8 6

思科腾讯通 8.6

李吉

技术市场工程师

思科统一通信事业部


8 6

回首过去


8 6

思科腾讯通 8.5

  • 优点

    • 在中国制造:思科完全中国本地化开发的统一通信客户端解决方案

    • 为中国制造(与腾讯合作):与中国本土厂商合作,打造定制的一款符合中国用户使用习惯的产品

    • 丰富的沟通功能与一体化的用户体验:为企业用户带来即时消息,语音/视频以及会议的高品质一体化感受

    • 可靠的产品质量,专业级服务和SLA:思科集网络专家,安全专家与通信专家的优势为企业提供源自思科硬件保障体系的服务

  • 不足

    • 安装和部署繁琐:不能支持Windows XP SP2,要求.NET 4.0,安装包太大,对机器硬件要求高,安装时间较长

    • 软件启动较慢:登入RTX后思科腾讯通插件启动较慢

    • 软件窗口反应较慢:接收和拨打电话时窗口界面反应较慢

    • 内存占用较大:全部软件加载后占用内存近200M

    • RTX界面老气:相对于其它即时聊天软件RTX界面显得有点过时


8 6

BAT文件

软硬电话切换

正在加载

帐号和密码

界面太土了

我的电脑可以装么

视频会议

什么是CSF

Tadnberg视频互通

思科网真视频互通

Polycom视频互通

思科腾讯通 8.5 关键字


8 6

从现在开始


8 6

哪儿都可以装

  • XP SP2也能装

  • 没有.NET 4.0也能装

  • 512M内存的机器也能装

  • 安装包不到30M

    装起来还特容易

  • 安装时间不到30秒

  • 新旧RTX版共存方便部分升级

  • RPI包推送思科腾讯通插件

  • LDAP同步,认证和角色管理

部署


8 6

  • 部署案例分析

  • 思科腾讯通8.5用户

  • 腾讯通老用户

  • UC老用户


8 6

软件性能


8 6

新功能


Agenda

Agenda

  • 产品功能概述

  • 产品架构和解决方案

  • 产品需求

  • 配置和部署


8 6

产品概述


8 6

Cisco ClientExperiences

Integrators & DeveloperCommunity

3rd Party DesktopExperiences

思科腾讯通客户端协作架构

History

Cisco Unified Client Services Client Service Framework

Vmail

IM

Audio

Call Ctl

Future

Conf

Presence

Directory

Video

Cisco Unified InfrastructureServices

CallControl

DataStore

PresenceServices

CallingHistory

ConferencingServices

Messaging

  • All Cisco UC desktop Clients built off a common client middleware platform

  • Cisco UC Enable leading 3rd party IM Clients

  • Provide access to same desktop UC features to development community


8 6

思科腾讯通产品概述

  • 思科腾讯通是将思科统一通信服务与腾讯通做集成后的产物,它提供了一个易管理的企业通信和协作平台

  • 腾讯通是由腾讯公司提供的企业级即时通信解决方案,它不仅提供了基本的即时通信功能,而且为在企业内部环境中使用量身订制了很多有用的功能

  • 它提供了丰富的商业通信模式,包括高清视频通话,高质量语音通话,语音视频会议和多媒体会议


8 6

思科统一通信与腾讯通带来无缝协作体验

  • 公司组织架构

  • 在线状态

  • 即时聊天与文件传输

  • 集成短信功能 *

  • 集成软电话

  • 硬电话控制

  • 高清视频通话

  • 思科网真、腾博视频终端互通

  • 可视化语音信箱

  • 在线协作,网络会议

  • 企业OA,ERP,CRM系统整合


8 6

思科腾讯通思科UC相关的按钮和菜单(1)

2

1

3

4

5

6

通话历史纪录 & 可视化语音信箱:点击来查看呼叫事件和语音留言。按钮旁边的数字标示了未接来电和新的语音留言的数量。如果你有新的语音留言,该按键会变成红色。

电话模式:点击该按键来进行在软电话和硬电话之间切换。

拨号盘:点击来打开拨号盘,用户可以在拨号盘中输入电话号码或是联系人的姓名来拨打电话。

电话图标:双击来呼叫该联系人。

思科腾讯通设置:点击来修改思科腾讯通的用户选项,例如视频设置。

呼叫前转设置快捷键:绿色图标指示当前电话的呼叫前转已启用。灰色图标表示没有启用。点击可以进行呼叫前转的设置。


8 6

思科腾讯通思科UC相关的按钮和菜单(2)

