Swing

swing 基础二


Swing

本节目标

  • Look And Feel

  • 了解MVC体系结构

  • 常用组件

    • JComboBox

    • JTextPane

    • JTabel

    • JTree


Swing

可插入的外观和感觉

  • UIManager管理外观

  • setLookAndFeel(String className)

  • SwingUtilities.updateComponentTreeUI(frame);

  • 常用外观:

    • Metal:javax.swing.plaf.metal.MetalLookAndFeel

    • Motif :com.sun.java.swing.plaf.motif.MotifLookAndFeel

    • GTK+:com.sun.java.swing.plaf.gtk.GTKLookAndFeel

    • Windows:com.sun.java.swing.plaf.windows.WindowsLookAndFeel


Mvc model view control

MVC(Model-View-Control)体系结构

Swing胜过AWT的主要优势在于MVC体系结构的普遍使用。在一个MVC用户界面中,存三个通讯对象:模型、视图和控制。模型是指定的逻辑表示法,视图是模型的可视化表示法,而控制则指定了如何处理用户输入。当模型发生改变时,它会通知所有依赖它的视图,视图使用控件指定其相应机制。

  为了简化组件的设计工作,在Swing组件中视图和控制两部分合为一体。每个组件有一个相关的分离模型和它使用的界面(包括视图和控件)。比如,按钮JButton有一个存储其状态的分离模型ButtonModel对象。组件的模型是自动设置的,例如一般都使用JButton 而不是使用ButtonModel 对象。另外,通过Model类的子类或通过实现适当的接口,可以为组件建立自己的模型。把数据模型与组件联系起来用setModel( )方法。


Swing

几个基于MVC实现的组件

  • JComboBox

  • JTextPane

  • JTable

  • JTree


Jcombobox

JCombobox

ComboBoxModel

定制ListCellRenderer绘制单元格

setRenderer(ListCellRenderer cellRenderer)


Jcombobox 1

JComboBox示例_1

import java.awt.*;import java.awt.event.*;import javax.swing.*;public class JComboBox4{  String[] s={"西瓜","苹果","草莓","香蕉","葡萄"};   public JComboBox4(){  JFrame f=new JFrame("JComboBox");  Container contentPane=f.getContentPane(); JComboBox combo=new JComboBox(s);  combo.setBorder(BorderFactory.createTitledBorder("你最喜欢吃哪些水果?"));  combo.setRenderer(new ACellRenderer());  combo.setMaximumRowCount(3);  contentPane.add(combo);f.pack();      f.show();      f.addWindowListener(new WindowAdapter(){


Jcombobox 2

JComboBox示例_2

public void windowClosing(WindowEvent e){      System.exit(0);     }      });       }  public static void main(String[] args){    new JComboBox4();  }} class ACellRenderer extends JLabel implements ListCellRenderer{ ACellRenderer(){ setOpaque(true);   }  public Component getListCellRendererComponent(JList  list,                                                Object value,                                                int index,                                                boolean isSelected,                                                boolean cellHasFocus){


Jcombobox 3

JComboBox示例_3

if (value!=null){        setText(value.toString());        setIcon(new ImageIcon(".\\icons\\fruit"+(index+1)+".jpg"));      }        if (isSelected){         setBackground(list.getSelectionBackground());         setForeground(list.getSelectionForeground());       }else{         setBackground(list.getBackground());          setForeground(list.getForeground());      }                                          return this;           }                                                 }


Jtextpane 1

JTextPane示例_1

import java.awt.Color;

import javax.swing.ImageIcon;

import javax.swing.JFrame;

import javax.swing.JTextPane;

import javax.swing.text.MutableAttributeSet;

import javax.swing.text.SimpleAttributeSet;

import javax.swing.text.StyleConstants;

import javax.swing.text.StyledDocument;

import javax.swing.JScrollPane;

public class DemoJTextPane2 extends JFrame {

JTextPane jtextPane;

MutableAttributeSet center_align, char_style_1, char_style_2;

public DemoJTextPane2() {

jtextPane = new JTextPane();

JScrollPane scroll = new JScrollPane(jtextPane,

JScrollPane.VERTICAL_SCROLLBAR_ALWAYS,

JScrollPane.HORIZONTAL_SCROLLBAR_ALWAYS);

