第四章 钢筋混凝土工程. 第二节 钢 筋 工 程. 钢筋的种类及性能 1 、按 化学成分 : 1 )碳素钢筋 低碳钢钢筋 ( 含碳量  0.25 ) , 中碳钢钢筋 ( 含碳量为 0.25 %  0.6 ) , 高碳钢钢筋 ( 含碳量大于 0.6 % ) 2) 普通低合金(合金元素 <5% ) 2 、按轧制外形分:光圆钢筋 变形钢筋--螺纹、月牙纹 3 、按作用分:受拉(压)钢筋、架立钢筋、分布钢 筋、箍筋、吊筋、腰筋、构造筋、锚固筋等.
