乔福机械工业股份有限公司. 公司簡報. Sales Director : Paul Tsai Date : Mar. 15, 2005. 喬福機械 品質政策. ABSOLUTE QUALITY ( 追求品質 ) SERVICE FIRST ( 服務至上 ) CUSTOMER SATSFACTION ( 永續經營 ) ** The number one exporter of CNC Machining centers from Taiwan in 1998. (1998 年台湾加工中心出口第一名 ) **.

Download Presentation

公司簡報

An Image/Link below is provided (as is) to download presentation

Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.


- - - - - - - - - - - - - - - - - - - - - - - - - - E N D - - - - - - - - - - - - - - - - - - - - - - - - - -

Presentation Transcript


5791041

乔福机械工业股份有限公司

公司簡報

Sales Director : Paul Tsai

Date : Mar. 15, 2005.


5791041

喬福機械 品質政策

  • ABSOLUTE QUALITY( 追求品質 )

  • SERVICE FIRST ( 服務至上 )

  • CUSTOMER SATSFACTION(永續經營)

  • ** The number one exporter of

  • CNC Machining centers from

  • Taiwan in 1998. (1998年台湾加工中心出口第一名)**


5791041

ISO 9001 : 2000


5791041

动柱式龙门加工中心

SDMC-5000/6000

SDMC-8000

SDMC-28000-2H

SDMC-11000-2H


5791041

定柱式龙门加工中心

DMC-3000/4000

DMC-4000x2500

五轴

五面


5791041

定柱式龙门3-5轴加工中心

  • 機器型號 :S & P系列

  • S系列(門寬1830mm)

    - DMC-2100S, 2600S, 3100S (BT-40)

    - DMC-2100SH, 2600SH,3100SH(BT-50)

  • 三軸行程:

    --- X:2100/2600/3100 mm

    Y:1778 mm

    Z:800 mm

  • P系列(門寬2400mm)

    -DMC-3100P, 4100P, 5100P (BT-40)

    -DMC-3100PH,4100PH,5100PH(BT-50)

  • 三軸行程:

    --- X:3100/4100/5100 mm

    Y:2300 mm

    Z:800 mm

  • 主軸轉速:

    --- 8000 ~ 20000 rpm BT-40,BBT-40, HSK-A63

    --- 6000 ~ 10000 rpm BT-50,BBT-50, HSK-A100


5791041

结构特性介绍(1)

兩柱間距- 1800/2400/2800/3800 mm

  • Wide machining area

  • provides a wide range

  • of operation.

  • (更大加工範圍及特殊規

  • 格訂制)


5791041

结构特性介绍

  • x軸滾珠絲槓螺帽旋轉驅動

  • X軸絲槓經預拉伸固

    定,由伺服馬達驅動

    螺帽旋轉進行移動

  • 優點:無絲槓旋轉時

    之偏擺誤差,響應速

    度快,高加速,慣性小


5791041

结构特性介绍(2-1)

  • 滾珠絲槓傳動特點:螺帽旋轉式


5791041

结构特性介绍(3)

  • 液壓配重: 單油缸平衡設計

  • This function can

    provides high stability

    and smooth operation.


5791041

结构特性介绍(4)

  • Multiple Configurations to match any need


Dmc series of end user

DMC-Series of end user

CYTEC G30 - 5-Axis Head (HSK-A100 , 10,000 RPM)

用户:天津大学


Dmc series of end user1

DMC-Series of end user

Model: DMC-2600SH + CYTEC G30 - 5-Axis Head ( HSK-A100 , 10,000 RPM )

S/No. VGB-3024 Shipment day : Oct. 30, 2003.

(实际加工情形)


Dmc series of end user2

DMC-Series of end user

CYTEC G30 - 5-Axis Head ( HSK-A100 , 10,000 RPM )

用户在台湾实际验收情形


Dmc series of end user3

DMC-Series of end user

Model: DMC-2600SH + CYTEC G30 - 5-Axis Head ( HSK-A100 , 10,000 RPM )

S/no. VB-1020 Shipment day : Aug. 30, 2001.

Customer : Tianjin University ( China )


Dmc series of end user4

DMC-Series of end user

Model: DMC-2600SH + CYTEC G-30 - 5-Axis Head

( HSK-A100 , 10,000 RPM )

S/no. VGB-3009

Shipment day : Oct. 24, 2003.

Customer :

KEMCO Tool & Machine ( USA )

Component for Aero Industries.


5791041

DMC+5-Axis of end user


Dmc 5 axis of end user

DMC+5-Axis of end user


Dmc series of end user5

DMC-Series of end user

Model: DMC-4000 + CYTEC M21 - 5-Axis Head ( HSK-A63 , 18,000 RPM )

S/no. VH-2049 Shipment day : Nov. 15, 2002.

Customer : Nagata India Limited ( Japanese company )

Car Sheet Metal Model.


Sdmc series of end user

SDMC-Series of end user

SDMC - 28000-2 Head ( 28000 x 3600 x 1000 mm )

用户:中国南车集团株洲车辆厂