  • RTX菜单扩展,加入了思科腾讯通相关的设置菜单

    思科腾讯通设置

    注销思科腾讯通

    帮助

    服务器状态和错误提示

    创建问题报告

    关于思科腾讯通

    思科腾讯通帮助


8 6

思科腾讯通打电话(1)

  • 丰富的拨打电话方式:

  • 双击“电话图标”

  • 上下文菜单选择

  • 即时聊天窗口点击

  • 拨号器

  • 快速搜索栏


8 6

思科腾讯通打电话(2)

  • 号码选择策略:

  • RTX个人资料中可以设置两个号码:办公和移动电话号码

  • 联系人右边的下拉箭头进行号码选择

  • 默认拨打办公号码


8 6

思科腾讯通打电话(3)

  • 用户可以点击拨打电话给外部联系人,例如打电话给客户,家人和朋友,即使他们都不在公司组织架构中

  • 该功能使用户在使用统一通信功能时更加灵活


8 6

思科腾讯通通话中功能

  • 电话会议 / 合并电话成会议

  • 呼叫转接

  • 保留 / 恢复呼叫

  • 暂留 / 取回呼叫

  • 为呼叫加入视频

  • 发起网络会议


8 6

思科腾讯通电话会议

  • 选择多个联系人发起ad-hoc方式的电话会议


8 6

思科腾讯通合并电话

  • 会话窗口中有两个通话

  • 合并两个通话为一个电话会议并显示所有参会者


8 6

思科腾讯通高清视频通话

  • 思科腾讯通为用户提供了基于标准H.264协议的视频交互功能,支持720p高清视频通话

  • CUCM的电话准入控制可以管理在区域网和广域网上的视频流量


8 6

思科腾讯通网络共享(1)

主持人从联系人列表中发起一个网络会议

每个参会者都会收到一个邀请

点击加入会议会自动进入到网络会议


8 6

思科腾讯通网络共享(2)

  • 聊天或者通话中一键发起WebEx会议

  • 思科WebEx会议提供桌面共享,白板,高质量视频等在线会议功能


8 6

思科腾讯通视频互通(1)

RTX Server

Cisco Unified CommunicationsManager

CodianMCU

VCS

CUC-RTX

150MXP

Polycom

E20

C20/40/60/90

9951

Ex 90


8 6

思科腾讯通视频互通(2)