StyledDocument mydocument=jtextPane.getStyledDocument();

center_align=new SimpleAttributeSet();


Jtextpane 2

JTextPane示例_2

char_style_1=new SimpleAttributeSet();

char_style_2=new SimpleAttributeSet();

StyleConstants.setAlignment(center_align,

StyleConstants.ALIGN_CENTER);

StyleConstants.setFontFamily(char_style_1,"Timer");

StyleConstants.setFontSize(char_style_1,20);

StyleConstants.setForeground(char_style_1,Color.red);

StyleConstants.setFontFamily(char_style_2,"Serif");

StyleConstants.setFontSize(char_style_2,14);

StyleConstants.setForeground(char_style_2,Color.BLUE);

try{

jtextPane.setCaretPosition(mydocument.getLength()); // 设置插入位置

jtextPane.insertIcon(new ImageIcon(this.getClass().getResource("images/qqicon.gif")));

mydocument.insertString(mydocument.getLength(),

"\n\nfirst\n\n",char_style_1);

}

catch(Exception e){}


Jtextpane 3

JTextPane示例_3

try{

mydocument.insertString(mydocument.getLength(),

"second\n\n",char_style_2);

jtextPane.setCaretPosition(mydocument.getLength()); // 设置插入位置

jtextPane.insertIcon(new ImageIcon(this.getClass().getResource("images/qqicon.gif")));

}

catch(Exception e){}

getContentPane().add(scroll);

setSize(400,300);

setVisible(true);

setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);

}

public static void main(String args[]){

new DemoJTextPane2();

}

}


Jtable

表格(JTable)

  • JTable构造方法:

    • JTable(TableModel dm)

    • JTable(object[][]rowData,object[]columnNames)

    • JTable(Vector rowData,Vector columnNames)

  • JTable类常用的方法有:getModel() //获得表格的数据来源对象getSelectedRow() //获得选中的行数


Jtable1

表格(JTable)

表格是Swing新增加的组件,主要功能是把数据以二维表格的形式显示出来。使用表格,依据M-V-C的思想,最好先生成一个MyTableModel类型的对象来表示数据,这个类是从AbstractTableModel类中继承来的,其中有几个方法是一定要重写,例如getColumnCount,getRowCount,getColumnName,getValueAt。因为JTable会从这个对象中自动获取表格显示所必需的数据,AbstractTableModel类的对象负责表格大小的确定(行、列)、内容的填写、赋值、表格单元更新的检测等等一切跟表格内容有关的属性及其操作。JTable类生成的对象以该TableModel为参数,并负责将TableModel对象中的数据以表格的形式显示出来。


Jtable 1

JTable示例_1

import javax.swing.table.AbstractTableModel;

import javax.swing.*;

import java.awt.*;

import java.awt.event.*;

public class DemoJTableModel2 implements ActionListener {

JTable t = null;

public DemoJTableModel2() {

JFrame f = new JFrame("DataModel");

JButton b1 = new JButton("数学老师");

b1.addActionListener(this);

JButton b2 = new JButton("学生阿呆");

b2.addActionListener(this);

JPanel panel = new JPanel();

panel.add(b1);

panel.add(b2);

t = new JTable(new MyTableModel2_1(1));

t.setPreferredScrollableViewportSize(new Dimension(550, 30));

JScrollPane s = new JScrollPane(t);

f.getContentPane().add(panel, BorderLayout.NORTH);


Jtable 2

JTable示例_2

f.getContentPane().add(s, BorderLayout.CENTER);

f.pack();

f.setVisible(true);

f.addWindowListener(new WindowAdapter() {

public void windowClosing(WindowEvent e) {

System.exit(0);

}

});

}

public void actionPerformed(ActionEvent e) {

if (e.getActionCommand().equals("学生阿呆"))

t.setModel(new MyTableModel2_1(1));

if (e.getActionCommand().equals("数学老师"))

t.setModel(new MyTableModel2_1(2));

t.revalidate();

}

public static void main(String args[]) {

new DemoJTableModel2();

}

}


Jtable 3

JTable示例_3

class MyTableModel2_1 extends AbstractTableModel {

Object[][] p1 = {

{ "阿呆", "1234", new Integer(66), new Integer(50),new Integer(116), new Boolean(false), new Boolean(false) }

};

