Ofdm transmission over wideband channel

OFDM Transmission over Wideband Channel

Gwo-Ruey Lee


Outlines

Outlines

  • OFDM Transmission over Wideband Channel

    • The Time Dispersive Channel Model

    • Effects of Time Dispersive Channels on OFDM

    • Channel Estimation

      • Time Domain Channel Estimation

      • Frequency Domain Channel Estimation

    • Equalization

      • Comparisons of Time- and Frequency- Domain Equalization


The time dispersive channel model

The Time Dispersive Channel Model

1/3

  • A time-dispersive channel can be characterized by its channel impulse response

    where

    is the number of multipath components

    is the path gain of path i

    is the path delay of path i


The time dispersive channel model1

The Time Dispersive Channel Model

2/3

  • Each path gain is a complex random variable with uniformly distributed phases and Rayleigh distributed magnitude.

  • The average power of each path decays exponentially.


The time dispersive channel model2

The Time Dispersive Channel Model

3/3

  • The mathematical model for the time dispersive channel is

    where is the sampling period, and is

    the root-mean-squared (RMS) delay spread.


Effects of time dispersive channels on ofdm

Effects of Time Dispersive Channels on OFDM

1/1

  • The phenomenon of multipath fading causes previous symbol to interfere with the latter symbol. This is known as the inter-symbol interference (ISI).

  • The received signal is the convolution of

    the transmitted symbols and the discrete-time

    channel impulse response.


Channel estimation

Channel Estimation

1/9

  • Channel estimation is the task of estimating the frequency response of the radio channel the transmitted signal travels before reaching the receiver antenna.

  • The channel estimation can be performed using the time domain approach and frequency domain approach.

    • Time domain channel estimation

    • Frequency domain channel estimation


Time domain channel estimation

Time Domain Channel Estimation

2/9

  • This channel estimation is performed using the time domain approach, before FFT processing of the training symbols.

  • In this, the channel impulse response instead of the channel frequency response, is estimated.


Time domain channel estimation1

Time Domain Channel Estimation

3/9

  • The received time domain signals are

    is the channel impulse response.

    is the known symbol.

    is noise.


Time domain channel estimation2

Time Domain Channel Estimation

4/9

  • The time domain convolution can be expressed as a matrix vector multiplication.

  • The parameter L is defined as the maximum length of the impulse response, L<64.


Time domain channel estimation3

Time Domain Channel Estimation

5/9

  • Then receive signal is expressed as


Time domain channel estimation4

Time Domain Channel Estimation

6/9

  • The least square (LS) estimate for is


Frequency domain channel estimation

Frequency Domain Channel Estimation

7/9

  • This channel estimation is performed using the frequency domain approach.

  • In this, the channel frequency response is estimated by using two repeat training sequences.


Frequency domain channel estimation1

Frequency Domain Channel Estimation

8/9

  • We get (4.2) from (4.1) through FFT transform,

  • If we have two repeat sequences,


Frequency domain channel estimation2

Frequency Domain Channel Estimation

9/9

  • The least square (LS) estimate for each is


Comparisons of time and frequency domain equalization

Comparisons of Time- and Frequency-Domain Equalization

1/1


References

References

  • [1] L. Hanzo, W. Webb and T. Keller, Single- and multi-carrier quadrature amplitude modulation – Principles and applications for personal communications, WLANs and broadcasting, John Wiley & Sons, Ltd, 2000.

  • [2] Mark Engels, Wireless Ofdm Systems: How to Make Them Work? Kluwer Academic Publishers.

  • [3] John Terry, Juha Heiskala, OFDM Wireless LANs: A Theoretical and Practical Guide, Sams.