  • 思科腾讯通与思科腾博参与的视频会议

  • 思科腾讯通与Polycom参与的视频会议


8 6

思科腾讯通通话中状态

桌面电话状态同步显示

  • 当使用思科腾讯通拨打和接听电话时,您的状态会更新显示为通话中

  • 当多个设备共享一个号码时,状态信息显示为该号码的状态


8 6

思科腾讯通通话历史纪录

通话历史记录可以通过思科腾讯通直接打开,并附带了若干过滤规则来帮助用户寻找到特定的纪录

  • 在软电话模式下,当用户有新的留言,这个按钮会变成红色来形象地提示用户

有新的留言


8 6

思科腾讯通编辑号码 – 通话历史纪录

  • 右键点击通话纪录中的联系人

  • 选择编辑号码进行拨号

  • 弹出号码编辑和回拨窗口


8 6

思科腾讯通可视化语音留言

  • 留言直接在窗口中播放– 回放可以通过鼠标拖拽来控制

  • 留言回放音量控制功能

  • 留言过滤规则选择


Outlook 2007

思科腾讯通Outlook 2007 集成

点击联系人前面的球,在弹出窗口中可以发起即时消息和音频通话

From the menu, Home -> IM or Home -> Call


Outlook 2010

思科腾讯通Outlook 2010 集成

将鼠标移到联系人帐号上或者点击联系人帐号前面的球,在弹出的浮动窗口中发起即时消息和音频通话

From the menu, Home -> IM or Home -> More -> Call


8 6

思科腾讯通思科腾讯通设置

在呼叫选项卡里,用户可以设置呼叫转接并可以选择不同的桌面电话与思科腾讯通绑定

用户可以在常规选项卡里面设置常规选项和启动Outlook集成功能

用户可以在账户选项卡中填入网络会议账号和可视化语音信箱账号

在视频选项卡上可以设置与视频相关的选项,比如调整视频可用带宽


8 6

产品架构


Solution topology

思科腾讯通Solution Topology

Cisco Unified Communications Manager

Cisco Unified MeetingPlace

Cisco Unity Connection

RTX 服务器

AD

DNS

Switch

Voice Gateway

CUC-RTX

CUC-RTX

Cisco IP Phone

PSTN

  • 服务器端只有RTX服务器和CUCM是必须的,其余的服务器根据客户功能需要进行配置

  • 客户端只有PC是必须的,如果用户预算足够可以配适当的思科IP电话


Cisco collaboration topology

思科腾讯通Cisco Collaboration Topology

Backend Server

soft MCU

Unit Connection

HardMCU

RTX Server

SIP

CUCM

SIP

SIP

SIP

SIP

EX 90

E 20

C60

Cisco Mobile

9951 IP phone

CUC-RTX

WebEx


8 6

思科腾讯通部署示例

总部

RTX 文件服务器

分部

RTXServer

OCS Server

CUCM集群B

CUC-RTX(softphone mode)

CUC-RTX(IP Phone Control Mode)

CUC-RTX(softphone mode)

CUC-RTX(IP Phone Control Mode)

CUC-RTX(softphone mode)

CUC-RTX(softphone mode)

Router

CUCM集群A

CiscoASA

Router

Router

CUC-RTX(IP Phone Control Mode)

英特网或家庭办公员工

支部

CUC-RTX(softphone mode, VPN to enterprise network)

CUC-RTX(softphone mode)


8 6

思科腾讯通架构 FAQ

  • RTX 服务器只提供即时消息和状态相关功能

  • RTX服务器不负责任何的语音/视频等多媒体信令

  • RTX服务器和CUCM之前没有SIP Trunk

  • RTX客户端不负责媒体流,而是思科腾讯通底层的CSF架构负责通话和话机管理


Mobile features of cisco unified

Mobile Features of Cisco Unified 产品要求


8 6

思科腾讯通硬件要求

  • 客户端电脑要求

  • RTX 服务器要求(腾讯推荐)


8 6

思科腾讯通软件要求(1)

  • 客户端要求

* Desk phone video is not supportedon 64-bit editions of Windows (soft phone video only)


8 6

思科腾讯通软件要求(2)

  • 服务器端要求


8 6

思科腾讯通网络要求

  • Ports Used for Inbound Traffic

  • Ports Used for Outbound Traffic


8 6

思科腾讯通话机支持

注意:视频电话(7985,8945,8941和99xx)和使用SIP协议的话机不支持Deskphone video


Mobile features of cisco unified1

Mobile Features of Cisco Unified 部署 & 配置


8 6

思科腾讯通RPI安装(1)

  • RPI是RTX插件的标准封装格式

  • CUC-RTX PRI包安装时会做如下的事情:

    • 在RTXC/Plugins文件夹下创建一个与该PRI包同名的文件夹

    • PRI包解压后将所包含的文件全部复制到该文件夹

    • 插件信息被写入进RTXPlugins.xml

    • 安装vcredist_x86.exe

    • 安装CiscoUnifiedCommunicationsforRTX.msi

      • 卸载老的CUC-RTX 版本(如果存在的话,例如CUC-RTX 8.5)

      • 安装新版本CUC-RTX


8 6

思科腾讯通RPI安装(2)

  • 直接安装

  • 推送安装


8 6

思科腾讯通配置步骤

  • RTX 服务器

    从AD导入用户或者手动创建用户

    为指定用户添加UC角色

  • 思科腾讯通管理器

    为相应的UC角色添加UC配置信息

  • Cisco Unified Communications Manager

    Enable LDAPIntegration (If LDAP is configured to sync the user accounts)

    Create devices for users

    Assign devices to users


8 6

思科腾讯通AD用户导入(1)

  • 1. Select “User import and Authentication” and click “Add”

2 . LDAP server basic info.


