Best practices for oracle database 10g rac on microsoft 64bit windows l.jpg

Best Practices for Oracle Database 10g RAC on Microsoft 64bit Windows

Philip Newlan

Principal Product Manager - RAC

[email protected]

Anu Chawla

Program Manager – Oracle Alliance

[email protected]


Slide2 l.jpg

<Insert Picture Here>

Microsoft / Oracle

Relationship


Commitment to windows l.jpg

Commitment to Windows

  • Oracle7 was the first database to ship on Windows

    • in 1994

  • Windows Server is a base development platform for Oracle

  • Windows Server is Tier 1

    • fully supported platform for Oracle

  • Focused Engineering and Product management groups for Windows-specific integration projects

  • Supported both 32-bit and 64-bit Windows Server 2003 on day of O/S release


Partnership l.jpg

Partnership

  • Oracle sponsors Microsoft events

    • (TechEd 2004, 2005, 2006)

  • Microsoft sponsors Oracle events

    • OracleWorld, UKOUG 2006,2007

  • Oracle RAC Training Sessions at MS Redmond campus

  • Demos in the ETC

  • Communication channels open at various levels in the organizations

  • Joint support contacts for customer escalations

    • How we jointly solve problems

  • Conference calls, briefings, etc.


Register at microsoft oracle customer information center www microsoft oracle com l.jpg

Register at Microsoft Oracle Customer Information Center:www.microsoft-oracle.com

Best Practices on running Oracle on Windows Server

Replay and Presentations of Oracle RAC on Windows Server Workshop

Invitations to Global Technical Workshops hosted by Microsoft and Oracle

Certification information for Oracle Applications and technology on Microsoft Platform


Oracle on windows widely deployed l.jpg

Oracle on WindowsWidely Deployed

Oracle Revenues by OS for new license sales

Other 2%

Unix 49%

Windows 29%

Source: Gartner Research –

May 2005 ID G00127787

Linux 20%


State of the market l.jpg

State Of The Market?

Microsoft Momentum

LinuxGrowthSlows

Windows Growth atx86 Pace

VAP/VARPreferenceImproves

Industry Trends

  • Continuum of non-commercial software to commercial integration

  • Broad interoperability movement

  • Competing at the workload level Windows #1 platform for UNIX migrations

    • 44% Windows versus 37% Linux

  • Virtualization and consolidation


State of the market8 l.jpg

State Of The Market?

Microsoft Momentum

LinuxGrowthSlows

Windows Growth atx86 Pace

VAP/VARPreferenceImproves

Industry Trends

  • Continuum of non-commercial software to commercial integration

  • Broad interoperability movement

  • Competing at the workload level Windows #1 platform for UNIX migrations

    • 44% Windows versus 37% Linux

  • Virtualization and consolidation


Load test windows 2003 v red hat 4 0 64 bit l.jpg

Load TestWindows 2003 v Red Hat 4.0 (64 bit)

  • RAC Stress Test (150-250 users)

    • Transactions Per Minute were up to 16% higher for MS Windows for 150 - 250 users.

    • The response times for the “Order Products” test component were up to 50% faster for MS Windows than Linux, and the response times for the “Order Products” component increased substantially above 150 users.

    • At 250 users, Linux performed over 30% of sorts on disk instead of sorts in memory.

    • For all of these tests, Linux used 17% - 40% more memory than MS Windows Server.

  • RAC User Load Tests (2500 – 4500 users)

    • At 3500 users, the Transactions Per Minute for MS Windows were 18% higher than the Linux Transactions Per Minute.

    • At 4000 users, MS Windows Server TPM continued to increase while the Linux test failed to complete.

    • At 2500 users, component response times were 9% - 33% faster for MS Windows Server; while at 3500 users Windows was faster by a wide margin.

    • For all of these tests, Linux used 5% - 25% more memory than MS Windows Server.


