Presentation Transcript
Remote sensing technology for scalable information networks l.jpg

Remote Sensing Technology for Scalable Information Networks

Douglas G. Goodin

Kansas State University

Geoffrey M. Henebry

University of Nebraska - Lincoln


Slide2 l.jpg

What is the role of remote sensing

in ecological research?

Ecological Remote Sensing enables recurrent observation…


Slide3 l.jpg

…at vast but variable spatial extents…


Slide4 l.jpg

…at multiple spatial scales…

Konza

Konza Prairie – 4 m resolution

Konza Prairie – 1000 m resolution




Remote sensing technology is l.jpg
Remote Sensing Technology is

  • Hardware – sensors, computers, storage, distribution networks

  • Software – commercial, public domain,

    user-created

  • “Wetware”– scientists, data managers


What are the elements of remote sensing technology from an ecological perspective l.jpg
What arethe Elements of Remote Sensing Technology (from an ecological perspective)?

  • Orbital, airborne, near-ground sensor systems

  • Ranges of spatial, temporal, & spectral resolutions

  • System for data acquisition, processing, distribution, & archiving

  • Algorithms to retrieve biogeophysical variables

  • Theory for interpretation & prediction




Slide11 l.jpg

Landsat

  • US – Private/Gov’t

  • Moderate spatial resolution

  • 1972-Present


Slide12 l.jpg

IKONOS

  • US – Private

  • 1999 – present

  • Very fine spatial resolution (1-4m)


Slide13 l.jpg

NOAA – Polar Orbiter

  • US Government

  • Coarse spatial resolution, global coverage

  • 1982 - Present


Slide14 l.jpg

RADARSAT

  • Canada – Gov’t/private

  • Imaging radar

  • 1996 - Present


Slide15 l.jpg

Terra/EO-1

“Next-Generation” – Earth Observation

  • Multi-instrument platform

  • Multispectral, hyperspectral

Coordinated observation

With Landsat - 7


Slide16 l.jpg

Aircraft Sensing Systems

  • Flexible mission planning

  • Selectable spatial resolution

  • High cost (?)


Slide17 l.jpg

AVIRIS

  • US Gov’t (NASA)

  • Hyperspectral (224 bands)

  • Multiple Aircraft (ER-2, Twin Otter)


Slide18 l.jpg

Other Aircraft Systems

  • Multiple (light) aircraft platforms

  • (Relatively) modest cost

  • Researcher control!


Slide19 l.jpg

Close Range Remote Sensing

  • A wide variety of multi/hyper

    spectral instruments

  • Not just “ground truth”

  • Researcher control


What are the elements of remote sensing technology from an ecological perspective21 l.jpg
What are the Elements of Remote Sensing Technology (from an Ecological perspective)?

  • Orbital, airborne, near-ground sensor systems

  • Ranges of spatial, temporal, & spectral resolutions

  • System for data acquisition, processing, distribution, & archiving

  • Algorithms to retrieve biogeophysical variables

  • Theory for interpretation & prediction


Slide22 l.jpg

Types of Earth Observing Sensors Ecological perspective)?


Slide23 l.jpg

Spatial Resolution Ecological perspective)?

Coarse

Moderate

Fine


Slide24 l.jpg

Spectral Resolution Ecological perspective)?

Panchromatic: 1 spectral band - very broad

Multispectral: 4-10 spectral bands - broad

Superspectral: 10-30 spectral bands - variable

Hyperspectral: >30 spectral bands - narrow

The challenge of hyperspectra is to reduce dense, voluminous, redundant data into a compact, effective suite of superspectral bands and indices for retrieval of biogeophysical fields.


What are the elements of remote sensing technology from an ecological perspective25 l.jpg
What are the Elements of Remote Sensing Technology (from an Ecological perspective)?

  • Orbital, airborne, near-ground sensor systems

  • Ranges of spatial, temporal, & spectral resolutions

  • System for data acquisition, processing, distribution, & archiving

  • Algorithms to retrieve biogeophysical variables

  • Theory for interpretation & prediction


Slide26 l.jpg

Data Handling System - Hardware Ecological perspective)?

Acquisition

Distribution/Storage

Processing


Slide27 l.jpg

Data Ecological perspective)?analysis system – linkages are critical

Researchers/

Groups

Archiving/Distribution


Slide28 l.jpg

The MODIS system Ecological perspective)?

An example


What are the elements of remote sensing technology from an ecological perspective29 l.jpg
What are the Elements of Remote Sensing Technology (from an Ecological perspective)?

  • Orbital, airborne, near-ground sensor systems

  • Ranges of spatial, temporal, & spectral resolutions

  • System for data acquisition, processing, distribution, & archiving

  • Algorithms to retrieve biogeophysical variables

  • Theory for interpretation & prediction


Slide30 l.jpg

Retrieval of Biogeophysical Quantities & Indices Ecological perspective)?

R = òòf(,) sin cos d d

T = [BT*(es)-1].25

NDVI = (rNIR - rRed)/(rNIR + rRed)

EVI =2.5*(rNIR-rRed)/(L+rNIR+C1*rRed-C2*rBlue)

s0 = [(S(i=1..N)xi2)/N] * [(C/k) * (sin a)/(sin aref)]


Slide31 l.jpg

Calibration to derive physical quantities: an engineering problem

  • Does the instrument give the correct physical data?

  • Is the instrument’s range & sensitivity appropriate for the application?

  • Cross-sensor calibration


Slide32 l.jpg

Calibration to derive ecological quantities: a scientific problem

  • Can the sensor data yield ecologically relevant relationships?

  • NOT ground “truth” – ground level observation RESCALING

  • Empirical relationships are site & time specific but reflectance, emission, and backscattering are interactions not intrinsic properties of observable entities


Slide33 l.jpg

Calibration to derive ecological quantities: a scientific problem

  • Top-down vs. bottom-up modeling perspectives

  • Model invertibility

  • Model robustness




What are the elements of remote sensing technology from an ecological perspective36 l.jpg
What are the Elements of Remote Sensing Technology (from an Ecological perspective)?

  • Orbital, airborne, near-ground sensor systems

  • Ranges of spatial, temporal, & spectral resolutions

  • System for data acquisition, processing, distribution, & archiving

  • Algorithms to retrieve biogeophysical variables

  • Theory for interpretation & prediction


Slide37 l.jpg

To enable ecological forecasting, Ecological perspective)?

we need monitoring strategies for

change detection:perceiving the differences

change quantification: measuring the magnitudes of the differences

change assessment: determining whether the differences are significant

change attribution: identifying or inferring the proximate cause of the change


Slide38 l.jpg

Observations Ecological perspective)?

Retrieval of

biogeophysical

variables

Ground segment

Acquisition, processing,

storage, & archiving

Information for

Ecological

Forecasting

Ecological

Questions &

Hypotheses

Change attribution

Change assessment

Assimilation of current

observational datastreams

Change detection

Change quantification

Spatio-Spectral-

Temporal

analysis

Definitions of nominal

trajectories and

estimates of uncertainty


Slide40 l.jpg

ACKNOWLEDGMENTS Ecological perspective)?

DGG acknowledges support from NASA EPSCoR subcontract 12860.

GMH acknowledges support from NSF #9696229/0196445 & #0131937.