8 6

思科腾讯通 AD用户导入(2)

  • 3. Select folder and users

4. User attributes mapping


8 6

思科腾讯通 AD用户导入(3)

  • 5. Import settings and authentication mode


8 6

思科腾讯通RTX用户配置UC角色

  • 在 RTX 服务器上,

    • 管理员创建UC角色

    • 管理员为该UC角色关联用户


8 6

思科腾讯通思科腾讯通管理器 – 部署UC

  • 思科腾讯通管理器,管理员为UC角色配置UC信息


8 6

思科腾讯通CUCM Dial Rules Configuration

  • Application Dial Rules and Directory Lookup Rules are both required

  • Application Dial Rules modify the dial string on outbound calls to conform to the route plan in place on CUCM

    Any number dialled by a user (not routable as-is) must have an ADR to resolve the number to the route plan

    E.g. If it is required that users be allowed to dial 4-digit extension numbers and CUCM is not configured for 4-digit dialling, then an ADR must be defined to resolve that 4-digit number to a number recognizable by the CUCM route plan

  • Directory Lookup Rules are used to translate numbers received in CUCM signalling for inbound calls to a number that can be resolved in contact store

    For example, if CUCM reports a call from 89023044, then that number needs to be transformed into +14089023044 as stored in RTX Server per the E.164 requirement noted earlier


8 6

思科腾讯通CUCM Dial Rules

  • Basic Client troubleshooting for Dial Rules:

    The CSF Core log will contain information on the translated numbers via the Dial Rules applied (if any). This is the first place to look when investigating potential dialing number related issues.

    Ensure files were downloaded via TFTP to the client

    Verify the numbers were translated to CUCM routable numbers

    For further log troubleshooting information refer to the “Troubleshooting” section of the TOI.


8 6

思科腾讯通CUCM CSF Device Configuration

  • Device Naming Convention

    Free form, no correlation to username required

    Any character [a-z,A-Z,0-9] up to 15 characters

  • Required Device Parameters

    Parameters without default values (must be explicitly set)

    Device Name (as described above), Device Pool, Phone Buttons Template, Device Security Profile, SIP Profile

    Parameters with default values

    Location, Device Mobility Mode, Use Trusted Relay Point, Packet Capture Mode, Presence Group, MTP Preferred Originating Code, Certificate Operation, AuthenticationMode, Key Size, DND Option


8 6

思科腾讯通LDAP sync

  • Strong recommendation – synchronize User Id’s between AD and CUCM

    Alternative – manual synchronization of User Id’s

    Requires the CUCM administrator create a CUCM User with the same User Id as the AD User Id

    CUCM Users should be assigned identical passwords as the corresponding AD user

  • User Id’s for CUCM and AD must be in the same CASE.


8 6

思科腾讯通CUCM LDAP Configuration

  • To enable Id Sync CUCM should be enabled to use

    LDAP Synchronization

    This allows CUCM to integrate with AD and build its user database from the same data source in which Windows users are defined.

    This allows CUCM to proxy any authentication request to the AD source for authentication and means that Windows and CUCM users are all authenticated by the same source

    For more information see:

    CUCM 7.x http://www.cisco.com/en/US/docs/voice_ip_comm/cucm/srnd/7x/directry.html

    CUCM 8.x http://www.cisco.com/en/US/docs/voice_ip_comm/cucm/srnd/8x/directry.html


8 6

思科腾讯通CUCMConfiguration for Video

  • CUCM Configuration

    Device config

    The Services Client Framework device type is always video-enabled.

    IP Phones need to be explicitly video enabled.

    Only SCCP (Skinny) IP phones support video with CSF.

    ‘PC port’ and ‘video capabilities’ must be enabled for IP phones.

    IP phone must be ‘tethered’ to the controlling PC via Ethernet cable in order for video to function (just like with CUVA/VT Advantage client)

    User Config

    Users must be a member of ‘Standard CTI Enabled’ group to control desk phones.

    CSF device and controlled IP phones must be configured as ‘Controlled Devices’ under ‘Device Association’


8 6

思科腾讯通Video Conference Configuration

  • CUCM Configuration for Ad-hoc video conferencing

    Configuration for CSF is no different from any other phone device.