Supported 32 bit architectures l.jpg

Supported 32-bit Architectures

  • For 32-bit x86 systems

  • Well-suited for mainstream deployments where 64-bit applications or drivers are unavailable

  • Most common on servers with 1-4 processors


Supported 64 bit architectures l.jpg

Gradually replaces 32-bit Windows as mainstream offering

Suitable for all workloads

Well-suited for combining 32-bit and 64-bit software

Intended for the most demanding Database and LOB deployments on 8-way+

Designed for pure 64-bit software stacks

Supported 64-bit Architectures


32 bit vs 64bit memory limits l.jpg

32 bit Vs 64bit Memory Limits

  • Product names listed are for general reference only and do not reflect actual product names. 64-bit

  • Windows Server Standard Edition will be available for x64 only.


Architecture thread and memory model 32bit windows l.jpg

SGA contains

db buffers,

log buffers

shared pool,

other memory

allocations

Each thread

consists of

PGA, stack,

other memory

allocations

Architecture – Thread and Memory Model32bit Windows

Oracle process

SGA

2GB

Background and foreground threads

Code


Architecture thread and memory model 64bit windows l.jpg

SGA contains

db buffers,

log buffers

shared pool,

other memory

allocations

Each thread

consists of

PGA, stack,

other memory

allocations

Architecture – Thread and Memory Model64bit Windows

Oracle process

SGA

8TB

Background and foreground threads

Code


Slide16 l.jpg

<Insert Picture Here>

Oracle Support for MS Windows


Windows 32 bit platform support l.jpg

Windows 32-bit Platform Support


Windows 64 bit platform support l.jpg

Windows 64-bit Platform Support


Windows vista support l.jpg

Windows Vista Support

  • Next Major Database Release

    • 32-bit support

    • 64-bit support ( for x64 systems)

  • 10gR2

    • Plan to certify and support 32-bit Client and Server

    • Latest Patchset plus possible patches – exact requirements will be documented when certification is completed and announced


Slide20 l.jpg

<Insert Picture Here>

Oracle Architecture


Database architecture process and memory l.jpg

Database ArchitectureProcess and Memory

  • Thread model, not a straight port of Oracle’s process architecture

  • 3GB (32-bit) or 8TB (64-bit) maximum memory per database instance. VLM support allows >3GB on 32-bit.

  • Runs as a Windows service process

  • No limits on memory, connections, resources except those imposed by the operating system

  • What does 8GB Process Address space give you ?

    • Connections

    • Datawarehousing improvements


Database architecture file i o l.jpg

Database ArchitectureFile I/O

  • Oracle10g supports asynchronous I/O to all types of files

  • Logical and physical raw files and partitions are fully supported (faster than NTFS)

  • Full 64-bit file I/O internally

    • No 2GB or 4GB limitations on database file sizes.

    • Maximum file size is 64GB

    • Maximum database size is 4 petabytes


Dual core and hyperthreading l.jpg

Dual Core and Hyperthreading

ü

  • Dual Core support

    • Supported – Oracle uses the OS scheduler

    • All versions of Oracle are supported in Hyperthreaded environments.

  • Hyperthreading

    • Circuitry added to Intel CPUs resulting in single CPU functioning as 2 CPUs

    • All versions of Oracle are supported in Hyperthreaded environments.

  • Customer 10 node RAC

    • 4 Dual cores with hyperthreading turned on

      • 16 CPU’s visible in taskmanager on each of 10 nodes

    • 32GB RAM per node - 200TB database

?


Slide24 l.jpg

<Insert Picture Here>

Best Practices for 64 bit Windows


Oracle on 64 bit windows l.jpg

Oracle on 64-bit Windows

  • Long history of supporting 64-bit databases on other platforms

  • Interoperability between 32-bit clients and 64-bit servers and vice versa

  • Improved performance, availability and scalability

  • Why do customers choose to migrate to 64bit Windows ?


64 bit best practices l.jpg

64-Bit Best Practices

  • Run correct 64-Bit version of Oracle for the architecture

    • 64-Bit Oracle for X64 (AMD or EM64T)

    • 64-Bit Oracle for Itanium.