String[] n1 = { "姓名", "学号", "语文", "数学", "总分", "及格", "作弊" };

Object[][] p2 = {

{ "阿呆", "1234", new Integer(50), new Boolean(false),new Boolean(false), "01234" },

{ "阿瓜", "1235", new Integer(75), new Boolean(true),new Boolean(false), "05678" }

};

String[] n2 = { "姓名", "学号", "数学", "及格", "作弊", "电话" };

int model = 1;

public MyTableModel2_1(int i) {

model = i;

}

public int getColumnCount() {

if (model == 1)

return n1.length;

else


Jtable 4

JTable示例_4

return n2.length;

}

public int getRowCount() {

if (model == 1)return p1.length;

elsereturn p2.length;

}

public String getColumnName(int col) {

if (model == 1)return n1[col];

elsereturn n2[col];

}

public Object getValueAt(int row, int col) {

if (model == 1)return p1[row][col];

elsereturn p2[row][col];

}

public Class getColumnClass(int c) {

return getValueAt(0, c).getClass();

}

}


Jtree 1

JTree示例_1

import java.awt.*;

import java.awt.event.*;

import javax.swing.*;

import javax.swing.tree.*;

public class DemoJTree1 extends JPanel {

String[][] data = { { "Colors", "Red", "Blue", "Green" },

{ "Flavors", "Tart", "Sweet", "Bland" },

{ "Length", "Short", "Medium", "Long" },

{ "Volume", "High", "Medium", "Low" },

{ "Temperature", "High", "Medium", "Low" },

{ "Intensity", "High", "Medium", "Low" } };

static int i = 0; // I用于统计按钮点击的次数

DefaultMutableTreeNode root, child, targetNode;

JTree tree;

DefaultTreeModel model;

public DemoJTree1() {

setLayout(new BorderLayout());

// 根节点进行初始化

root = new DefaultMutableTreeNode("root");


Jtree 2

JTree示例_2

// 树进行初始化,其数据来源是root对象

tree = new JTree(root);

DefaultTreeCellRenderer dtcr=new DefaultTreeCellRenderer();

dtcr.setBackgroundSelectionColor(Color.ORANGE);

tree.setCellRenderer(dtcr);

// 把滚动面板添加到Trees中

add(new JScrollPane(tree));

// 获得数据对象DefaultTreeModel

model = (DefaultTreeModel) tree.getModel();

// 按钮test进行初始化

JButton test = new JButton("Press me");

// 按钮test注册监听器

test.addActionListener(new ActionListener() {

public void actionPerformed(ActionEvent e) {

if (i < data.length) {

// 按钮test点击的次数小于data的长度

child = new Branch(data[i++]).node();

// 生成子节点

targetNode = (DefaultMutableTreeNode)


Jtree 3

JTree示例_3

tree.getLastSelectedPathComponent();

if (targetNode == null)

targetNode = root;

model.insertNodeInto(child, targetNode, 0);

// 把child添加到chosen

}

}

});

test.setBackground(Color.blue);

// 按钮test设置背景色为蓝色

test.setForeground(Color.white);

// 按钮test设置前景色为白色

JPanel p = new JPanel();

// 面板p初始化

p.add(test);

// 把按钮添加到面板p中

add(p, BorderLayout.SOUTH);

// 把面板p添加到Trees中

}

public static void main(String args[]) {


Jtree 4

JTree示例_4

JFrame jf = new JFrame("JTree demo");

jf.getContentPane().add(new DemoJTree1(), BorderLayout.CENTER);

// 把Trees对象添加到JFrame对象的中央

jf.setSize(200, 500);

jf.setVisible(true);

}}

class Branch {

DefaultMutableTreeNode r;

public Branch(String[] data) {

r = new DefaultMutableTreeNode(data[0]);

// 给节点r添加多个子节点

for (int i = 1; i < data.length; i++) {

r.add(new DefaultMutableTreeNode(data[i]));

}}

public DefaultMutableTreeNode node() {// 返回节点

return r;

}}


Swing1

Swing的程序设计

Swing的程序设计一般可按照下列流程进行: 1. 引入Swing包 2. 选择"外观和感觉" 3. 设置顶层容器 4. 设置按钮和标签 5. 向容器中添加组件 6. 在组件周围添加边界 7. 进行事件处理