    You must have a Conference bridge configured.

    You must have a Media Resource Group and Media Resource Group List configured.

    Optionally, for ad-hoc conferencing, you can change the ‘Minimum Video Capable Participants To Allocate Video Conference’ in System->Service Parameters->Call Manager. Note that when an ad-hoc conference is initiated, it will either use an audio bridge or a video bridge based on this setting. Once the conference has been started, it will continue to use the same bridge. So if it starts as audio it will always be audio-only.

    You must configure devices to use the appropriate Media Resource Group List.


8 6

思科腾讯通Unity Connection Configuration

  • Documentation guides:

    • Unity Connection 8.x: http://www.cisco.com/en/US/docs/voice_ip_comm/connection/8x/roadmap/8xcucdg.html

  • Unity Connection:

    • Integrate with the same directory source as the peer CUCM system whenever you can. Otherwise keep in mind:

      • Keeping the subscriber userId consistent across Directory and domains solves a lot of contact matching limitations.

      • Consider importing users/subscribers from the telephony integration (CUCM) as much as you can for the same reasons.


8 6

Documentation:

http://www.cisco.com/en/US/docs/voice_ip_comm/cusrst/admin/sipsrst/configuration/guide/spsrst41.html

Configure SRST IP address and port in UCM Admin web page under System->SRST

No CSF specific configuration

Same configuration on the SRST as for a TNP phone

SIP Registrar should be enabled

Voice Register Pools must be configured (Please refer to the admin guide above)

思科腾讯通SRST configuration


8 6

思科腾讯通CSF Security (1)

  • CUCM secure mode

    • Certificate Trust Lists are used to verify the CUCM servers that a client connects to.

    • The CTL file contains certificates for all of the Cisco backend servers for which CSF may need to communicate securely

    • CSF will not allow the creation of secure connections to any server not explicitly listed in the Trust list.

    • Note that the CTL file needs to be manually deleted when moving clients from one environment to another

    • If CSF is not running in secure mode, you can move from one environment to another by simply changing your registry settings and restarting CSF.

  • The CTL file is at

    • XP: C:\Documents and Settings\<username>\Application Data\Cisco\Unified Communications\Cucrtx\Security\sec\CTLFile.tlv

    • Vista/Win7: C:\Users\<username>\AppData\Roaming\Cisco\Unified Communications\Cucrtx\Security\sec\CTLFile.tlv


8 6

思科腾讯通CSF Security (2)

  • Certificate Verification

    • Once the CTL file has been downloaded, CSF will communicate with the Cisco Authority Proxy Function (CAPF) to generate an X.509-formatted Locally Significant Certificate (LSC) using a shared secret.

      • This “authorization string” will have been given to the user by some secure, out-of-band process which is not handled by CSF.

        • Example of out-of-band process would be delivering the string via email.

    • Once this LSC has been generated locally, it will be used to establish TLS connections with Cisco backend servers when secure connections are required.

  • Encryption

    • Signaling and media may be encrypted once trust is established

      • TLS connections for SIP signaling

      • SRTP for media packets.

    • Note: This is controlled by SIP security profile on the CUCM.


Mobile features of cisco unified2

Mobile Features of Cisco Unified 附录


8 6

思科腾讯通CUC-RTX Component Overview


8 6

思科腾讯通Solution Architecture

TencentProrietary Protocol

RTX

RTP/SRTP

思科腾讯通

RTX server

SIP

TFTP

CTI-QBE

Client Services Framework 2G

Media

Conf

V-Mail

History

Call Ctrl

Meeting

HTTPS

RTP/SRTP(Soft phone Calls to other clients)

TCP

IMAP/SecureIMAP

RTP/SRTP

TFTP

HTTP

CTI-QBE

Webex Cloud

MediaResource

CCMCIP Server

SIP

Unity ConnectionMessaging

Call

Control

CTI

Manager

TFTPServer


Message flow for cuc rtx manger

思科腾讯通Message Flow for CUC-RTX Manger

  • Note: if “UseLocalSetting” is defined in users’ registry table “HKCU\\Software\\Cisco Systems, Inc.\\Unified Communications\\cucrtx”, CUCRTX will not request UC settings from Server.


  • Login
