1) = 1 – not allowed

EUROMICRO DSD 2010, Lille


Four phase discipline
Four-Phase Discipline

Inputs in space state (00)

Outputs in working state (10, 01)

Outputs in space state (00)

Inputs in working state (10, 01)

EUROMICRO DSD 2010, Lille


Seitz s constraints
Seitz’s Constraints

Strong constraints

  • Each output changes its state only when all inputs have changed their state

    In contrast to weak constraints

  • Some outputs are permitted to change their state when some inputs have changed their state

EUROMICRO DSD 2010, Lille


Seitz s constraints1
Seitz’s Constraints

Strong constraints

  • Each output changes its state only when all inputs have changed their state

    In contrast to weak constraints

  • Some outputs are permitted to change their state when some inputs have changed their state

EUROMICRO DSD 2010, Lille


Seitz s strong constraints
Seitz’s Strong Constraints

Pros

  • Regularity

  • Extra completion detection logic not needed

  • Circuit delay is based on actual gate delays

  • No additional synchronization chains

    Cons

  • Rather high area and delay

  • DIMS (Delay-Insensitive Minterm Synthesis)

  • NCL (Null Convention Logic)

  • Direct Logic

  • EUROMICRO DSD 2010, Lille


    Dims delay insensitive minterm synthesis
    DIMS (Delay-Insensitive Minterm Synthesis)

    • 2-level implementation

    • 2n n-input C-elements + n-input OR

       Function implemented as sum-of-minterms

    EUROMICRO DSD 2010, Lille


    Ncl null convention logic
    NCL (Null Convention Logic)

    • Library of 27 special gates

    • Based on threshold functions

    • Any function up to 4 inputscan be implemented

      … but in dual-rail, 4 inputs = 2 variables only

    EUROMICRO DSD 2010, Lille


    Direct logic
    Direct Logic

    • Two‑level C-OR DIMS logic implemented as a single gate

    • Both positive and complemented outputs are provided

    • Different delays for each input

    EUROMICRO DSD 2010, Lille


    Comparison
    Comparison

    EUROMICRO DSD 2010, Lille


    Multi level dual rail network
    Multi-Level Dual-Rail Network

    • Positive and complemented values of each signal provided

    • Each node implemented as DIMS, NCL, or Direct logic

    EUROMICRO DSD 2010, Lille


    Motivation proposed method
    Motivation & Proposed Method

    State-of-the-art

    • Nodes are implemented as simple gates (NAND, XOR)

    4x 2-input gate = 22*4 = 88 transistors in Direct logic

    EUROMICRO DSD 2010, Lille


    Motivation proposed method1
    Motivation & Proposed Method

    Proposed

    • Nodes are implemented as complex gates

    1x 2-input gate + 1x 3-input gate = 22 + 34 = 56 transistors

    EUROMICRO DSD 2010, Lille


    Motivation proposed method2
    Motivation & Proposed Method

    State-of-the-art

    • Nodes are implemented as simple gates (NAND, XOR)

      Proposed

    • Nodes are implemented as complex gates, i.e. gates of a given number of inputs and any function

    • Can be implemented both in DIMS and Direct logic

    • Like FPGA LUTs

    • Tools for synchronous synthesis can be used

       FPGA mapping

    EUROMICRO DSD 2010, Lille


    Where s the problem
    Where’s the Problem?

    Facts:

    Increase of the number of node inputs will:

    • Decrease the number of nodes

    • Decrease the number of levels

    • Increase the node size

    • Increase the node delay

      Question:

      Where is the trade-off?

    EUROMICRO DSD 2010, Lille


    Experimental setup
    Experimental Setup

    • 228 circuits processed (MCNC, ISCAS)

    • Optimized by ABC choice script

      • Mapped into k-input NANDs (ABC map command)

         state-of-the-art (k-NAND)

      • Mapped into k-LUTs (ABC fpga command)

         complex gates (k-CG)

      • Mapped into MCNC standard cells (ABC map) something in-between (SC)

        k = 2…6

    • Implemented as DIMS, Direct logic, and NCL

    EUROMICRO DSD 2010, Lille


    Results dims area
    Results – DIMS - Area

    EUROMICRO DSD 2010, Lille


    Results dims area1
    Results – DIMS - Area

    EUROMICRO DSD 2010, Lille


    Results dims delay
    Results – DIMS – Delay

    EUROMICRO DSD 2010, Lille


    Results dims delay1
    Results – DIMS – Delay

    EUROMICRO DSD 2010, Lille


    Discussion dims
    Discussion - DIMS

    Implementation using arbitrary 2-input gates is the best one, both in area and delay

    • No big surprise. Complexity (and delay)of DIMS grows exponentially with the number of gate inputs

    • Results are consistent – the more node inputs, the higher area and delay

    EUROMICRO DSD 2010, Lille


    Results direct logic area
    Results – Direct Logic - Area

    EUROMICRO DSD 2010, Lille


    Results direct logic area1
    Results - Direct Logic - Area

    EUROMICRO DSD 2010, Lille


    Results direct logic delay
    Results – Direct Logic - Delay

    EUROMICRO DSD 2010, Lille


    Results direct logic delay1
    Results – Direct Logic - Delay

    EUROMICRO DSD 2010, Lille


    Discussion direct logic
    Discussion - Direct Logic

    Implementation using 3-input complex gates is the best one, both in area and delay

    • This is a good result confirming our theory

    • Results are consistent - no coincidence

    • State-of-the-art 2-NAND implementation is extremely inefficient:

      • 21% area improvement

      • 19% delay improvement

    • 3-CG implementation is even better than NCL

      • 10% area improvement

      • 19% delay improvement

    EUROMICRO DSD 2010, Lille


    Conclusions
    Conclusions

    • Efficient implementation of asynchronous logic operating under strong constraints proposed

    • Tools (& methods) for synchronous synthesis are used for asynchronous synthesis

    • 3-input complex nodes implemented using Direct logic

    • Extensive experiments confirmed the theory

    • cca. 20% area and delay improvement vs. all state-of-the-art methods

    EUROMICRO DSD 2010, Lille