  • 32-Bit Oracle Server not supported on 64-Bit platforms

  • Enable Large Pages


Slide27 l.jpg

New for Windows Server 2003 SP1

  • Large Page support

    • For instances with large memory requirements, large page support can improve performance

      • 32 bit – 4kb default – 2MB max

      • 64 bit – 8kb default – 2MB on x64 -16 MB on IA64

  • NUMA support for memory/scheduling

    • Database intelligently allocates memory and schedules threads based on node configuration

    • Best Practice: For NUMA on AMD patch to a minimum 10.2.0.2 P5

ü


64 bit migration l.jpg

64-bit: Migration

  • 32-bit to 64-bit upgrade process is simple

    • 32-bit data files are compatible with 64-bit DB

  • No need to recreate the database

  • Full export and import not required

  • Database Upgrade Assistant automates process

  • Transparent migration for end-user applications

    • No changes required to existing client applications when running against 64-bit database


File system best practices l.jpg

File System Best Practices

ü

  • Use ASM – whether single-instance or RAC – use 10.1.0.4 or higher

  • Provisioning storage when you need it… and save money

    • No need to move datafiles around

    • No need to take tablespaces offline

    • Allocate what you need, when you need it

    • Simple to add or remove

      • Add disks with no downtime

    • Save time and money

ASM Disk Group

% utilization

Ctrl file, redo log, data 1,…data n


Where do i locate my datafiles l.jpg

Where do I locate my datafiles ?

  • 10g Windows RAC tracked customers


Slide31 l.jpg

<Insert Picture Here>

Management & Diagnostics tools


Grid control l.jpg

Grid Control


Out of the box database control l.jpg

Out of the Box Database Control

  • No client install required

  • Fully functional after database creation

  • Discovery, Configuration & Monitoring

    • Listener

    • ASM

    • RAC database


Diagnostic tools performance monitor l.jpg

Diagnostic Tools - Performance Monitor


Process explorer l.jpg

Process Explorer


Tools l.jpg

OS Tools

MS Tools

diskpart

poolmon

memsnap

tasklist, taskkill

tlist (with -c)

Driverquery - with /V

sc (sc query state= all)

Sysinternals

regmon, filemon, procexp, tcpview

Windows Services for Unix

Oracle Tools

srvctl

crsctl

ocrdump

crs_stat

cluvfy

Tools


Cpu tuning l.jpg

CPU Tuning

  • Oracle uses all processors available through the OS

  • ORACLE_AFFINITY registry value can be set to tell Oracle which threads to run on which processors (same setting for all instances)

  • Thread priorities can be set in the registry using the ORACLE_PRIORITY variable


Cpu tuning diagnosing high cpu l.jpg

CPU Tuning – Diagnosing High CPU

  • Process Explorer

    • drill down to threads

    • Get thread id of high CPU thread

  • Use following to map OS Thread Id to Oracle Background Process

    SELECT a.spid, b.username

    FROM v$process a, v$session b

    WHERE a.addr= b.paddr

    AND a.spid = <thread number>


Networking best practices l.jpg

Networking Best Practices

  • The default queue-size for Windows Server is 50 – increase using QUEUESIZE parameter in LISTENER.ORA – prevents errors during login storms

  • Use multiple listeners for increased throughput

  • Increase SDU_SIZE in SQLNET.ORA or TNSNAMES.ORA

    • Controls SQL*Net packet size

    • Set to larger SDU size for apps with bulk data transfer (LOBS, Dataguard etc). Perhaps 32k


Networking best practices40 l.jpg

Networking Best Practices

  • SQLNET.AUTHENTICATION_SERVICES=(NTS) This is a default value in SQLNET.ORA for a reason – it should be left at default. – Required for RAC

  • In 10.2.x, SQLNET.INBOUND_CONNECT_TIMEOUT defaults to 60 – this may need to be set to 0 in some situations

ü


Slide41 l.jpg

<Insert Picture Here>

Installation and Patching

Best Practices and Support’s Top Issues


Installation pre reqs l.jpg

Installation Pre-reqs

  • Hardware is set up correctly

  • Use the Cluster Verification Utility (CVU).

