  1. D’ Waiters 105060807111083 SUKMA NUR FAIZ AFFANDI 105060800111075 NURUL FITRIA K 105060801111068 ARINTA ASESANTI

  2. Gambaran Umum (What) • D’ waiters ini adalah sistem informasi yang berguna untuk mempermudah pelayan dalam suatu restoran dengan menggunakan sistem komputerisasi berbasis grafis.

  3. Gambaran Umum (Why) • Sistem dibuat dengan tujuanpenyesuaian dengankebutuhansetiaprestoran, untukmenyediakanlayanan yang lebihbaikkepadaparapelanggandankendali yang lebihhandalkepadaparapengelolarestoran. • Mempermudah PelayananRestoran • MencegahKebocoranKeuangan • Ketepatan total pembelian • MenghitungHargaPokokPenjualanMakanan • Laporan

  4. Analisa Kebutuhan • AntarMukaPerangkatkeras • CPU : Core • RAM : 3GB • Grafik : 3D Accelerated Card with TnL 32 Mb (GeForce 3Ti / Radeon 9 series) • Suara : Windows 7 compatible sound card • Hard Drive : 500 GB free disk space • AntarMukaPerangkatLunak • Server = DBMS • user = Java

  5. Data Flow Diagram (level 0)

  6. Data Flow Diagram (level 1)

  7. Data Flow Diagram (level 2)

  8. Entity Relation Diagram

  9. Entity Relation Diagram