  • User Accounts

  • Remote Desktop Client.

  • Environment Variables

  • Networking

  • Disk Layout

  • Enable Automount

  • Stop ‘troublesome’ Services.

  • Time Sync


Install remote desktop client l.jpg

Install - Remote Desktop Client

  • If you must use the remote desktop client

    • Invoke the client with the /console command line parameter


Cluster verification utility cvu l.jpg

Cluster Verification Utility - CVU

  • CVU checks and reports on varies configuration items at various steps during the install

    • Does not fix anything !

  • Get the latest version from OTN

    • http://otn.oracle.com/rac - Right Hand Side - CVU

  • Two steps to run prior to starting install

    • runcluvfy stage -post hwos -n iwinrca01,iwinrca02

    • runcluvfy stage -pre crsinst -n iwinrca01,iwinrca02

  • Other steps as required


Cluster verification utility l.jpg

-pre dbcfg

Configures

RAC DB

-pre dbinst

Installs

RAC

-pre crsinst

Installs

Oracle Clusterware

-post crsinst

-pre cfs

Sets up OCFS

( OPT )

-post cfs

User sets up the

Hardware,

network & storage

-post hwos

Cluster Verification Utility


Most common support issues l.jpg

Most Common Support Issues

  • Oracle can be installed (and patches applied) over a remote connection.

  • Try installing on the server console directly, to determine if the problem is with the remote connection utility.

  • Logging into Windows as a user account, with Admin privs, is not identical as to logging in as the Local Administrator account. If there are problems installing, try using the Local Administrator account.


Most common support issues47 l.jpg

Most Common Support Issues

  • Files in use errors:

    • Must stop ALL Oracle Services.

    • Stop the DTC (Distributed Transaction Coordinator) service.

    • Use Process Explorer to find the process using the Oracle files.

  • Problems running catpatch.sql or catcpu.sql:

    • Verify there are NO invalid objects in the Database, prior to applying a patch.

    • Verify the Shared_Pool_size and Java_Pool_Size are set to a minimum of 150MB each.

  • Don’t set ORACLE_HOME in environment – Oracle gets its environment via the Registry. Oracle.key file in OH\bin points to correct registry key.


Patching best practices l.jpg

Patching Best Practices

  • For existing installs, make plans to test and apply future patchsets

    • Don’t wait until you are forced to apply patch on a production system without sufficient testing

    • Apply patches within 6 months of release

  • At minimum, CPU (Critical Patch Update) patches are released quarterly

  • Fifth-digit patches provided on Windows platforms which bundle one-off patches

  • For fixing new issues, applying latest patchset and fifth-digit patches available will help in eliminating known bugs


Slide49 l.jpg

<Insert Picture Here>

High Availability Solutions on Windows


High availability solutions l.jpg

High Availability Solutions

  • HA becomes essential as databases are critical component of business

  • HA Goals: Minimize downtime to your company and your customers

  • Solutions for Windows Environments

    • Real Application Clusters (RAC)

    • Oracle Fail Safe

    • Data Guard (DG)

    • Maximum Availability Architecture (MAA)

    • Oracle Clusterware for Single Instance

      • Provides MSCS – without MSCS

    • See http://www.oracleracsig.org this Thursday 16th


More information l.jpg

More Information

  • Windows Server Technology Center

    • http://otn.oracle.com/windows

  • Oracle RAC

    • http://otn.oracle.com/rac

    • http://otn.oracle.com/asm

  • Microsoft – Oracle

    • http://ww.microsoft-oracle.com

  • Oracle RAC SIG

    • http://www.oracleracsig.org

  • For more questions

    [email protected]

    [email protected]


Slide52 l.jpg

The preceding is intended to outline our general product direction. It is intended for information purposes only, and may not be incorporated into any contract. It is not a commitment to deliver any material, code, or functionality, and should not be relied upon in making purchasing decisions.The development, release, and timing of any features or functionality described for Oracle’s products remain at the sole discretion of Oracle.


  • Login
